330881-16-00-175-00-02

/ 4.9
1001 reviews | Need a Specific Revision?
The 330881-16-00-175-00-02 is a PROXPAC XL self-contained transducer with PPS housing, M24 x 3 thread, 175 mm probe penetration, integrated Proximitor sensor, and Type 4X/IP66 rating.
Get a quick price for 330881-16-00-175-00-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330881-16-00-175-00-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330881-16-00-175-00-02
  • Product Family:
    PROXPAC XL Proximity Transducer Assembly
  • Product Type:
    PROXPAC XL Proximity Transducer Assembly
  • Probe:
    3300 XL 8 mm (without approvals)
  • Housing Material:
    PPS with glass and conductive fibers
  • Mounting Thread:
    M24 x 3
  • Standoff Adapter:
    None
  • Probe Penetration:
    175 mm
  • Fittings:
    None (two plugs, two washers included)
  • Enclosure Rating:
    Type 4X, IP66
  • Key Benefit:
    Solves deep-well mounting in corrosive environments—175 mm penetration, PPS housing resists chemicals, no extension cable, Type 4X/IP66 rated for outdoor/washdown use.
  • Weight:
    1.45 kg
  • Estimated shipping dimensions:
    36.5x9x9.3cm
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Connectivity Safety and Compliance

Features:

  • PPS housing with glass and conductive fibers provides corrosion resistance and electrostatic dissipation.
  • 175 mm probe penetration with M24 x 3 thread for deep-well mounting without standoffs.
  • Self-contained design eliminates extension cable and separate Proximitor housing.
The 330881-16-00-175-00-02 slides 175 mm into your machine. M24 x 3 threads anchor it securely. No standoffs, no adapters—just thread it in and reach the target.

PPS with glass fibers replaces metal. No rust, no pitting. Type 4X and IP66 ratings mean install it outdoors, in washdowns, or on offshore platforms. The 330881-16-00-175-00-02 survives where aluminum fails.

No extension cable. No separate Proximitor box. Just wire straight from the monitor to the 330881-16-00-175-00-02. Fewer connections, less panel space, faster installation.

The 330881-16-00-175-00-02 Bently Nevada PROXPAC XL Proximity Transducer may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330881-16-00-175-00-02 PROXPAC XL Proximity Transducer Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330881-16-00-175-00-02 PROXPAC XL Proximity Transducer Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330881-16-00-175-00-02
  • Condition New Original ready stock
  • Product Family 330881-00-00-175-00-02,330881-01-00-175-00-02,330881-16-00-175-05-02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Rotating Machinery Protection: Monitoring radial vibration (axial oscillation) and axial displacement (thrust position) of large steam turbines, compressors, pumps, and fans.
  • Space-Confined Environments: The integrated probe and sensor eliminate the need for extension cables, making it suitable for surface mounting and simplifying on-site wiring.
  • Harsh Industrial Environments: The housing offers excellent resistance to chemical corrosion, UV radiation, and sealing performance, making it suitable for refineries, chemical plants, and offshore platforms.
  • Specific Specifications and Applications: This model features a 175 mm probe penetration depth (Option -175), suitable for machine housings requiring deeper penetration.
  • Integrated Architecture: The probe and sensor are integrated internally, eliminating the need for extended cables between the probe and sensor, significantly reducing signal attenuation and potential connector failure risks.
  • Field Wiring: Supports 16 to 24 AWG field cables. Three-core shielded cable is recommended for signal transmission to monitoring instruments up to 305 meters (1,000 feet) away.
  • Interface Specifications: This model uses 3/4-14 NPT mounting threads (Option -02), but does not come with specific connector accessories (Option -00), and is suitable for direct screwing into standard process interfaces.
  • Protection Rating: The enclosure meets IP66 and Type 4X standards, effectively protecting against moisture, dust, and corrosive media intrusion.
  • Electromagnetic Compatibility (EMC): Complies with CE directives (e.g., EN 61000-6-2/4), providing extremely high immunity to radio frequency interference (RFI/EMI).
  • Functional Safety: As part of the 3300 XL series, it supports functional safety applications up to SIL 2 (single-channel) or SIL 3 (redundant configuration) in systems meeting specific conditions.
  • Material Compliance: The enclosure is made of glass fiber reinforced PPS, providing electrostatic dissipation and complying with industrial safety operating procedures.
Description
The 330881-16-00-175-00-02 combines a 3300 XL 8 mm probe without approvals into a self-contained assembly. Its M24 x 3 metric thread mounts directly into large-bore ports, while 175 mm probe penetration reaches deep into thick casings. The housing is molded from PPS with glass and conductive fibers, replacing steel and aluminum for corrosion resistance and electrostatic dissipation.

Inside the 330881-16-00-175-00-02, the Proximitor sensor lives in the housing cover—no extension cable, no separate sensor box. Field wiring connects straight from monitors to the assembly. This self-contained design eliminates two connectors and a cable, reducing failure points and installation time.

The 330881-16-00-175-00-02 carries Type 4X and IP66 ratings, meaning it withstands dust, water, and corrosion. Install it outdoors, in washdown areas, or on offshore platforms. The PPS housing resists chemicals that would eat aluminum. The M24 x 3 thread provides a robust anchor for heavy-duty applications.

This assembly solves the pain point of deep-well mounting in corrosive environments. The 330881-16-00-175-00-02 reaches 175 mm into machinery without standoffs, while its PPS housing stands up to salt spray and chemicals. No extension cable means fewer connections to fail. No separate Proximitor housing means simpler panels.
Alternative Names
330881-00-00-175-00-02 330881-01-00-175-00-02 330881-16-00-175-05-02 330881-16-00-175-06-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What thread does the 330881-16-00-175-00-02 use?
M24 x 3 metric thread for large-bore mounting ports.
Is the housing corrosion resistant?
Yes. PPS with glass and conductive fibers replaces steel and aluminum, resisting salt spray and chemicals.
What environmental ratings does this assembly carry?
Type 4X and IP66—dust-tight, water-resistant, and corrosion-protected for outdoor and washdown installations.
Does this assembly include a probe?
Yes. It comes with a 3300 XL 8 mm probe without hazardous area approvals.
