6SC6512-0AA02

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6SC6512-0AA02 is a SIMODRIVE 650 transistor control PCB documented for the 120 A drive execution. It coordinates control signals and transistor switching inside the associated power assembly.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6SC6512-0AA02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6SC6512-0AA02

  • Manufacturer:
    Siemens
  • Part Number:
    6SC6512-0AA02
  • Product Family:
    Siemens SIMODRIVE
  • Product Type:
    Transistor Control PCB
  • Stock:
    1
  • Drive Family:
    SIMODRIVE 650
  • Assembly Type:
    Transistor control printed-circuit board
  • Current Class:
    120 A
  • Associated Drive Execution:
    6SC6512-4AA02
  • Ordering Identity:
    6SC6512-0AA02
  • Weight:
    8.3776 lbs (3.8 kg)
  • Estimated shipping dimensions:
    64 x 17.8 x 6 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Configuration & Programming Diagnostics Control

Features:

  • Controls transistor switching within the documented 120 A SIMODRIVE 650 execution.
  • Forms the control PCB associated with drive assembly 6SC6512-4AA02.
  • Supports repair of legacy Siemens variable-speed drive equipment.
The supplied item is the control-electronics PCB identified by the complete ordering code and intended for the corresponding SIMODRIVE 650 hardware.

It processes the converter control path and coordinates transistor operation so the connected power assembly can regulate motor output.

Board revision, connectors and parameter data must be compared with the removed unit before power is restored to the drive.

Availability is confirmed against the exact board and revision requested.
Verified resources for Siemens 6SC6512-0AA02:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Restores the control electronics of compatible SIMODRIVE 650 motor-drive assemblies.
  • Supports maintenance of legacy production machinery that retains the documented 120 A converter.
  • Provides a board-level repair option when the original power stage and motor system remain serviceable.
  • Retain the approved drive parameter record before removing the existing control board.
  • Confirm that revision-dependent settings and feedback assignments correspond to the installed converter.
  • Reload and validate configuration data using the service procedure for the complete drive assembly.
  • Use the converter fault history to separate control-board symptoms from power-stage or feedback failures.
  • Inspect gate-control connections and cable seating before attributing a trip to the printed-circuit board.
  • Verify normal status through a controlled startup after replacement rather than applying full load immediately.
  • Processes the internal command path that governs transistor switching in the associated converter.
  • Coordinates with the original power section and feedback hardware instead of functioning independently.
  • Maintains the documented control relationship for the 120 A SIMODRIVE 650 execution.
Description
Siemens 6SC6512-0AA02 is a transistor-control printed-circuit board for the SIMODRIVE 650 family. The documented execution belongs to the 120 A drive class and is associated with the 6SC6512-4AA02 power assembly, where it forms part of the internal transistor-control hardware. Rather than carrying the motor load directly, the PCB provides the coordinated control layer used by the power transistors, making its ordering identity inseparable from the electrical class and mechanical execution of the host drive.

Within the drive, the board processes control commands and coordinates the switching stage used by the power section. Its role makes it relevant to maintenance of legacy motion systems in which the original SIMODRIVE 650 mechanical arrangement, power hardware and interconnections are being retained rather than replaced as a complete drive package. Restoring this control path can preserve an established machine axis, but successful service still depends on the condition of the associated power devices, supplies, cables and surrounding drive electronics.

Selection should be based on the complete drive designation and the installed power-stage configuration, not only on the appearance of the PCB. Connector positions, board revision and the 120 A association should all be checked against the existing assembly before 6SC6512-0AA02 is fitted as a service replacement. During installation, the drive must be safely de-energized and its DC link discharged; keyed connectors, mounting hardware and board seating should then be compared with the removed unit before power is restored.
Alternative Names
Siemens 6SC6512-0AA02 6SC 6512-0AA02 6SC65120AA02 SIMODRIVE 650 6SC6512-0AA02 Siemens transistor control PCB 6SC6512-0AA02 6SC6512-4AA02 control board SIMODRIVE 650 120 A control PCB
Technical notes
When replacing 6SC6512-0AA02, preserve the original connector positions and parameter record, then confirm that the board revision matches the 120 A SIMODRIVE 650 power assembly.
