22811-01-06-10-02

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 22811-01-06-10-02 is a 7200 8 mm M10 × 1 probe with a 10 mm unthreaded section, 60 mm case, unarmored 1.0 m lead and miniature male coaxial connector.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 22811-01-06-10-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 22811-01-06-10-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    22811-01-06-10-02
  • Product Family:
    7200 Proximity Transducer Systems
  • Product Type:
    8 mm Standard Mount Probe
  • Stock:
    1
  • Case thread:
    M10 × 1
  • Overall case length:
    60 mm
  • Unthreaded length:
    10 mm
  • Integral cable length:
    1.0 m
  • Lead armor:
    Without lead armor
  • Connector:
    Miniature male coaxial
  • Weight:
    0.06 kg
  • Estimated shipping dimensions:
    1.8x1.8x116cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals 10 mm Tip Section Lead Routing Five-metre Loop Product Applications

Features:

  • Unthreaded tip: The 01 option supplies 10 mm ahead of the threaded section.
  • 60 mm case: The 06 metric option defines overall M10 × 1 case length.
  • Unarmored one-metre lead: The 22811 family has no stainless-steel lead covering.
This 8 mm probe separates the 10 mm unthreaded section from its 60 mm overall case length.

The 1.0 m integral cable ends in the 02 miniature male coaxial connector.

A 7200 extension cable and Proximitor complete the noncontact measurement loop.

Apter Power can provide technical documentation, a quotation and 7200 configuration support for the Bently Nevada 22811-01-06-10-02 8 mm Standard Mount Probe.
Bently Nevada 22811-01-06-10-02 8 mm Standard Mount Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Unthreaded length: The 01 metric option specifies 10 mm.
  • Case length: The 06 option is 60 mm overall.
  • Mounting thread: The 22811 housing uses M10 × 1.
  • Sensing tip: The standard 7200 probe diameter is 8 mm.
  • Integral cable: The 10 option is 1.0 m.
  • Armor: The 22811 family leaves the lead unarmored.
  • Termination: The 02 option is a miniature male coaxial connector.
  • Cable junction: Cable LoC strengthens the improved 8 mm tip-to-lead connection.
  • Lead combination: A 1.0 m probe lead plus 4.0 m extension makes 5 m.
  • Proximitor: The 18745-03 is the listed five-metre unit.
  • Gap sensing: The probe tip detects distance to the shaft target.
  • Conditioned output: The Proximitor supplies the signal to the monitor.
  • Radial vibration: A complete 7200 system can observe shaft motion.
  • Average shaft position: The assembled loop can measure radial location.
  • Axial thrust: The system can indicate thrust position.
  • Rotor eccentricity: The complete transducer loop can measure bow.
Description
The 10 mm unthreaded section of 22811-01-06-10-02 distinguishes this 7200 standard 8 mm probe from the flush-option 00 versions. Its metric M10 × 1 case measures 60 mm overall.

A 1.0 m integral lead ends in a miniature male coaxial connector. Because the 22811 family has no stainless-steel lead armor, 22811-01-06-10-02 relies on the installation route for any additional cable protection.

As part of a complete 7200 transducer loop, 22811-01-06-10-02 senses target gap at the probe tip. The chosen extension cable and Proximitor establish the total electrical length and deliver the conditioned monitoring signal.
Alternative Names
Bently Nevada 22811-01-06-10-02 22811 01 06 10 02 22811/01/06/10/02 2281101061002 22811-01-06-10-02 7200 probe
Technical notes
On 22811-01-06-10-02, the 01 and 06 options specify a 10 mm unthreaded section and a 60 mm overall M10 × 1 case. The unthreaded section affects where the 8 mm tip sits relative to the mounting face; it is not extra cable reach. The unarmored 1.0 m integral lead is a separate routing constraint.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does 22811-01-06-10-02 provide a 10 mm unthreaded tip for a recessed M10 mounting point?
Yes. Its 01 option provides 10 mm unthreaded length within a 60 mm overall M10 × 1 case.
Will 22811-01-06-10-02 fit where the installed probe case must be 60 mm long?
Yes. The 06 metric case option specifies 60 mm; the available mounting depth still determines placement.
Is the integral cable on 22811-01-06-10-02 protected by stainless-steel armor?
No. The 22811 family is supplied without lead armor, so the planned cable route determines external protection needs.
Which extension length makes a five-metre 7200 path with 22811-01-06-10-02?
A 4.00 m extension combines with its 1.0 m integral lead for the 18745-03 five-metre arrangement.
Does Cable LoC on 22811-01-06-10-02 replace the need for cable-route protection?
No. The 7200 standard 8 mm design secures the lead at the probe tip, but this 22811 configuration remains unarmored along its integral cable.
Can 22811-01-06-10-02 alone supply a calibrated vibration reading?
No. It is the sensing probe; the matching extension cable and Proximitor are needed for the complete 7200 signal chain.
