Features:
- Serial communication termination
- Rs-232, rs-422 and rs-485 interfaces
- Matched with Safety Manager communication module and approved cable
FS-DCOM-232/485 provides field termination for serial control-system networks in a Honeywell Safety Manager installation.
Its standard fs construction and the documented RS-232, RS-422 and RS-485 interfaces must match the cabinet and field design.
Verify port mode, termination, shielding and signal reference and the complete connected path before the equipment is released to operation.
The Honeywell FS-DCOM-232/485 RS-232/RS-422/RS-485 Communication FTA is available for quotation and technical support from Apter Power.
Verified resources for FS-DCOM-232/485:
Signal Data:
- serial communication termination
- RS-232, RS-422 and RS-485 interfaces
- System role: field termination for serial control-system networks
Use the documented FS-DCOM-232/485 electrical limits when calculating the complete connected circuit.
Diagnostics:
- Port mode, termination, shielding and signal reference
- Check channel and system alarms
- Document normal and fault-state results
Resolve all FS-DCOM-232/485 wiring, power, communication and system diagnostics before release to operation.
Compatibility:
- Matched hardware: Safety Manager communication module and approved cable
- Construction: Standard FS construction
- Confirm firmware and hardware revision
Match FS-DCOM-232/485 to the approved cabinet, cable, termination and field-device arrangement.
Installation Check:
- Verify power, polarity and grounding
- Confirm terminal allocation and cable identification
- Prove the complete end-to-end function
Record the final configuration and all functional-test results after installing FS-DCOM-232/485.
