FS-TSDI-16UNI

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell FS-TSDI-16UNI is a 16-channel universal input field termination assembly for 24/48 V DC and NAMUR circuits for Honeywell Safety Manager.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for FS-TSDI-16UNI
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FS-TSDI-16UNI

  • Manufacturer:
    Honeywell
  • Part Number:
    FS-TSDI-16UNI
  • Product Family:
    Honeywell FSC Series
  • Product Type:
    16-Channel Universal Safe Digital Input FTA
  • Stock:
    1
  • Input channels:
    16 in two groups of eight
  • Supported circuits:
    24/48 V DC or DIN NAMUR
  • Module interface:
    Redundant SDIL-1608 pair via SICC cable
  • Group protection:
    250 mA fuse in common positive lead
  • Maximum group output:
    175 mA
  • Mounting:
    DIN rail
  • Terminal capacity:
    2.5 mm2 / AWG 14
  • Construction:
    Non-conformal-coated FS version
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    9x7x6cm
  • Tariff Code:
    3822120000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Signal Data Diagnostics Compatibility Installation Check

Features:

  • Sixteen universal input terminations
  • Two fused groups of eight channels
  • 24/48 V DC and NAMUR circuit support
FS-TSDI-16UNI provides the DIN-rail interface between sixteen field loops and redundant SDIL-1608 modules.

Group current, voltage and diagnostics depend on the selected module and converter configuration.

The FTA, SICC cable and redundant modules must be commissioned as one signal path.

The Honeywell FS-TSDI-16UNI 16-Channel Universal Safe Digital Input FTA is available for quotation and technical support from Apter Power.
Verified resources for FS-TSDI-16UNI:

Signal Data:

  • Input channels: 16 in two groups of eight
  • Supported circuits: 24/48 V DC or DIN NAMUR
  • Module interface: Redundant SDIL-1608 pair via SICC cable
Use the documented FS-TSDI-16UNI limits when calculating the complete field circuit.

Diagnostics:

  • Fuse and group-current supervision
  • Field-loop state diagnostics
  • Module-side diagnostic verification
Resolve all FS-TSDI-16UNI channel, wiring and system diagnostics before release to operation.

Compatibility:

  • Redundant SDIL-1608 module pair
  • 250 mA group fuse
  • Maximum 175 mA group output
Match FS-TSDI-16UNI to the approved Safety Manager module, termination and field-device arrangement.

Installation Check:

  • Confirm DIN-rail mounting
  • Check fuse, polarity and torque
  • Prove channels through the application
Complete and record the end-to-end functional test after installing FS-TSDI-16UNI.
Description
Honeywell FS-TSDI-16UNI 16-Channel Universal Safe Digital Input FTA is a sixteen-channel universal safe digital input field termination assembly for Honeywell Safety Manager.

It organizes 24 V DC, 48 V DC or DIN NAMUR circuits into two groups of eight. Each group has a 250 mA fuse and connects by SICC cable to a redundant pair of SDIL-1608 modules.

Verify field voltage, sensor type, group current, fuse, loop polarity, terminal torque and cable allocation. Prove every channel and group diagnostic through the connected modules and application.
Alternative Names
FS-TSDI-16UNI FS TSDI 16UNI FSTSDI16UNI Honeywell FS-TSDI-16UNI Honeywell FS TSDI 16UNI Honeywell FSTSDI16UNI FS-TSDI-16UNI 16-Channel Universal Safe Digital Input FTA Honeywell Safety Manager FS-TSDI-16UNI
Technical notes
FS-TSDI-16UNI terminates sixteen 24/48 V DC or NAMUR input circuits in two fused groups. Verify the exact field interface and approved system configuration before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can both 24 V and 48 V circuits be used?
Yes, but the connected input module determines the actual voltage and diagnostic limits.
How are the channels grouped?
They are arranged as two groups of eight with a 250 mA common-positive fuse per group.
Can NAMUR sensors be terminated here?
Yes when the SDIL-1608 converter and sensor-current thresholds are correctly selected.
Which hardware must be matched with FS-TSDI-16UNI?
Verify Redundant SDIL-1608 module pair, 250 mA group fuse and the approved Safety Manager hardware list before installation.
Which diagnostics are important for FS-TSDI-16UNI?
Check fuse and group-current supervision, field-loop state diagnostics, module-side diagnostic verification and clear every unexplained channel or system alarm.
Can another construction variant replace FS-TSDI-16UNI?
Only after environmental construction, certifications, hardware revision and project approval have been confirmed.
What commissioning checks are required for FS-TSDI-16UNI?
Perform these product-specific checks: confirm din-rail mounting, check fuse, polarity and torque, prove channels through the application; document the final results.
What information is needed to quote FS-TSDI-16UNI?
Provide the exact FTA model, hardware revision, connected field circuit, required construction, quantity and destination.
