51403626-200

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell 51403626-200 is an IDE drive storage card designed for stable system data handling with dual supply input support. It operates with industrial-grade electrical compatibility and reliable read/write performance in control environments.
Get a quick price for 51403626-200
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 51403626-200

  • Manufacturer:
    Honeywell
  • Part Number:
    51403626-200
  • Product Family:
    Honeywell DCS
  • Product Type:
    IDE Drive Storage Card
  • Supply Voltage:
    +5V DC ±5% / +12V DC ±10%
  • Power Consumption:
    Maximum 5.0 Watts (Active read/write mode)
  • Standby Power:
    Approximately 1.2 Watts (Idle state)
  • Input Current:
    0.5A @ 5V (Typical) / 0.2A @ 12V (Typical)
  • Logic Level:
    3.3V LVTTL / 5V TTL Compatible
  • Data Bus Width:
    16-bit Parallel ATA
  • Operating Temperature:
    0°C to +60°C (32°F to 140°F)
  • Storage Temperature:
    -40°C to +85°C (-40°F to 185°F)
  • Relative Humidity:
    5% to 95% RH (Non-condensing)
  • Weight:
    2.58 kg
  • Estimated shipping dimensions:
    20x27x10.5cm
  • Tariff Code:
    8302420000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Upgrade Use Cases Environmental Monitoring

Features:

  • Dual-voltage power architecture supporting stable integration in industrial control systems
  • Optimized energy consumption with distinct active and idle power modes
  • Industrial-grade electrical protection and wide environmental tolerance range
Honeywell 51403626-200 is an IDE drive storage card designed for industrial data handling environments where stable storage performance is required. The Honeywell 51403626-200 supports a dual supply input structure, enabling flexible deployment across different control systems. With a 16-bit Parallel ATA interface, the Honeywell 51403626-200 ensures consistent communication between storage and processing units. The design focuses on stable operation under continuous industrial workload conditions. It is suitable for applications requiring reliable embedded storage functionality.

The Honeywell 51403626-200 operates with efficient power management, consuming up to 5.0 watts during active operations and reducing consumption in idle state. This allows the Honeywell 51403626-200 to maintain balanced energy usage in long-term operation scenarios. Its logic compatibility with both 3.3V LVTTL and 5V TTL enhances system integration flexibility. The Honeywell 51403626-200 is structured to support dependable signal handling across industrial computing platforms. It contributes to stable system performance in data-critical environments.

Designed with environmental resilience in mind, Honeywell 51403626-200 operates within a temperature range from 0°C to +60°C and withstands storage conditions from -40°C to +85°C. The Honeywell 51403626-200 also supports humidity levels between 5% and 95% RH non-condensing, making it adaptable to varied industrial sites. With built-in ESD protection up to 4 kV, the Honeywell 51403626-200 enhances system durability under electrical stress conditions. Its structural design supports consistent operation in demanding environments. This makes the Honeywell 51403626-200 suitable for long-term industrial storage applications.

The 51403626-200 Honeywell IDE Drive Storage Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 51403626-200 IDE Drive Storage Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell 51403626-200 IDE Drive Storage Card Specs

