The Motortronics MVC4-TCB 36-0576 is a dedicated terminal block and control board designed specifically for the MVC4 series medium-voltage soft starters, maintaining the operational integrity of the entire motor control system.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for MVC4-TCB 36-0576
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVC4-TCB 36-0576

  • Manufacturer:
    MOTORTRONICS
  • Part Number:
    MVC4-TCB 36-0576
  • Product Family:
    MOTORTRONICS
  • Product Type:
    Dedicated Terminal Block and Control Board
  • Stock:
    3
  • Series Compatibility:
    MVC4 Series Medium-Voltage Soft Starters
  • Function:
    Core Logic Interface
  • Control Power Voltage:
    120 VAC
  • Input/Output Type:
    Programmable Inputs and Outputs
  • Isolation Method:
    Fiber-Optic Isolation Paths
  • Auxiliary Contacts:
    Dry Contacts
  • Weight:
    0.25 kg
  • Estimated shipping dimensions:
    3.5x13.3x13.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Certifications & Standards Compatibility & Interoperability

Features:

  • Core Interface Between the 120 VAC Control Power Source and MVC4 Series Soft Starter Logic System
  • Integrates Capability of Signal Processing with Fiber-Optic Isolation Protection
  • Functions in Coordination with the MVC4 Series Medium-Voltage Soft Starters and High-Voltage Power Components
The MOTORTRONICS MVC4-TCB 36-0576 serves as the Terminal and Control Board in an MVC4 soft starter system, delivering reliable logic interface functionality to all control modules within the starter. It continuously processes incoming 120 VAC control power and converts low-voltage signals into precisely timed commands, distributing these instructions through isolated pathways to support seamless operation of all monitoring and protection functions. Stable signal transmission is standard with the MVC4-TCB 36-0576, and its redundant isolation architecture ensures accurate command execution even in the presence of high-voltage barriers or electromagnetic interference. The MVC4-TCB 36-0576 incorporates significant design improvements over previous control interface solutions, including universal programmable input/output capability within the MVC4 starter framework.

The MVC4-TCB 36-0576 provides essential control functions common to the entire starter system, and represents a critical component of the motor protection path, directly influencing the proper, normal operation of the overall motor control system. One MVC4-TCB 36-0576 board is required per MVC4 soft starter to establish the primary logic interface. The MVC4-TCB 36-0576 occupies a dedicated position within the starter enclosure and interfaces directly with the CPU and power electronics.

For complex industrial applications, the MVC4 system leverages the MVC4-TCB 36-0576 to manage critical signal processing tasks. In addition to standard control operations, the board performs automatic fault detection and emergency response coordination. The MVC4-TCB 36-0576 executes protective actions using internal circuitry designed for heavy-duty industrial environments. Through this method, the control board continuously monitors the health of incoming signals such as ESTOP and Fault inputs. If the system detects that a critical safety signal requires immediate action, it will automatically trigger protective logic to isolate the power electronics and prevent motor damage or system-wide downtime.
