PR6423/00R-111 CON041

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson EPRO PR6423/00R-111 with CON041 is a reverse-mounted 8 mm eddy-current chain using an unarmoured 5 m open-end cable. The DIN-rail converter conditions the 8 V/mm, 2 mm proximity signal.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for PR6423/00R-111 CON041
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423/00R-111 CON041

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423/00R-111 CON041
  • Product Family:
    Epro
  • Product Type:
    Reverse-Mount 8 mm Eddy Current Sensor and Converter
  • Stock:
    1
  • Sensor family:
    PR6423
  • Converter:
    CON041
  • Probe thread:
    M10 x 1
  • Cable armour:
    Unarmoured
  • Sleeve configuration:
    reverse-mount body
  • Cable length:
    5 m
  • Cable termination:
    Open end
  • Nominal sensitivity:
    8 V/mm
  • Measuring range:
    2 mm
  • Minimum shaft diameter:
    25 mm
  • Converter mounting:
    DIN rail mounting
  • Converter weight:
    60 g
  • Sensor protection:
    IP66
  • Measurement principle:
    Eddy current, non-contact
  • Weight:
    0.353 lbs (0.16 kg)
  • Estimated shipping dimensions:
    16 x 15 x 2 cm
  • Tariff Code:
    90318090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Environmental Ratings Safety Communication

Features:

  • Uses a reverse-mounted M10 × 1 PR6423 probe body.
  • Routes a 5 m unarmoured cable to open-end field conductors.
  • Works with the compact DIN-rail CON041 converter.
The 00R suffix is the key mechanical identifier because it places the mounting geometry in the reverse-body configuration. The 111 ending defines the associated cable execution.

The probe observes shaft-to-tip distance without contact, while CON041 converts that change into the signal used by the monitoring channel.

Verify bracket access, cable support and terminal designations before removal. Re-establish the electrical working point only after the reverse-mounted body is fully locked in position.

PR6423/00R-111 CON041 supply is checked against the reverse body and open-end wiring execution.
Verified resources for Emerson PR6423/00R-111 CON041:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Fit an 8 mm proximity sensor where bracket access favors reverse mounting.
  • Land a fixed five-metre probe cable directly in a monitoring cabinet terminal path.
  • Maintain a compact DIN-rail converter arrangement for shaft-relative measurement.
  • The probe body carries the documented IP66 rating when its mounting preserves the seal.
  • Unarmoured cable needs external protection from abrasion, oil exposure and impact.
  • Keep the DIN-rail converter and open conductors inside a clean, dry enclosure.
  • Secure the machine against rotation before working at the probe mounting point.
  • Protect the unarmoured cable from abrasion, hot surfaces and moving components.
  • Keep monitoring outputs inhibited until the static gap and channel polarity are verified.
  • The open-end cable carries the analog measurement path rather than a digital network protocol.
  • Shield and reference connections determine immunity to electrical noise along the five-metre run.
  • Signal continuity should be checked end-to-end before the converter output is evaluated.
Description
PR6423/00R-111 CON041 uses the reverse-body PR6423 execution for installations where the sensor must be secured from the side opposite a conventional forward sleeve. Its M10 × 1 thread, unarmoured construction and five-metre open-end lead define a compact mechanical arrangement that terminates directly at the field wiring associated with CON041.

The CON041 is a 60 g DIN-rail signal converter designed to condition the non-contact probe response at a nominal 8 V/mm over a 2 mm range. This layout separates the sensing point from cabinet electronics while avoiding a plug connection at the cable end, which can be useful where conductors land on fixed terminals.

Reverse mounting changes how thread reach, locknut access and probe-tip position are established, so an ordinary PR6423 body cannot be assumed to fit. The unarmoured cable needs its own mechanical protection, and conductor identity, shield termination and final gap must be checked before the channel is returned to machine monitoring.
Alternative Names
PR6423/00R-111 CON041 PR6423 00R 111 CON041 PR6423-00R-111-CON041 PR642300R111CON041 Emerson EPRO PR6423/00R-111 CON041 PR6423/00R-111 CON041 EPRO PR6423 Eddy Current Measurement Emerson EPRO Reverse-Mount 8 mm Eddy Current Sensor and Converter PR6423/00R-111 CON041 Reverse-Mount 8 mm Eddy Current Sensor and Converter
Technical notes
PR6423/00R-111 CON041 is a reverse-mount, open-end assembly; a forward-body substitute or incorrect conductor termination can shift the gap and defeat the protection channel.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What makes Emerson EPRO PR6423/00R-111 CON041 a reverse-mount probe?
Its 00R body geometry is arranged for installation from the opposite mounting direction and must match the bracket layout.
Where do the open-end conductors of Emerson EPRO PR6423/00R-111 CON041 terminate?
They land in the designated field wiring path for the CON041 converter according to the installation diagram.
What converter mass is listed for Emerson EPRO PR6423/00R-111 CON041?
The CON041 portion is documented at 60 g and is designed for DIN-rail mounting in the cabinet.
Why does Emerson EPRO PR6423/00R-111 CON041 need cable guarding?
Its five-metre lead is unarmoured, so the installation must prevent abrasion, crushing and contact with moving or hot surfaces.
What target condition supports the 8 V/mm response of Emerson EPRO PR6423/00R-111 CON041?
Use the documented conductive target material, surface condition and minimum geometry when establishing the working gap.
Can a forward-body PR6423 replace Emerson EPRO PR6423/00R-111 CON041?
Not without redesigning and validating the mounting, insertion depth, cable route and calibrated measurement chain.
