IS420YDOAS1B

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IS420YDOAS1B is an active Mark VIeS discrete output I/O pack for approved relay terminal-board assemblies.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IS420YDOAS1B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS420YDOAS1B

  • Manufacturer:
    General Electric
  • Part Number:
    IS420YDOAS1B
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    Mark VIeS Discrete Output I/O Pack
  • Stock:
    1
  • I/O Function:
    Discrete output
  • Output Channels:
    12 relay outputs, subject to the selected terminal board
  • Listed Terminal Boards:
    IS410TRLYS1B, IS410TRLYS1D, IS410TRLYS1F, and IS410TRLYS2F
  • DC Control Supply:
    24/28 V DC
  • Maximum DC Control Power:
    19.8 W including relay coils
  • DC Connector:
    Micro Mate-N-Lok
  • Enclosure:
    Aluminum case
  • Diagnostics:
    Status LEDs and health variables
  • Operating Temperature:
    -40 to +70 °C
  • Storage Temperature:
    -40 to +85 °C
  • Mounting Boundary:
    Installed with its approved DIN-rail terminal-board assembly
  • Weight:
    0.34 kg
  • Estimated shipping dimensions:
    5.7x12.2x8.3cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Output Channels Terminal Boards Ordering Review

Features:

  • Discrete output role: The pack interfaces Mark VIeS control with relay terminal-board outputs.
  • Approved board combinations: GE documents specific TRLY terminal-board variants.
  • Industrial temperature range: The official operating range is -40 to +70 °C.

IS420YDOAS1B processes discrete output commands and reports pack and output health through the Mark VIeS I/O architecture.

The relay hardware is defined by the connected terminal board, so the I/O pack must not be reviewed independently from that assembly.

Procurement should preserve the terminal-board article, relay-load schedule, DC supply record, pack revision, and controller configuration.

Availability is subject to Apter Power's current inventory and sourcing confirmation.

General Electric IS420YDOAS1B Mark VIeS Discrete Output I/O Pack Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

General Electric IS420YDOAS1B Mark VIeS Discrete Output I/O Pack Specs

General

  • ManufacturerGeneral Electric
  • ModelIS420YDOAS1B
  • ConditionNew and factory sealed
  • Product FamilyMark VIeS Discrete Output I/O Packs

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Discrete output planning

  • Channel scope: Plan the twelve documented relay outputs.
  • Relay boundary: Relay type and circuit behavior depend on the selected terminal board.
  • Health data: Use the documented LEDs and health variables during controlled testing.
  • Load record: Retain the approved relay-load and protection schedule.

Approved termination review

  • S1B: Use only where the official Mark VIeS table lists IS410TRLYS1B.
  • S1D: Confirm the IS410TRLYS1D circuit arrangement before matching.
  • S1F and S2F: Verify the exact board suffix and relay configuration.
  • Assembly check: Match the pack and terminal board as one documented I/O assembly.

Identity and project checks

  • Pack identity: Confirm IS420YDOAS1B on the supplied unit.
  • DC supply: Verify the documented 24/28 V DC control source.
  • Revision record: Preserve the installed hardware revision and controller configuration.
  • Terminal board: Quote the complete TRLY model with the I/O pack request.
Description

The General Electric IS420YDOAS1B is a Mark VIeS discrete output I/O pack for approved relay terminal-board assemblies.

Official documentation for IS420YDOAS1B specifies 24/28 V DC control power, a Micro Mate-N-Lok DC connector, status diagnostics, and operation from -40 to +70 °C.

Before ordering IS420YDOAS1B, verify the exact relay terminal board, output circuit requirements, installed pack revision, and complete Mark VIeS hardware record.

Revisions

Revision Part #

Also known as

IS420YDOAS1A
IS420YDOAS1-A, Series A, Rev A
Alternative Names
General Electric IS420YDOAS1B GE IS420YDOAS1B IS420YDOAS1B IS420 YDOA S1B IS420YDOA S1B GE Vernova IS420YDOAS1B IS420YDOAS1B Discrete Output I/O Pack Mark VIeS YDOA I/O Pack
Technical notes
GE IS420YDOAS1B is a Mark VIeS discrete output I/O pack used with specified relay terminal boards. Verify the exact terminal-board assembly, relay configuration, DC control supply, and complete pack label.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is GE IS420YDOAS1B used for?
It is a Mark VIeS discrete output I/O pack used with approved relay terminal boards. Verify the complete I/O assembly before ordering.
Which product family includes IS420YDOAS1B?
It belongs to GE Mark VIeS distributed I/O. The terminal-board suffix determines the connected relay hardware.
Which terminal boards are listed for IS420YDOAS1B?
GE lists IS410TRLYS1B, IS410TRLYS1D, IS410TRLYS1F, and IS410TRLYS2F in the reviewed table. Confirm the exact board-specific configuration.
How do I verify the correct IS420YDOAS1B?
Check the full pack label, hardware revision, TRLY terminal-board model, relay loads, DC supply, and controller configuration.
Is IS420YDOAS1B active or discontinued?
The official GE Vernova lifecycle table identifies IS420YDOAS1B as active. Supply and lead time still require sourcing confirmation.
Is there an official replacement for IS420YDOAS1B?
No direct replacement is claimed on this page. Use GE documentation and an engineering review for any proposed change.
Where can I get IS420YDOAS1B documentation and pricing?
Open the verified PDF in Manuals, then send Apter Power the terminal-board model, quantity, destination, condition, and required date.
