IC200UDR005-CH

/ 4.9
1001 reviews | Need a Specific Revision?
The GE IC200UDR005-CH is a VersaMax 28-point Micro PLC with sixteen 24 VDC inputs, one 24 VDC output, eleven relay outputs, and a 120/240 VAC power supply.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for IC200UDR005-CH
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200UDR005-CH

  • Manufacturer:
    General Electric
  • Part Number:
    IC200UDR005-CH
  • Product Family:
    GE VersaMax
  • Product Type:
    VersaMax Micro 28-Point PLC
  • Stock:
    1
  • Built-in I/O:
    28 points
  • DC Inputs:
    Sixteen 24 VDC positive/negative logic input circuits
  • Relay Outputs:
    Eleven normally open 2 A relay circuits
  • DC Output:
    One 24 VDC output, Q1
  • AC Power Range:
    100 VAC -15% to 240 VAC +10%
  • High-Speed Counters:
    Up to four Type A or one Type A and one Type B
  • +24 VDC Field Power:
    200 mA maximum for input circuits and user devices
  • AC Input Frequency:
    50 Hz -5% to 60 Hz +5%
  • Weight:
    0.58 kg
  • Estimated shipping dimensions:
    150 x 90 x 76 mm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications I/O Resources Counters Serial Ports

Features:

  • Twenty-eight integrated control points
  • Eleven normally open 2 A relay outputs
  • 100 to 240 VAC nominal operating power
The IC200UDR005-CH identifies a hardware revision of the IC200UDR005 VersaMax Micro configuration.

The controller combines CPU, discrete I/O, field-power output, high-speed functions, and serial communication in a 150 mm-wide enclosure.

Compare the complete suffix, terminal wiring, project file, expansion arrangement, and AC supply before replacing a CH-marked unit with another revision.

The GE IC200UDR005-CH VersaMax 28-Point Micro PLC is listed as Active / Available from OEM. Contact Apter Power for quotation, documentation, and revision review.
GE IC200UDR005-CH VersaMax 28-Point Micro PLC Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
GE IC200UDR005-CH VersaMax 28-Point Micro PLC Specs

General

  • Manufacturer GE
  • Model IC200UDR005-CH
  • Condition New and Original
  • Product Family VersaMax Micro

Integrated point allocation

  • DC inputs: Sixteen inputs accept documented 24 VDC positive- or negative-logic signals.
  • Relay outputs: Eleven normally open relay circuits switch external AC or DC loads.
  • Q1 output: The single DC output can perform standard or selected high-speed functions.
  • Field supply: The controller provides up to 200 mA of 24 VDC for inputs and user devices.

Built-in high-speed functions

  • Type A: The input section can provide as many as four independent Type A counters.
  • Type B: One Type A and one quadrature Type B counter may be configured together.
  • Pulse output: Q1 supports pulse-train or PWM operation when configured in the project.
  • Relay limit: Relay outputs can support counter output duties but not pulse-train or PWM modes.

Controller communication setup

  • Port 1: The first serial interface supports programming and documented serial services.
  • Port 2: The second interface supports RS-485 network operation for configured devices.
  • Network limit: The manual specifies up to eight slave devices before using a repeater.
  • Configuration: Match port mode, baud rate, cabling, and protocol to the existing PLC project.
Description
The IC200UDR005-CH is a 28-point VersaMax Micro PLC built around the IC200UDR005 hardware configuration. It combines sixteen configurable 24 VDC inputs, eleven normally open 2 A relay outputs, one 24 VDC output, and a 100 to 240 VAC nominal operating supply in one compact controller.

Inputs on the IC200UDR005-CH can operate as positive or negative logic standard points, and selected inputs support up to four Type A high-speed counters or one Type A plus one Type B counter. The controller also supplies up to 200 mA of 24 VDC field power for input circuits and user devices.

The Q1 circuit of the IC200UDR005-CH can be configured as a standard output, high-speed counter output, pulse train, or PWM output. Relay circuits Q2-Q12 switch external AC or DC field loads and require a suitable external source for the connected devices.

The IC200UDR005-CH measures 150 mm wide, 90 mm high, and 76 mm deep, with an official weight of 580 g. When comparing the CH and DJ hardware markings, use the full nameplate suffix, controller power arrangement, terminal layout, and project configuration rather than assuming revision interchangeability.
Revisions

Revision Part #

Also known as

IC200UDR005-DJ
IC200UDR005DJ, Series DJ, Rev DJ
Alternative Names
General Electric IC200UDR005-CH IC200UDR005 CH IC200UDR005CH GE IC200UDR005-CH GE Fanuc IC200UDR005-CH Emerson IC200UDR005-CH VersaMax IC200UDR005-CH IC200 UDR005 CH
Technical notes
The GE IC200UDR005-CH is a 28-point VersaMax Micro PLC with sixteen 24 VDC inputs, eleven relay outputs, one DC output, and 120/240 VAC power.
