6ES7223-1BL32-0XB0

/ 4.9
1001 reviews | Need a Specific Revision?
The Siemens 6ES7223-1BL32-0XB0 is a SIMATIC S7-1200 SM 1223 digital I/O module with 16 sink/source 24 V DC inputs and 16 transistor outputs rated at 0.5 A per channel.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 6ES7223-1BL32-0XB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7223-1BL32-0XB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7223-1BL32-0XB0
  • Product Family:
    Siemens Simatic S7-1200
  • Product Type:
    Digital I/O Module
  • Stock:
    3
  • Digital Inputs:
    16
  • Digital Outputs:
    16
  • Total Digital Channels:
    32
  • Digital Input Groups:
    2
  • Digital Output Groups:
    1
  • Output Type:
    24 V DC transistor
  • Rated Output Current:
    0.5 A per channel
  • Backplane Current at 5 V DC:
    185 mA max.
  • Digital Input Current, Signal 1:
    4 mA typical per channel
  • Minimum Input Current, Signal 1:
    2.5 mA
  • Maximum Permissible Quiescent Current, Signal 0:
    1 mA
  • Input Level for Signal “0”:
    5 V DC at 1 mA
  • Input Level for Signal “1”:
    15 V DC at 2.5 mA
  • Input Characteristic:
    IEC 61131 Type 1
  • Total Output Current per Ground, Horizontal Installation up to 50°C:
    8 A max.
  • Electrical Isolation Between Output Channels and Backplane Bus:
    500 V AC
  • Horizontal installation:
    −20°C to +60°C
  • Vertical installation:
    −20°C to +50°C
  • Storage/transport:
    −40°C to +70°C
  • Relative Humidity:
    Up to 95% at 25°C, without condensation
  • Weight:
    0.282 kg
  • Estimated shipping dimensions:
    8.80 × 11.10 × 8.50 cm
  • Tariff Code:
    85389091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Communication Safety & Compliance

Features:

  • Balanced I/O with 24V DC sink/source inputs and 0.5A transistor outputs.
  • 8A total current per group with 50µs/200µs output delay.
  • 70mm width, IP20, LED status indicators, and diagnostic alarms.
The 6ES7223-1BL32-0XB0 is a SM 1223 digital I/O module providing 16 digital inputs and 16 digital outputs in a single compact module. The inputs operate at 24V DC with sink/source capability, organized in two isolated groups for flexible field wiring. The outputs use transistor technology with 0.5A per channel, suitable for driving relays, solenoids, and indicator lamps. The 6ES7223-1BL32-0XB0's balanced I/O configuration makes it ideal for applications requiring equal numbers of inputs and outputs, reducing the need for multiple modules.

The 6ES7223-1BL32-0XB0 delivers 0.5A per output channel with a total group current of 8A in horizontal installation up to 50°C. The outputs feature fast switching times with a maximum delay of 50µs for 0→1 transitions and 200µs for 1→0 transitions, ensuring responsive control for time-critical applications. The 6ES7223-1BL32-0XB0 supports shielded cable lengths up to 500m and unshielded up to 150m, providing flexibility for distributed I/O installations. The 6ES7223-1BL32-0XB0's high output current and fast switching make it suitable for demanding automation tasks.

The 6ES7223-1BL32-0XB0 has an IP20 protection rating and operates from -20°C to 60°C, making it suitable for industrial environments. The 6ES7223-1BL32-0XB0 includes diagnostic alarms and LED indicators for input and output status monitoring, enabling rapid troubleshooting. The 6ES7223-1BL32-0XB0 carries CE, C-Tick, and FM approvals, ensuring compliance with international standards.

The 6ES7223-1B32-0XB0 SIEMENS Digital I/O Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

SIEMENS 6ES7223-1B32-0XB0 Digital I/O Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SIEMENS 6ES7223-1B32-0XB0 Digital I/O Module Specs

General

  • Manufacturer SIEMENS
  • Model 6ES7223-1B32-0XB0
  • Condition New Original ready stock
  • Product Family SM 1223 Digital Input/Output Modules
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Factory Automation & Production Lines: Interfacing with mechanical sensors (proximity, photoelectric switches), limit switches, and pushing control signals to 24V pneumatic solenoids and light curtains.
  • Packaging and Bottling Systems: Managing high-speed conveyor sorting gates, feeding systems, and counting inputs on automated labeling machinery.
  • Building Automation and Infrastructure: Monitoring status indicators of HVAC valves, fan systems, and automated lighting networks, or controlling low-power auxiliary water pumps via interposing relays.
  • Material Handling and Logistics: Expanding I/O density on small automated guided vehicle (AGV) docking stations, smart sorting bins, and simple lifting elevators.
  • Integrated Backplane Bus Link: The module snaps onto the right side of any S7-1200 CPU using a slide-out, built-in backplane bus connector. Power for the internal module electronics is drawn entirely from this CPU backplane bus.
  • Field-Side Wiring Connections: Features removable screw or push-in terminal blocks. This allows field technicians to swap a damaged module without disconnecting individual field wires, vastly reducing maintenance downtime.
  • Input Channel Topology (Sink/Source): The 24V DC digital inputs can be wired in either Sink (M-switching) or Source (L+-switching) configurations, accommodating a massive variety of global PNP and NPN industrial sensors.
  • Electrical Galvanic Isolation: Features optical isolation (optocouplers) between the field-side electronics and the internal S7-1200 backplane logic circuit. This completely isolates the sensitive CPU brain from external field voltage surges or wiring shorts.
  • Built-In Output Protection: Each transistor output is electronically protected against short-circuits and thermal overloads. If a field valve shorts out, the channel shuts down to prevent burning out the module.
  • CE & UKCA: Fully certified for European and UK industrial safety, health, and environmental standards.
Description
The Siemens 6ES7223-1BL32-0XB0 is a SIMATIC S7-1200 digital I/O module (SM 1223) providing 16 digital inputs and 16 digital outputs in a single compact module. This module offers a cost-effective solution for applications requiring balanced I/O configurations. The 6ES7223-1BL32-0XB0 is designed for use with the S7-1200 PLC system.

The Siemens 6ES7223-1BL32-0XB0 features 16 digital inputs with 24V DC (sink/source) organized in 2 groups, and 16 digital outputs with transistor technology at 0.5A per channel. The 6ES7223-1BL32-0XB0 has a typical power loss of 4.5W and consumes 185mA from the backplane bus. The 6ES7223-1BL32-0XB0 operates on a 24V DC supply with a voltage range of 20.4-28.8V.

The 6ES7223-1BL32-0XB0 includes diagnostic alarms and LED indicators for input and output status monitoring. The 6ES7223-1BL32-0XB0 has a total output current of 8A per group (horizontal installation up to 50°C). The 6ES7223-1BL32-0XB0 features galvanic isolation between channels (in groups of 2 for inputs, groups of 1 for outputs).

The 6ES7223-1BL32-0XB0 has an IP20 protection rating and operates from -20°C to 60°C. The 6ES7223-1BL32-0XB0 supports shielded cable lengths up to 500m and unshielded up to 150m. The 6ES7223-1BL32-0XB0 carries CE, C-Tick, and FM approvals, making it suitable for global industrial applications.
Alternative Names
6ES72231BL320XB0 6ES7 223-1BL32-0XB0
Technical notes
The Siemens 6ES7223-1BL32-0XB0 is an S7-1200 SM 1223 digital I/O module with 16 DI (24V DC) and 16 DO (0.5A transistor). Features 4.5W power loss, 185mA backplane current, 8A group output, 50µs/200µs output delay, 500m shielded cable, -20°C to 60°C.
