RH916XG

/ 4.9
1001 reviews | Need a Specific Revision?
Foxboro RH916XG is the passive compression termination assembly that connects eight isolated field current loops to an FBM201 module.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for RH916XG
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for RH916XG

  • Manufacturer:
    Invensys
  • Part Number:
    RH916XG
  • Product Family:
    Foxboro
  • Product Type:
    FBM201 Compression Termination Assembly
  • Stock:
    1
  • Channels:
    8
  • Construction:
    Passive compression termination assembly
  • Termination cable type:
    Type 1
  • Cable length range:
    Up to 30 m
  • Dimensions:
    7.6 × 9.0 × 12.5 cm
  • Height above DIN rail:
    7.2 cm, nominal
  • Mounting:
    32 mm or 35 mm DIN rail
  • Weight:
    0.181 kg
  • Tariff Code:
    8536909000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Field Wiring Cable Interface Mechanical Fit Application
  • Terminates eight FBM201 field circuits
  • Uses a separately selected Type 1 TA cable
  • Confirm terminal style, cable length and loop-power design

RH916XG is selected when an FBM201 installation requires its documented passive compression field-terminal assembly.

It must be treated as wiring hardware rather than as the electronic input module, so its physical data belong only to the TA record.

Before replacement, photograph every terminal and verify the Type 1 cable at both ends to prevent channel reversal or shared-return errors.

Availability, condition, price, and shipping time for RH916XG are confirmed during quotation.

Foxboro RH916XG Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Label all eight circuits before removing terminals
  • Preserve individual returns, shields and loop-power feeds
  • Tighten compression terminals to the approved practice
  • Use only the documented Type 1 TA cable
  • Check both D-sub connectors for bent pins and secure latching
  • Maintain the cable bend radius and enclosure routing
  • Allow for the nominal 12.5 cm TA depth
  • Mount on a supported 32 mm or 35 mm DIN rail
  • Keep service access clear for terminal inspection
  • FBM201 field-loop termination
  • DIN-rail marshalling inside process cabinets
  • Like-for-like replacement of RH916XG assemblies
Description
Foxboro RH916XG routes eight field-current circuits through compression terminals to the FBM201 baseplate connection.

The assembly contains no measurement electronics; conversion, diagnostics and isolation are performed by the associated FBM201.

DIN-rail mounting allows the field wiring to remain organized separately from the electronic module and to be located up to the documented cable limit.
Alternative Names
RH916XG RH 916 XG Foxboro RH916XG Invensys RH916XG FBM201 RH916XG Foxboro Evo RH916XG Invensys Foxboro RH916XG
Technical notes
RH916XG is the passive compression termination assembly for Foxboro FBM201 analog input modules, not an electronic FBM. Before replacement, verify the Type 1 cable, terminal wiring and loop-power arrangement; keep its 0.181 kg weight and TA dimensions separate from the FBM201 module fields.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Foxboro RH916XG directly replace a legacy P0916AA termination assembly?
Yes. Foxboro RH916XG supersedes P0916AA for FBM201 applications. Before replacement, confirm the existing terminal assignments, Type 1 cable, field-loop wiring and certification requirements remain compatible.
Does Foxboro RH916XG include the termination cable required to connect it to FBM201?
No. Foxboro RH916XG is the termination assembly only. The Type 1 termination cable must be selected separately according to the required length, cable-jacket material and installed FBM baseplate connection.
Can Foxboro RH916XG be replaced without changing the FBM201 database?
A like-for-like TA normally does not change the database, but every terminal assignment and loop-power connection must remain identical.
Why might several loops fail after replacing Foxboro RH916XG?
Check TA cable seating, connector pin damage, common loop-power wiring and shifted terminal assignments before suspecting the FBM201.
What should be documented before removing Foxboro RH916XG?
Record the TA label, rail position, cable part and length, all eight terminal assignments, shields, returns and loop-power feeds.
Can Foxboro RH916XG be used with FBM201b, FBM201c or FBM201d modules?
No. Foxboro RH916XG is specified for the standard FBM201 0–20 mA input module. FBM201b, FBM201c and FBM201d require their corresponding termination assemblies, so the exact FBM variant must be confirmed before ordering.
How should Foxboro RH916XG be accepted after installation?
Continuity-check each terminal-to-channel path, inspect shield practice and polarity, then validate all eight loops through the connected FBM201.
