        HIMA F60CPU03
        HIMA F60CPU03
        HIMA F60CPU03
        HIMA F60CPU03
        HIMA F60CPU03
        HIMA F60CPU03
        Ask our team:
        • Phone: +86 181 0690 9650
        • E-Mail sales1@apterpower.com

        • Lifecycle Status

          Active / Available
          Apter Power distributes certified HIMA safety system components, ensuring dependable processor hardware solutions for mission-critical industrial environments.

        F60CPU03

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The HIMA F60CPU03 (CPU 03) is the core central processing module for the HIMatrix F60 safety control system. It is responsible for executing user programs, system monitoring, and communication functions, and is suitable for high-reliability safety automation applications.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for F60CPU03
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for F60CPU03

        • Manufacturer:
          HIMA
        • Part Number:
          F60CPU03
        • Product Family:
          HIMA HIMatrix system
        • Product Type:
          Processing Module
        • Stock:
          1
        • Total program and data memory for all application programs:
          5 MB less 64 kBytes for CRCs
        • Response time:
          ≥ 6 ms
        • Ethernet interfaces:
          4 x RJ-45, 10/100BaseT (at 100 Mbit/s) with integrated switch.
        • Fieldbus Interfaces:
          2 x 9-pole D-sub; FB1 and FB2 with fieldbus submodule pluggable.
        • Operating Voltage:
          24 VDC, -15 %...+20 %, rPP ≤ 15 %, provided by a power supply unit with safe isolation in accordance with IEC 61131-2 requirements.
        • Operating data:
          3.3 VDC / 1.5 A; 5 VDC / 0.1 A.
        • Buffer for date/time:
          Gold capacitor
        • Ambient temperature:
          0 °C...+60 °C
        • Storage temperature:
          -40 °C...+85
        • Space requirement:
          6 RU, 4 HP
        • Certified:
          CE, TÜV, PROFIBUS Nutzerorganisation (PNO).
        • Weight:
          1 kg
        • Estimated shipping dimensions:
          10x5x9cm
        • Tariff Code:
          8537101190
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Key Function Installation Application

        Features:

        • High-Reliability Safety Processing Core
        • Flexible Communication with Multiple Ethernet and Fieldbus Interfaces
        • Advanced Diagnostics and Continuous Self-Monitoring Functions
        The HIMA F60CPU03 is a central processing module designed specifically for safety-critical industrial control systems, serving as the core control unit in the HIMatrix F60 system. It not only executes user programs but also handles the overall system logic coordination and communication management. Through its integrated multi-interface design, the F60CPU03 can easily connect to automation equipment at different levels. Its multitasking capabilities enable the system to run multiple control logics simultaneously, improving overall efficiency. This capability is particularly critical in complex industrial environments. The F60CPU03's design emphasizes stability and safety, making it a core component of highly reliable systems.

        In terms of functionality, the F60CPU03 combines high-speed response with abundant communication resources, supporting flexible deployment in industrial networks. Four Ethernet interfaces with integrated switching functionality reduce the need for additional network equipment. Simultaneously, dual fieldbus interfaces support modular expansion, allowing the system to adapt to different field protocol requirements. Users can efficiently configure and maintain the F60CPU03 using the SILworX tool. This module also supports Sequence of Events (SOE), assisting engineers in fault analysis and system optimization. Overall, the F60CPU03 provides a highly integrated control solution.

        In industrial applications, the F60CPU03 is widely used in process control, safety interlocking systems, and critical equipment protection scenarios. Its robust self-testing mechanism and operational monitoring functions significantly enhance system safety. The module continuously monitors CPU cycles, I/O signal processing, and system status, enabling real-time fault detection. Combined with its wide temperature range and stable power supply design, the F60CPU03 maintains reliable operation in harsh environments. For industries requiring high availability and safety certifications, such as energy, chemical, and manufacturing, this module provides a reliable solution.

