F8652X

/ 4.9
1001 reviews | Need a Specific Revision?
HIMA F8652X is identified in HIMA certification material as the central module for the H41q safety-controller family, with T-code T4.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for F8652X
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for F8652X

  • Manufacturer:
    HIMA
  • Part Number:
    F8652X
  • Product Family:
    HIMA HIQuad H41q/H51q
  • Product Type:
    Safety-related central module for H41q
  • Stock:
    1
  • T-code:
    T4
  • Revision:
    01
  • HIMA report:
    968/FSP 1254.00/16
  • Revision-list status:
    valid
  • Nonincendive input Vmax:
    15 V
  • Nonincendive input Imax:
    500 mA
  • Nonincendive input Ci:
    0
  • Nonincendive input Li:
    0
  • Nonincendive output Voc:
    6 V
  • Nonincendive output Isc:
    500 mA
  • Groups A/B:
    Ca 1 µF; La 0.15 mH
  • Groups C/D:
    Ca 2 µF; La 0.5 mH
  • Dimensions:
    4 x 18.5 x 12.8 cm
  • Weight:
    0.3 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals H41q identity Certification boundary Replacement checks Application
  • HIMA central module for H41q-MS, H41q-HS, and H41q-HRS systems
  • F8652X is listed with a T4 temperature-code classification
  • Revision 01 is identified as valid in the H41q/H51q TÜV revision list

HIMA F8652X is an H41q central module documented for the H41q-MS, H41q-HS, and H41q-HRS automation-system variants.

The official FM certificate lists F8652X as an H41q central module with a T4 classification. The TÜV revision list identifies hardware revision 01 under report 968/FSP 1254.00/16 with valid status.

Before replacement, confirm the H41q system variant, module revision, rack position, approved firmware and application configuration. Do not substitute the H51q F8650X solely because it belongs to the same module family.

Availability, condition, price, and shipping time for HIMA F8652X are confirmed during quotation.

HIMA F8652X H41q Central Module Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • HIMA identifies F8652X as a central module for the H41q controller family
  • Documented system variants: H41q-MS, H41q-HS, and H41q-HRS
  • FM certificate temperature-code classification: T4
  • TÜV report reference: 968/FSP 1254.00/16
  • F8652X hardware revision 01 is listed with valid status
  • The certification record confirms approval context but does not replace the applicable H41q installation manual
  • Match the installed H41q-MS, H41q-HS, or H41q-HRS system variant
  • Verify the approved safety configuration, hardware revision, firmware, and application program
  • Confirm electrical, interface, rack-position, and installation requirements from the applicable HIMA manual
  • Central processing within HIMA H41q safety-controller systems
  • Service applications for H41q-MS, H41q-HS, and H41q-HRS configurations
  • Replacement planning for a matching F8652X hardware revision and approved system configuration
Description
HIMA F8652X is identified by the HIMA Certificate of Conformity as the T4 Central Module [H41q] execution, making the exact controller family and certificate scope central to correct selection.

The associated HIMA revision record covers the H41q-MS, H41q-HS and H41q-HRS contexts at revision 01 under report 968/FSP 1254.00/16, while the certificate defines the safety-wiring conditions that govern an approved installation.

For replacement, reconcile the nameplate, safety project, revision record, wiring-group calculation and cabinet position before energizing; the listing dimensions and weight are maintained as supplied attributes and are not used to infer additional HIMA specifications.
Alternative Names
F8652X HIMA F8652X H41q F8652X F8652X central module H41q-MS F8652X F8652X T-code T4
Technical notes
F8652X must be matched to the H41q variant, T4 certificate, revision 01, report 968/FSP 1254.00/16 and applicable wiring-group limits before replacement; certificate scope and installed safety configuration remain the key risks.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can a buyer confirm that HIMA F8652X matches the installed H41q safety controller?
Compare the complete nameplate, T-code, controller variant and approved safety project with the HIMA certificate before accepting the module as a replacement.
What documentation should be checked before replacing HIMA F8652X in a safety system?
Review the certificate, revision list, report reference, safety requirements specification, cabinet drawings, wiring calculations and maintenance procedure for the exact installed H41q execution.
How should a technician assess whether HIMA F8652X wiring is compatible with the existing safety cabinet?
Recheck the certified wiring-group calculation, field-device entity parameters, terminal assignment, segregation and approved barriers against the installed project; do not infer safety compatibility from the connector or dimensions alone.
What should be done before removing HIMA F8652X from an operating safety system?
Obtain the approved maintenance permit, place the system in its defined safe state, back up the safety configuration, record wiring and diagnostics, and preserve the original revision evidence for rollback.
What commissioning checks are important after installing HIMA F8652X?
Confirm the module identity and revision, inspect wiring and barriers, run the approved diagnostics and proof-test procedure, verify the safety logic, and record sign-off in the maintenance documentation.
Can HIMA F8652X be selected from the supplied dimensions alone?
No. Match the H41q variant, T-code, revision, certificate report, safety wiring limits, cabinet position and project configuration before replacement.
What commissioning evidence should be retained for HIMA F8652X?
Keep the certificate and revision-list references, nameplate photograph, wiring-group calculation, insulation/loop checks, revision confirmation, startup diagnostics and approved safety validation record.
