General Electric IS420UCSCH1A-G-V0.1-A
General Electric IS420UCSCH1A-G-V0.1-A
General Electric IS420UCSCH1A-G-V0.1-A
General Electric IS420UCSCH1A-G-V0.1-A
General Electric IS420UCSCH1A-G-V0.1-A
General Electric IS420UCSCH1A-G-V0.1-A
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail sales1@apterpower.com
  • Lifecycle status

    Active / Available from OEM
    Apter Power provides configuration review, technical documents, quotation, and sourcing guidance.

IS420UCSCH1A-G-V0.1-A

/ 4.9
1001 reviews | Need a Specific Revision?
GE Vernova IS420UCSCH1A-G-V0.1-A is a Mark VIe UCSC controller configuration based on the IS420UCSCH1A four-core 1.2 GHz platform with six 100 Mb Ethernet ports.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for IS420UCSCH1A-G-V0.1-A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS420UCSCH1A-G-V0.1-A

  • Manufacturer:
    General Electric
  • Part Number:
    IS420UCSCH1A-G-V0.1-A
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    UCSE controller
  • Stock:
    1
  • Processor:
    AMD GX-412HC, 1.2 GHz, 4 cores
  • Memory:
    4 GB DDR3-1333
  • Storage:
    40 GB solid-state drive
  • Ethernet Ports:
    6 × 100 Mb
  • Console Port:
    RJ45
  • USB Ports:
    2 × USB 2.0
  • Input Voltage:
    18 to 30 VDC
  • Maximum Power:
    31 W
  • Operating Temperature:
    -40 to 70 °C
  • Relative Humidity:
    95%, non-condensing
  • Weight:
    2.93 lbs (1.327 kg)
  • Estimated shipping dimensions:
    5.5 x 15.0 x 16.8 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Performance Configuration

Features:

  • Uses a four-core 1.2 GHz processor.
  • Provides six 100 Mb Ethernet ports.
  • Includes 4 GB DDR3 memory and a 40 GB solid-state drive.
The current ordering configuration is IS420UCSCH1A-G-V0.1-A, a Mark VIe UCSC controller based on the documented H1A platform.

It executes the assigned Mark VIe controller application and exchanges control-network data through six Ethernet interfaces.

Before installation, verify the complete suffix, software image, network addresses, cabinet wiring, DC power, and environmental limits.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for GE Vernova IS420UCSCH1A-G-V0.1-A: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

General

  • ManufacturerGE Vernova
  • ModelIS420UCSCH1A-G-V0.1-A
  • ConditionNew Original ready stock
  • Product FamilyMark VIe UCSE
  • Execute a compatible Mark VIe control application.
  • Connect the controller to the assigned control-network topology.
  • Replace an exact UCSC configuration after software and suffix verification.
  • The AMD GX-412HC processor operates at 1.2 GHz with four cores.
  • The platform provides 4 GB DDR3-1333 memory.
  • The platform uses a 40 GB solid-state drive.
  • Preserve the approved Mark VIe application image before replacement.
  • Record all six Ethernet assignments before disconnecting the controller.
  • Verify the RJ45 console and two USB service connections for the installed configuration.
Description
GE Vernova IS420UCSCH1A-G-V0.1-A is a Mark VIe UCSC controller configuration built on the IS420UCSCH1A platform with a four-core 1.2 GHz processor, 4 GB DDR3 memory, and a 40 GB solid-state drive.

Six 100 Mb Ethernet ports support control-network connections. Confirm the complete suffix, application image, network assignment, and 18-30 VDC supply before replacement.
Revisions

Revision Part #

Also known as

IS420UCSCH1B
GE Vernova IS420UCSCH1B, UCSC H1B Controller
IS420UCSCH1C
GE Vernova IS420UCSCH1C, UCSC H1C Controller
Alternative Names
IS420UCSCH1A-G-V0.1-A IS420UCSCH1A G V0.1 A IS420UCSCH1AGV01A GE IS420UCSCH1A-G-V0.1-A GE Vernova IS420UCSCH1A-G-V0.1-A GE Mark VIe UCSC Controller IS420UCSCH1A-G-V0.1-A
Technical notes
Match the complete IS420UCSCH1A-G-V0.1-A suffix, Mark VIe software image, network assignment, and DC supply.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What processor platform is used by IS420UCSCH1A-G-V0.1-A?
The documented IS420UCSCH1A platform uses a 1.2 GHz AMD GX-412HC four-core processor.
How many Ethernet ports are available?
The hardware platform provides six 100 Mb Ethernet ports.
What DC input range is required?
The controller accepts 18 to 30 VDC, with 24/28 VDC nominal operation.
What memory and storage are provided?
The documented platform includes 4 GB DDR3 memory and a 40 GB solid-state drive.
What must be matched when replacing this controller?
Match the complete suffix, Mark VIe application image, network assignments, software compatibility, and cabinet wiring.
Which dimensions and mass apply to this configuration?
The official platform data lists a 55 × 150 × 168 mm chassis and a mass of 1,327 g.
