IC693CBL300

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC693CBL300 is a 1 m (3 ft) three-connector wye cable used to interconnect Series 90-30 expansion backplanes in a daisy-chain arrangement.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for IC693CBL300
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC693CBL300

  • Manufacturer:
    General Electric
  • Part Number:
    IC693CBL300
  • Product Family:
    GE 90-30 Series PLC
  • Product Type:
    I/O bus expansion cable
  • Stock:
    2
  • Cable Length:
    1 Meter / 3 Feet
  • Connector End 1:
    Single Male 25-pin D-connector
  • Connector End 2:
    wo-headed Dual Connector (One Male, One Female 25-pin D)
  • Connection Topology:
    Daisy-chain arrangement (Multi-rack configurations)
  • Compatibility:
    CPUs, remote racks
  • Feature:
    Wye adapter
  • Weight:
    0.4 lbs (0.18 kg)
  • Estimated shipping dimensions:
    3.5x1.6x114cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Compatibility Installation

Features:

  • Provides a 1 m (3 ft) expansion-bus cable length.
  • Uses a three-connector wye arrangement.
  • Contains no built-in terminating resistor.
The current ordering configuration is IC693CBL300, the 1 m wye expansion cable with two connectors at one end and one connector at the other.

It supports serial-bus connections between a universal backplane and compatible expansion backplanes within the documented cable-count and total-length limits.

Before installation, verify connector orientation, point-to-point pin mapping, cable routing, and termination at the final expansion connection.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for General Electric IC693CBL300: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

General

  • ManufacturerGeneral Electric
  • ModelIC693CBL300
  • ConditionNew Original ready stock
  • Product FamilyGE Series 90-30
  • Connect a compatible expansion backplane to the controller expansion bus.
  • Daisy-chain expansion backplanes within the documented system limits.
  • Use the wye connector as a connection point for an approved custom cable.
  • Use the cable with supported IC693 and PACSystems RX3i expansion hardware.
  • Keep the total expansion-cable length at or below 15 m (50 ft).
  • Limit the I/O expansion system to no more than seven expansion cables.
  • Maintain point-to-point pin connections through the expansion cable.
  • Install the required terminator at the final expansion connection.
  • Inspect all three connectors and secure the shells before commissioning.
Description
General Electric IC693CBL300 is a 1 m (3 ft) wye expansion cable for the PACSystems RX3i serial expansion bus and compatible IC693 backplane arrangements.

It has male and female connectors at one end and a male connector at the other. The cable has no built-in termination, so the last expansion connection requires the specified terminator arrangement.
Revisions

Revision Part #

Also known as

IC693CBL300A
IC693CBL300-A, Series A, Rev A
IC693CBL300B
IC693CBL300-B, Series B, Rev B
Alternative Names
IC693CBL300 IC693 CBL300 IC693-CBL300 GE IC693CBL300 GE Fanuc IC693CBL300 GE Series 90-30 Expansion Cable
Technical notes
IC693CBL300 is a 1 m three-connector expansion cable without built-in termination.
