Bently Nevada 22810-00-10-10-02 is a 7200 8 mm M10 × 1 proximity probe with a 100 mm case, stainless-steel lead armor, a 1.0 m integral lead and miniature male coaxial connector.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for 22810-00-10-10-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 22810-00-10-10-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    22810-00-10-10-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    8 mm Standard Mount Probe
  • Stock:
    1
  • Case thread:
    M10 × 1
  • Overall case length:
    100 mm
  • Unthreaded length:
    0 mm
  • Integral cable length:
    1.0 m
  • Lead armor:
    Stainless-steel lead armor
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    22x20x1.5cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals M10 Mount Armored Lead 5 m Signal Product Applications

Features:

  • Metric case: An M10 × 1 thread carries the standard 8 mm sensing tip.
  • 100 mm case: The 10 metric case option selects 100 mm overall length.
  • Armored lead: A 1.0 m integral cable has stainless-steel armor.
This configuration combines a 100 mm threaded case with 0 mm unthreaded length.

The integral coaxial lead ends in a miniature male connector for the chosen extension cable.

The complete 7200 loop also uses a Proximitor to condition the probe signal for monitoring.

Apter Power can provide technical documentation, a quotation and 7200 configuration support for the Bently Nevada 22810-00-10-10-02 8 mm Standard Mount Probe.
Bently Nevada 22810-00-10-10-02 8 mm Standard Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Metric thread: The 22810 case is M10 × 1.
  • Case reach: The 10 option is 100 mm overall length.
  • Tip section: The 00 option adds 0 mm unthreaded length.
  • Sensing face: The standard tip diameter is 8 mm.
  • Integral length: The 10 lead option provides 1.0 m of coaxial cable.
  • Mechanical covering: The 22810 family uses stainless-steel lead armor.
  • Coax termination: The 02 option has a miniature male connector.
  • Tip connection: The standard 8 mm 7200 design includes Cable LoC.
  • Combined length: A 1.0 m integral lead and 4.0 m extension form a 5 m path.
  • Conditioning unit: The 18745-03 Proximitor is specified for that five-metre path.
  • Probe task: The 8 mm tip senses displacement from the target surface.
  • Monitor signal: The Proximitor conditions the return signal for display.
  • Radial vibration: A complete 7200 loop can monitor bearing-area shaft motion.
  • Axial thrust: The assembled system can sense shaft thrust position.
  • Rotor bow: Eccentricity is a documented 7200 system measurement.
  • Average position: The full loop can measure radial shaft position.
Description
With an M10 × 1 case and stainless-steel lead armor, 22810-00-10-10-02 is the 100 mm-case version of the 7200 standard 8 mm proximity probe. It belongs to the metric-threaded 22810 family.

The 00 option leaves no unthreaded tip length, while a 1.0 m integral cable ends in a miniature male coaxial connector. These dimensions give 22810-00-10-10-02 a specific case-and-lead arrangement for the installed probe mount.

A complete 7200 measurement channel pairs 22810-00-10-10-02 with the extension length and Proximitor selected for the total loop. The probe senses target gap; the Proximitor conditions that signal for the monitoring system.
Alternative Names
Bently Nevada 22810-00-10-10-02 22810 00 10 10 02 22810/00/10/10/02 2281000101002
Technical notes
The 22810-00-10-10-02 order code specifies a 100 mm M10 × 1 case with 0 mm unthreaded length; its 10 lead option is 1.0 m. The 7200 system length is determined by this integral lead plus the extension cable, not by case length. A nominally similar probe with another case code changes installation geometry without changing the electrical lead option.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Will 22810-00-10-10-02 fit an M10 × 1 mounting point planned for a 100 mm probe case?
Yes. Its metric thread is M10 × 1 and its overall case option is 100 mm; the mounting depth must accommodate that case.
Does 22810-00-10-10-02 have an exposed unthreaded length beyond its threaded case?
No. The 00 option means 0 mm unthreaded length; it does not add a separate unthreaded reach.
Does 22810-00-10-10-02 include armor around its integral lead?
Yes. The 22810 probe family includes stainless-steel lead armor, distinct from the unarmored 22811 family.
Which extension length completes a 5 m 7200 path with 22810-00-10-10-02?
A 4.00 m extension combines with its 1.0 m integral lead for the five-metre arrangement specified with the 18745-03 Proximitor.
Can 22810-00-10-10-02 alone send a calibrated displacement output to a monitor?
No. This probe needs the appropriate 7200 extension cable and Proximitor; the system-level output is not an individual probe rating.
Is the 02 termination on 22810-00-10-10-02 a miniature male coaxial connector?
Yes. The final 02 option specifies the miniature male coaxial connector for the 7200 cable path.
