Features:
- Interface Between the Universal AC Power Source and SIMODRIVE 611 Drive System
- Combines Capability of AC/DC Power Conversion with Single-Axis Motor Control
- Operates in Conjunction with the SIMODRIVE 611 Control Unit and Associated Motor Modules
The SIEMENS 6SN1123-1AA00-0EA2 functions as the Power Module within the SIMODRIVE 611 drive lineup, delivering regulated DC power conversion and motor control for single-axis applications. It continuously processes incoming power to drive feed axes at 56 A rated current and main spindles at 60 A rated current, distributing controlled power through the drive bus to support steady state operation of connected servo motors.
The 6SN1123-1AA00-0EA2 provides essential power functions for single-axis drive applications and serves as a critical component of the motion control path, directly affecting the proper, normal operation of the overall drive system. One 6SN1123-1AA00-0EA2 power module is required per controlled axis within the SIMODRIVE 611 configuration. The 6SN1123-1AA00-0EA2 occupies a designated slot position in the drive lineup and integrates with the control unit to execute precise speed and torque commands.
For multi-axis applications, the SIMODRIVE 611 system requires additional 6SN1123 series power modules installed in corresponding axis slots. In addition to standard single-axis operation, the modular configuration also performs coordinated motion control. The SIMODRIVE 611 multi-axis arrangement executes synchronization using the internal bus architecture specified in the drive options.
The 6SN1123-1AA00-0EA2 SIEMENS POWER MODULE may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6SN1123-1AA00-0EA2 POWER MODULE Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SIEMENS 6SN1123-1AA00-0EA2 POWER MODULE Specs
General
- Manufacturer SIEMENS
- Model 6SN1123-1AA00-0EA2
- Condition New Original ready stock
- Product Family 6SN1123-1AA00-0DA0,6SN1123-1AA00-0JA1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- CNC Machine Tools: Drives high-precision axes in metal milling, turning, grinding, and woodworking CNC machinery.
- Motor Control: Powers 1FT5/1FT6 synchronous feed motors up to 56 A and 1PH asynchronous main spindles up to 60 A.
- Automated Production Lines: Deployed in heavy-duty packaging, automotive welding, and high-speed material handling systems.
- Mount the 6SN1123-1AA00-0EA2 in the SIMODRIVE 611 modular lineup and connect it to the common DC-link busbars.
- Install a compatible plug-in control unit; controller commands and drive communication are handled through this control interface.
- Use software appropriate to the installed control unit, with separate 24 V wiring for pulse enable and emergency-stop functions.
- IP20 protection requires installation in a suitable control cabinet. Operation is permitted from 0°C to +55°C, with derating above +40°C.
- Storage and transport temperatures range from −40°C to +70°C. Internal cooling uses an integrated fan to dissipate heat.
- Installation follows DIN EN 50178; upstream residual-current protection must be AC/DC-sensitive where required.
