The Bently Nevada 330881-16-10-110-06-02 is a fully self-contained proximity transducer assembly featuring an integrated 3300 XL Proximitor sensor for simplified installation and high-performance shaft monitoring.
Get a quick price for 330881-16-10-110-06-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330881-16-10-110-06-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330881-16-10-110-06-02
  • Product Family:
    PROXPAC XL Proximity Transducer Assembly
  • Probe and Approvals Option:
    3300 XL 8 mm probe without approvals
  • Standoff Adapter Option (B Dimension):
    100 mm
  • Probe Penetration Option (C Dimension):
    110 mm
  • Fittings Option (supplied as a kit):
    One 3/4-14 NPT fitting, one 3/414 NPT to 1/2-14 NPT SST reducer and two plugs
  • Mounting Thread Option:
    3/4-14 NPT (required if ordering Standoff Adapter Option)
  • Output resistance:
    50 Ω
  • Weight:
    1.35 kg
  • Estimated shipping dimensions:
    36.5x9x9.3cm
  • Tariff Code:
    7307990000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Standards Application Interoperability

Features:

  • Offers A Fully Self-Contained Proximity Transducer With Integrated 3300 XL Sensor
  • Provides Superior Environmental Protection And Electrostatic Dissipation With PPS Housing
  • Simplifies Installation And Reduces Wiring Complexity Compared To Older Probe Assemblies
The Bently Nevada 330881-16-10-110-06-02 PROXPAC XL is a high-integrity proximity transducer assembly designed for precision shaft monitoring in industrial machinery. Unlike the earlier 31000 and 32000 Proximity Probe Housing Assemblies, the PROXPAC XL integrates the 3300 XL Proximitor sensor directly within the housing cover. This self-contained design eliminates the need for separate Proximitor housings and extension cables, streamlining installation while maintaining reliable analog signal output for high-performance monitoring.

Engineered for demanding environments, the 330881-16-10-110-06-02 features an 8 mm probe, 100 mm standoff adapter, and 110 mm probe penetration. The supplied fitting kit includes a 3/4-14 NPT fitting, a 3/4-14 NPT to 1/2-14 NPT stainless steel reducer, and two plugs. With a 50 Ω output resistance and direct field wiring capability, the assembly provides precise measurement and seamless integration with standard Bently Nevada monitoring systems, offering advantages over the 31000/32000 series that require additional cabling and housings.

Constructed from advanced Polyphenylene Sulfide (PPS) thermoplastic reinforced with glass and conductive fibers, the PROXPAC XL housing ensures high mechanical strength, effective electrostatic charge dissipation, and protection in Type 4X/IP66 rated environments. Its design allows field wiring to connect directly to the monitoring system, reducing installation errors and maintenance effort. Overall, the 330881-16-10-110-06-02 PROXPAC XL delivers enhanced reliability, simplified installation, and improved environmental resilience compared to older Bently Nevada probe assemblies.