        The F60CPU03 HIMA Processing Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        HIMA F60CPU03 Processing Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        HIMA F60CPU03 Processing Module Specs

        General

        • Manufacturer HIMA
        • Model F60CPU03
        • Condition New Original ready stock
        • Product Family F60CPU01,F60GEH01,F60AO801
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Safety Level (SIL 3 / PL e): Compliant with IEC 61508 (SIL 3) and EN ISO 13849-1 (PL e) standards, specifically designed for critical safety tasks.
        • Multi-protocol Communication: Integrated Ethernet interface, supporting multiple industrial protocols including safeethernet (HIMA patent), PROFINET IO, PROFIsafe, and Modbus TCP.
        • High-Performance Computing: Compared to the earlier CPU 01, CPU 03 boasts faster logic processing speed and larger memory capacity, supporting more complex process flows.
        • Redundancy and Diagnostics: Internally designed with redundancy, featuring robust self-diagnostic capabilities, enabling real-time monitoring of CPU voltage, temperature, and the operating status of each module.
        • Slot Positioning: In the F60 subrack, typically installed in Slot 2 (Slot 1 is usually the power module PS 01).
        • Configuration Software: Logic development, hardware configuration, and online enforcement must be performed using SILworX programming software.
        • Indicator Light System: The panel integrates multiple LED indicators to clearly display Run, Error, Stop, and network connection status.
        • Physical Interface: Provides a dedicated Reset button and an RJ45 Ethernet port for local debugging and network connectivity.
        • Petrochemical Industry (ESD System): As an emergency shutdown system, it immediately shuts off valves upon detecting abnormal pressure or liquid level to prevent explosions or leaks.
        • Power Energy (BMS System): Used for boiler burner management, monitoring flame status, and controlling fuel ignition/cutoff processes.
        • Rail Transit (Signaling): Used for station platform screen door control, switch machine monitoring, or Automatic Train Protection (ATP) systems.
        • Fire and Gas (F&G System): Connects to smoke and combustible gas detectors and automatically activates audible and visual alarms or fire sprinkler systems.
        Description
        The HIMA F60CPU03 is a core component of the HIMatrix F60 controller, specifically designed for safety-related applications. As the central processing unit, the F60CPU03 stores the operating system and user programs and executes all critical control tasks, including system logic processing, communication management, and operational status monitoring. This module can only be installed in a dedicated slot to the right of the power supply module in the subrack to ensure the safety and consistency of the system architecture.

        In terms of performance, the F60CPU03 provides 5 MB of program and data storage space (effective capacity after deducting CRC checksum) and has a response time of ≥6 ms, meeting the demands of rapid control. The module is equipped with four Ethernet interfaces (RJ-45, 10/100BaseT, with integrated switching function) and two pluggable fieldbus interfaces (9-pin D-sub), supporting flexible industrial communication architectures. Through the F60CPU03, the system can achieve efficient data exchange with PADT and other control systems.

        In terms of reliability design, the F60CPU03 incorporates a multi-layered safety monitoring mechanism, including CPU hardware and software self-tests, runtime monitoring (including user programs), I/O testing, and signal processing verification. The module also continuously monitors the supply voltage and operating temperature to ensure timely response in abnormal situations. Its safety functions meet industrial safety control requirements and are suitable for mission-critical systems.

        The F60CPU03 has strong environmental adaptability, supporting 24 VDC power supplies (-15% to +20%) and meeting the safety isolation requirements of the IEC 61131-2 standard. Operating within a temperature range of 0°C to +60°C and a storage temperature range of -40°C to +85°C, this module is suitable for various industrial environments. Furthermore, an integrated gold capacitor serves as a time buffer, ensuring data retention during power outages.

        As part of the HIMatrix F60 series, the HIMA F60CPU03 supports multitasking, online reload, and SOE (Sequence of Events) functionality, giving it significant advantages in process industries, safety interlocking systems, and high-reliability control scenarios. The SILworX programming tool allows users to efficiently configure the system and develop safety logic.
        Alternative Names
        F60GEH01 F60DO2401 F60AI801 F60AO801 F60MI2401 F60CPU01 F60 CPU 03 F6OCPUO3
        Technical notes
        The HIMA F60CPU03 is a central processing module designed for the HIMA F60 programmable electronic system (PES), a safety-related controller widely used in high-integrity applications such as emergency shutdown (ESD), fire and gas (F&G), and burner management systems (BMS).
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What is the main function of the F60CPU03 module?
        The F60CPU03 acts as the central processor of the HIMatrix F60 system, executing user programs and managing communication.
        How does F60CPU03 handle communication?
        The F60CPU03 uses four Ethernet ports and two fieldbus interfaces for system integration. It supports communication with PADT and other automation systems.
        What operating conditions does F60CPU03 support?
        The F60CPU03 operates at 24 VDC with a wide tolerance and supports 0°C to +60°C environments.
        How does F60CPU03 ensure time accuracy?
        The F60CPU03 uses a gold capacitor to buffer date and time.
