    Apter Power can quote F3430 and provide the matched two-page technical document.

F3430

/ 4.9
1001 reviews | Need a Specific Revision?
HIMA F3430 is a four-fold safety-related relay module with safe isolation, integrated shutdown and four normally open output contacts. It is specified for controlled switching within documented safety circuits.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for F3430
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for F3430

  • Manufacturer:
    HIMA
  • Part Number:
    F3430
  • Product Family:
    HIMA HIQuad H41q/H51q
  • Stock:
    1
  • Switching Voltage:
    5 to 250 V AC; 5 to 110 V DC
  • Switching Current:
    10 mA to 4 A
  • Relay Outputs:
    4 normally open, dust-tight contacts
  • Contact Material:
    Silver alloy, gold-flashed
  • Switching Time:
    Approx. 8 ms
  • Reset Time:
    Approx. 6 ms
  • Bounce Time:
    Approx. 1 ms
  • Mechanical Life:
    ≥ 30 × 10⁶ switching operations
  • Electrical Life:
    ≥ 2.5 × 10⁵ operations at full resistive load and ≤ 0.1 operations/s
  • AC Switching Capacity:
    Max. 500 VA at cos φ > 0.5
  • DC Switching Capacity:
    120 W to 30 V; 50 W to 70 V; 30 W to 110 V
  • Space Requirement:
    4 TE
  • Operating Current at 5 V DC:
    < 100 mA
  • Operating Current at 24 V DC:
    < 120 mA
  • Safety-Control Output Fuse:
    Max. 2.5 A
  • Safety Integrity Level:
    SIL 3
  • Safety Application Profiles:
    ESD and ProtecS
  • Supported HIMA Systems:
    H41, H51, H41q, and H51q
  • Valid Certified Revisions:
    01 and 02
  • FM Hazardous-Location Classification:
    NI/I/2/ABCD; T4, Ta = 60 °C
  • EN ISO 13849-1 Status:
    Not certified
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    2x19x12.7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Diagnostics & Protection Safety & Compliance Performance & Efficiency

Features:

  • Provides four safety-related relay output channels.
  • Uses three series relays with diversity and an integrated safety shutdown.
  • Includes safe isolation between the input circuitry and output contacts.
The F3430 ordering identity designates a four-fold relay module for safety-related control duties, with dust-tight normally open contacts.

Its relay stage switches field loads while a solid-state open-collector output can drive the LED indication in the cable plug.

For safety-control use, protect each output circuit with no more than the documented 2.5 A fuse and verify the Z 7149 / 3430 / C cable-plug wiring before energization.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for HIMA F3430: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Switches safety-related field loads from a four-channel relay output stage.
  • Supports shutdown and interlock circuits that require isolated normally open contacts.
  • Provides contact outputs for valves, alarms and other resistive control loads within the stated ratings.
  • Integrated safety shutdown uses three series relays with diverse construction.
  • A cable-plug LED can be driven by the dedicated open-collector indication output.
  • Safety-control output circuits may be fused at a maximum of 2.5 A.
  • Safe input-to-contact isolation follows EN 50178 requirements.
  • Clearance and creepage distances are designed for overvoltage category III up to 300 V.
  • The documented requirement class covers AK 1 through AK 6 applications.
  • Typical switching time is approximately 8 ms with a reset time near 6 ms.
  • Contact bounce is approximately 1 ms under the documented operating conditions.
  • Mechanical life is rated at no less than 30 million switching operations.
Description
The HIMA F3430 Relay Module is a compact and efficient component designed for industrial automation and safety systems. This module is engineered to control and manage relay functions, ensuring reliable switching operations in critical environments.

Its robust construction and adherence to industrial safety standards make it an ideal choice for applications requiring precise control and dependable performance. Lightweight and easy to install, the F3430 provides exceptional functionality while minimizing system complexity.
Alternative Names
F3430 HIMA F3430 F 3430 F-3430 HIMA F 3430 HIMA F3430 Relay Module HIMA F3430 4-Fold Relay Module HIMA F3430 Safety-Related Relay Module
Technical notes
For safety-control service, HIMA F3430 output circuits must be fused at no more than 2.5 A, and the Z 7149 / 3430 / C plug wiring must be verified before restart.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is a 2.5 A fuse limit important for HIMA F3430 safety outputs?
The official sheet limits output-circuit fusing to 2.5 A when the module is used in safety controls.
How does HIMA F3430 build diversity into each safety relay channel?
Each channel uses three series relays with diverse construction together with an integrated safety shutdown.
What indication function is available through the HIMA F3430 cable plug?
A solid-state open-collector output can drive the LED display in the designated cable plug.
Which insulation boundary applies to HIMA F3430 installation?
The module provides safe input-to-contact isolation to EN 50178, with spacing designed for overvoltage category III up to 300 V.
How should HIMA F3430 service-life data influence maintenance planning?
Compare operating duty with the documented mechanical and electrical switching-life figures instead of judging wear by age alone.
What should accompany an inquiry for HIMA F3430 replacement stock?
Provide the F3430 label, cable-plug reference, load details and photographs so the four-channel configuration can be checked.