The 330881-16-10-110-06-02 Bently Nevada PROXPAC XL Proximity Transducer may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330881-16-10-110-06-02 PROXPAC XL Proximity Transducer Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330881-16-10-110-06-02 PROXPAC XL Proximity Transducer Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330881-16-10-110-06-02
  • Condition New Original ready stock
  • Product Family 330881-28-07-155-06-02,330881-16-00-307-06-02,330881-16-00-200-06-025
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Explosion-proof Certification: Certified by METI (Japan), CSA (Canada/USA), ATEX (Europe), and IECEx (International), suitable for flammable and explosive areas such as Zone 0/1 or Class I, Division 1.
  • Functional Safety: Supports SIL 2 Safety Instrumented System (SIS) configuration, meeting high-reliability monitoring requirements.
  • Electromagnetic Compatibility (EMC): Complies with EN 61326-1 standard, possessing strong immunity to radio frequency interference (RFI) and magnetic field interference, ensuring data stability.
  • Environmental Protection: Equipped with IP66-level enclosure protection, the probe tip can withstand high-pressure liquid spray and dust intrusion.
  • Axial Displacement Monitoring: Measures the axial movement of the rotor in turbines, compressors, or pumps, preventing rotor-stator collisions.
  • Radial Vibration Measurement: Real-time capture of vibration amplitude (Peak-to-Peak) of high-speed rotating shafts to identify imbalances, misalignments, or bearing wear faults.
  • Keyphasor Detection: Serves as a speed and phase reference signal for mechanical diagnostic analysis (e.g., Bode plots, polar plots).
  • Space-Constrained Installation: The integrated probe and preamplifier design makes it particularly suitable for confined space environments where a separate preamplifier enclosure cannot be installed.
  • System Integration: Directly connects to the Bently Nevada 3500 monitoring system (e.g., the 3500/42M module) or the Distributed Proximitor® architecture.
  • Backend Interchangeability: Its output signal is a standard 7.87 V/mm (200 mV/mil) voltage signal, fully consistent with the signal characteristics of the standard 3300 XL 8mm preamplifier, eliminating the need for system recalibration.
  • Wiring Definition: Employs a standard 3-wire (Power, Common, Signal) connection, compatible with industry-standard shielded twisted-pair cables.
  • Physical Installation: The 330881 series offers flexible thread gauges (1/2-14 NPT or M20x1.5) and probe extension lengths, compatible with various mechanical housing opening sizes.
Description
The Bently Nevada 330881-16-10-110-06-02 PROXPAC XL Proximity Transducer is a complete, self-contained proximity probe system designed for precision shaft position monitoring in industrial and turbomachinery applications. Unlike the 31000 and 32000 Proximity Probe Housing Assemblies, which require separate Proximitor sensors and extension cabling, the PROXPAC XL integrates its own 3300 XL Proximitor sensor within the housing cover. This design eliminates the need for separate Proximitor housings and reduces installation complexity while improving signal reliability.

The assembly features a 3300 XL 8 mm probe without approvals, a standoff adapter option of 100 mm, and a probe penetration option of 110 mm. Fittings are supplied as a kit including one 3/4-14 NPT fitting, one 3/4-14 NPT to 1/2-14 NPT stainless steel reducer, and two plugs. The mounting thread option is 3/4-14 NPT, which is required if ordering the standoff adapter option. With an output resistance of 50 Ω, the 330881-16-10-110-06-02 delivers precise analog signal outputs compatible with standard Bently Nevada monitoring systems.

Constructed from advanced Polyphenylene Sulfide (PPS) thermoplastic reinforced with glass and conductive fibers, the PROXPAC XL housing provides superior strength, improved electrostatic charge dissipation, and exceptional resistance to harsh operating environments. Rated for Type 4X and IP66 protection, this assembly is ideal for severe conditions where older steel or aluminum housings in the 31000 or 32000 series may be vulnerable to corrosion or mechanical damage.

The 330881-16-10-110-06-02 PROXPAC XL allows direct connection between field wiring and monitoring systems, reducing cabling errors and simplifying maintenance compared to previous Bently Nevada designs. Its integrated design ensures accurate positioning measurements, enhanced reliability, and easier system configuration, making it the preferred solution for modern high-integrity machinery monitoring systems.
Alternative Names
330881-16-10-105-06-02 330881-16-08-095-06-02 330881-16-05-150-00-02 330881-16-00-180-03-02 330881-16-05-035-01-02
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the Bently Nevada 330881-16-10-110-06-02 PROXPAC XL used for?
It monitors shaft position and vibration with a fully self-contained proximity transducer, integrating a 3300 XL Proximitor sensor for precision measurements.
How does the PROXPAC XL differ from the 31000 or 32000 probe housings?
The PROXPAC XL integrates the Proximitor sensor into the housing, eliminating separate sensors and extension cables, while the 31000/32000 require external Proximitor connections.
What mounting thread is required?
The 330881-16-10-110-06-02 requires a 3/4-14 NPT mounting thread, necessary when using the standoff adapter option.
