1C31238H01

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson 1C31238H01 is the wiring-schematic cavity insert used in documented Ovation compact contact-input, digital-input and sequence-of-events assemblies that do not require a personality module.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1C31238H01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1C31238H01

  • Manufacturer:
    Emerson
  • Part Number:
    1C31238H01
  • Product Family:
    Ovation
  • Product Type:
    Ovation Compact I/O Personality-Module Cavity Insert
  • Stock:
    1
  • Function:
    Wiring-schematic label and cavity insert
  • Supported Channel Count:
    16 at subsystem level
  • Compatible Contact Input:
    1C31234G01
  • Compatible Compact DI:
    1C31232G01, G02 or G03 as documented
  • Compatible Compact SOE:
    1C31233G01, G02, G03 or G04 as documented
  • Active Electronics:
    None in the insert
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Compatibility Installation Compliance

Features:

  • Occupies the personality-module cavity in compatible compact input assemblies.
  • Carries the wiring schematic for configurations that need no active PMOD.
  • Supports the documented 16-channel compact DI, contact-input and SOE arrangements.
The current ordering configuration is 1C31238H01, the passive cavity insert identified for selected Ovation compact input electronics modules.

It closes the unused PMOD position and gives installers the wiring reference for the exact compact contact, digital-input or event-input circuit.

Match the full electronics-module suffix and field voltage before use, and apply the hazardous-voltage label where the official manual requires it.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Emerson 1C31238H01: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Completes the PMOD cavity in a 16-channel Ovation compact contact-input assembly.
  • Provides the wiring reference for supported compact digital-input configurations without individual point fusing.
  • Provides the cavity insert used by documented compact sequence-of-events configurations.
  • The insert is listed with 1C31234G01 for 48 VDC on-card wetting contact inputs.
  • It is listed with 1C31232 compact digital-input electronics when the fused PMOD is not selected.
  • It is listed with 1C31233 compact sequence-of-events electronics in the documented voltage arrangements.
  • The insert fits the personality-module position in the Ovation base unit.
  • Its printed schematic must correspond to the electronics module and field wiring installed in that position.
  • DIN-rail base-unit installation follows the Ovation cabinet and project drawing requirements.
  • All listed compact contact-input configurations using this insert are CE Mark certified.
  • The 125 VAC/VDC compact input arrangement requires warning label 1B30025H01 on the base unit.
  • External fusing or current limiting is recommended for hazardous inputs when the fused PMOD is not used.
Description
1C31238H01 is an Ovation foam cavity insert for the personality-module position in selected 16-channel compact input assemblies. It provides the applicable wiring schematic where no active personality module is required.

The insert is documented with compact contact input 1C31234G01 and with compatible 1C31232 and 1C31233 compact digital or sequence-of-events configurations. The electrical function remains in the paired electronics module.

Select the insert only after matching the complete electronics-module suffix and field-voltage arrangement. A 125 VAC/VDC installation requires the specified hazardous-voltage warning label and project drawing identification.
Alternative Names
1C31238H01 Emerson 1C31238H01 1C31238 H01 1C31238-H01 1C31238H 01 1C31238H-01 Emerson Ovation Traditional I/O 1C31238H01 Emerson Ovation Compact I/O Personality-Module Cavity Insert
Technical notes
1C31238H01 contains no active electronics; confirm the exact mating module, wiring diagram, required warning label, and external current limiting before 125 VAC/VDC service.
