81305-040-00

/ 4.9
1001 reviews | Need a Specific Revision?
81305-040-00 is a Bently Nevada 7200 14 mm extension cable with a 4.01 m electrical length and no armor. The -040 option is specified for the 81725-01 five-metre Proximitor sensor.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for 81305-040-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 81305-040-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    81305-040-00
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    14 mm Extension Cable
  • Stock:
    1
  • Cable electrical length:
    4.01 m (158 in), ±10%
  • Armor:
    None (-00 option)
  • Specified Proximitor:
    81725-01 five-metre system
  • Minimum bend radius:
    25.4 mm without armor
  • Probe/cable temperature:
    -34.4°C to +177°C
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    19x19x1.5cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals System Match Cable Routing Signal Chain Product Applications

Features:

  • Specified electrical length: The -040 option provides a 4.01 m cable for the 7200 14 mm system.
  • Unarmored construction: The -00 option has no cable armor and a 25.4 mm minimum bend radius.
  • Defined sensor pairing: Bently Nevada specifies this -040 cable only with the 81725-01 five-metre Proximitor sensor.
81305-040-00 sits between the 14 mm probe lead and Proximitor sensor in a 7200 proximity measurement chain.

The -040 selection establishes a 4.01 m electrical cable length; the published ordering table ties that selection to a five-metre system using 81725-01.

The unarmored lead needs a routing path that respects its minimum bend radius and keeps the installed connectors protected.

Apter Power can support an 81305-040-00 Bently Nevada 14 mm Extension Cable enquiry with a scoped quotation and 7200 system documentation.
Bently Nevada 81305-040-00 14 mm Extension Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Cable role: 81305-040-00 connects the 14 mm probe lead to the Proximitor in a 7200 transducer chain.
  • Five-metre selection: The -040 extension is listed for use with the 81725-01 five-metre Proximitor sensor.
  • Length pairing: The probe lead and extension cable together establish the intended probe-to-sensor system length.
  • Component boundary: The cable passes the probe signal; it is not the powered Proximitor sensor.
  • Unarmored route: The -00 configuration has no armor and needs a 25.4 mm minimum bend radius.
  • Electrical length: The -040 ordering option is 4.01 m with a ±10% tolerance.
  • Temperature scope: The 7200 document gives the probe and extension cable an operating range of -34.4°C to +177°C.
  • Connector protection: The 14 mm system humidity statement assumes the connectors are protected and does not describe submersible service.
  • System principle: The complete 7200 assembly provides a non-contact gap-to-voltage measurement.
  • Sensor power: The published -18 to -24 Vdc requirement belongs to the Proximitor sensor, not the passive extension cable.
  • 14 mm response: The 4.06 mm linear range is a calibrated system specification, not a cable-only rating.
  • Monitor connection: Bently Nevada lists the 7200 transducer system for use with 3300 and 3500 monitors.
  • Radial vibration: A complete 7200 14 mm chain can observe rotor movement for bearing-condition monitoring.
  • Axial thrust: The assembled transducer system can follow rotor position along the shaft axis.
  • Eccentricity: The 7200 system supports shaft-bow measurements during large-turbine startup.
  • Rod drop: A configured chain can contribute to rider-band wear measurement on reciprocating compressors.
Description
81305-040-00 is the unarmored 4.01 m extension cable in Bently Nevada's 7200 14 mm proximity transducer system. It joins the probe lead to a compatible Proximitor sensor, helping complete the specified five-metre measurement chain.

For 81305-040-00, the 7200 ordering table limits the -040 cable option to the 81725-01 five-metre Proximitor sensor. That distinction matters when replacing a cable because the probe, extension lead and sensor are selected as a system length.

The 81305-040-00 carries the probe signal; the -24 Vdc power specification belongs to the Proximitor sensor, not the passive cable. The unarmored cable has a 25.4 mm minimum bend radius, a useful routing detail for the installed measurement chain.
Alternative Names
Bently Nevada 81305-040-00 BN 81305-040-00 81305 040 00 8130504000 81305-040-00 14 mm extension cable Bently Nevada 81305 040 00 BN 81305 040 00 81305 040 00 extension cable
Technical notes
The 81305-040-00 cable's -040 electrical-length option is specified for the 81725-01 five-metre 7200 sensor arrangement. A lead with the same connector but a different electrical length changes the probe-to-sensor chain and may move the measurement outside the published system response. Apter Power can help match the installed chain before quotation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does 81305-040-00 suit an armored cable run?
The -00 cable is unarmored. Where the installed route requires armor, Apter Power can help identify the documented armored option rather than quote this version as an armored replacement.
Can 81305-040-00 be routed around a very tight cabinet bend?
The published minimum bend radius for the unarmored cable is 25.4 mm. A tighter route calls for a different path or cable arrangement to protect the signal lead.
Does 81305-040-00 need its own power connection?
This extension cable carries the probe signal; the Proximitor sensor receives system power. Apter Power can help distinguish the cable from the powered sensor when preparing a spare-parts quote.