General

  • Manufacturer Honeywell
  • Model 51403626-200
  • Condition New Original ready stock
  • Product Family 51403698-100,51403645-100,51403645-400
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Firmware Version Compatibility: Supports a smooth transition of the software architecture for older Honeywell TDC 3000 system storage devices, ensuring real-time operation without altering existing operational logic.
  • Maintenance-Free Solid-State Architecture: Utilizes non-mechanical flash memory instead of traditional magnetic media, completely eliminating the risks of head wear and motor failure, ensuring the continuous and stable operation of the control system.
  • High-Speed ​​Data Read/Write: Significantly optimizes data throughput efficiency during startup, heavy load, and batch processing of the control module, shortening system boot and policy loading wait times.
  • Online Hot-Swapping Support: Allows maintenance without interrupting the overall operation of the control network in spare slots or redundant configurations, ensuring continuous production.
  • Historical module data storage: Used as the core medium in Honeywell Historical Modules (HM) or Application Modules (AM) to store long-term process trends, event logs, and historical control data.
  • Control file backup and recovery: Configuration policies of storage node processors and Advanced Process Manager (APM), CL compilation scripts, and system boot image files enable rapid recovery in emergency situations.
  • Modern upgrade for replacing legacy storage devices: Specifically designed to replace discontinued and easily damaged traditional IDE hard drives or tape drives in TDC 3000 systems, achieving low-cost hardware life extension for the system.
  • Multi-node configuration parameter distribution: Utilizing its IDE standard interface and universal read/write capabilities, this feature enables offline transmission and distribution of large-scale engineering configuration data between offline engineering workstations and Online Local Control Network (LCN) nodes.
  • Harsh Industrial Environment Adaptability: Designed for the high-frequency vibration, strong electromagnetic interference, and dusty environments inside industrial control cabinets, providing physical resilience far exceeding that of standard commercial hard drives.
  • Stable Operation Over a Wide Temperature Range: Maintains stable electrical performance under normal and extreme temperature fluctuations in industrial environments, preventing storage sector loss due to ambient temperature.
  • Self-monitoring of health status: Supports continuous tracking of memory card health by the main control system, and timely alerts to abnormal wear and tear of memory cards through the DCS system alarm mechanism.
  • Low power consumption: Solid-state cards have lower heat generation and energy consumption, effectively reducing the heat dissipation pressure inside the enclosed controller chassis and improving the environmental friendliness of the entire system.
Description
Honeywell 51403626-200 is an IDE drive storage card engineered for use in industrial computing systems requiring stable data storage and retrieval performance. It supports a dual power input configuration of +5V DC ±5% and +12V DC ±10%, allowing flexible integration into existing hardware architectures. The unit is designed with a 16-bit Parallel ATA data bus structure to ensure consistent data transfer between system components.

In operational mode, Honeywell 51403626-200 maintains a maximum power consumption of 5.0 watts during active read/write cycles, while reducing to approximately 1.2 watts in idle state for improved energy efficiency. Typical input current values are 0.5A at 5V and 0.2A at 12V, reflecting its balanced electrical design for stable operation. The logic interface is compatible with both 3.3V LVTTL and 5V TTL standards, supporting broader system compatibility.

The Honeywell 51403626-200 is also designed with protective and environmental tolerance features, including ESD protection up to 4 kV according to IEC 61000-4-2 standards. It operates reliably within a temperature range of 0°C to +60°C and can be stored between -40°C and +85°C. With humidity tolerance from 5% to 95% RH (non-condensing), the unit is suitable for diverse industrial conditions.
Alternative Names
51403645-400 51403645-100 51403698-100 51403519-160 51403299-200
Technical notes
Honeywell 51403626-200 IDE drive storage card operates with +5V DC ±5% and +12V DC ±10% supply voltage, consumes up to 5.0W in active mode and about 1.2W in idle state, supports 0.5A at 5V and 0.2A at 12V input current, features 16-bit Parallel ATA data bus, LVTTL/TTL compatible 3.3V and 5V logic levels, provides 4 kV ESD protection per IEC 61000-4-2, and operates from 0°C to +60°C with storage range -40°C to +85°C and 5%–95% RH non-condensing humidity.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What input voltage configuration does Honeywell 51403626-200 IDE drive storage card support for system integration?
Honeywell 51403626-200 supports +5V DC ±5% and +12V DC ±10% dual supply voltage input for industrial use.
What environmental storage conditions are defined for Honeywell 51403626-200 IDE drive storage card?
Honeywell 51403626-200 supports storage temperatures from -40°C to +85°C with 5% to 95% RH non-condensing humidity.
What logic compatibility standards are supported by Honeywell 51403626-200 IDE drive storage card?
Honeywell 51403626-200 supports 3.3V LVTTL and 5V TTL compatible logic levels.
