Features:
- 16 fire-detector channels
- 24 v dc monitored fire-detector loops
- Matched with SAI-1620m safe analog input module
FS-TSFIRE-1624 provides termination and power distribution for approved fire detectors in a Honeywell Safety Manager installation.
Its standard fs construction and the documented 24 V DC monitored fire-detector loops must match the cabinet and field design.
Verify alarm thresholds, loop continuity and supply supervision and the complete connected path before the equipment is released to operation.
The Honeywell FS-TSFIRE-1624 16-Channel Safe Fire Detector Input FTA is available for quotation and technical support from Apter Power.
Verified resources for FS-TSFIRE-1624:
Signal Data:
- 16 fire-detector channels
- 24 V DC monitored fire-detector loops
- System role: termination and power distribution for approved fire detectors
Use the documented FS-TSFIRE-1624 electrical limits when calculating the complete connected circuit.
Diagnostics:
- Alarm thresholds, loop continuity and supply supervision
- Check channel and system alarms
- Document normal and fault-state results
Resolve all FS-TSFIRE-1624 wiring, power, communication and system diagnostics before release to operation.
Compatibility:
- Matched hardware: SAI-1620m safe analog input module
- Construction: Standard FS construction
- Confirm firmware and hardware revision
Match FS-TSFIRE-1624 to the approved cabinet, cable, termination and field-device arrangement.
Installation Check:
- Verify power, polarity and grounding
- Confirm terminal allocation and cable identification
- Prove the complete end-to-end function
Record the final configuration and all functional-test results after installing FS-TSFIRE-1624.
