The Woodward 5460-667 is a 125V DC/DC power supply module delivering stable, low-ripple power for turbine and engine control systems.
Get a quick price for 5460-667
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 5460-667

  • Manufacturer:
    Woodward
  • Part Number:
    5460-667
  • Product Family:
    5400 Series
  • Product Type:
    125V DC/DC Power Supply
  • Input Voltage:
    3 x 530 V AC ±15% or 1 x 230 V AC ±15%
  • Output Voltage:
    125V DC
  • Safety Certification:
    VDE 0805 / EN 60950
  • Surge Voltage Immunity:
    EN 6100-4-5
  • EMI Suppression:
    EN 55011, Class B
  • Mounting:
    DIN rail snap-on fastening
  • Status Indication:
    LED
  • Weight:
    1.76 kg
  • Estimated shipping dimensions:
    12.5x22x17.1cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Performance & Efficiency

Features:

  • High Output Stability for Critical Control Systems
  • Comprehensive Protection for Industrial Reliability
  • Flexible Installation with Global Certification
The Woodward 5460-667 delivers exceptional output voltage stability with minimal residual ripple, ensuring sensitive electronic control systems receive clean, consistent power. This stability translates directly to more reliable turbine and engine control, reducing the risk of nuisance trips or erratic controller behavior caused by power fluctuations.

Engineered for demanding environments, the Woodward 5460-667 incorporates both short-circuit and no-load protection as standard features. These safeguards protect not only the power supply itself but also the connected control equipment, preventing damage from common electrical faults that frequently occur in industrial settings.

The Woodward 5460-667 supports both three-phase (530V) and single-phase (230V) input configurations with ±15% tolerance, accommodating different site power infrastructures worldwide. Its compact DIN rail design and compliance with multiple international standards (VDE, EN) make it a versatile choice for control cabinet upgrades or new installations across different regions.

The 5460-667 Woodward 125V DC/DC Power Supply Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Woodward 5460-667 125V DC/DC Power Supply Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Woodward 5460-667 125V DC/DC Power Supply Module

General

  • Manufacturer Woodward
  • Model 5460-667
  • Condition New Original ready stock
  • Product Family 5466-353,5417-040,5437-843
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Turbine Control Systems:The Woodward 5460-667 is specifically suited for powering steam, gas, and hydro turbine control systems where stable 125V DC power is required for reliable governor operation.
  • Engine Generator SetsP:The module provides essential DC power for diesel and gas generator control panels, supporting engine speed governing and load sharing functions.
  • Industrial Automation Panels:The DIN rail mounting and compact dimensions of the Woodward 5460-667 make it an excellent choice for general industrial control cabinets requiring dependable 125V DC power distribution.
  • Retrofit and Replacement Projects:As a direct replacement for original Woodward power supplies, the Woodward 5460-667 simplifies upgrade projects for existing turbine and engine control systems without requiring panel reconfiguration.
  • Temperature Range:The Woodward 5460-667 is designed for operation within standard industrial control cabinet temperature ranges, maintaining specified performance without forced cooling in typical indoor environments.
  • Electrical Noise Immunity:With EN 50082-2 certification, the Woodward 5460-667 maintains stable operation even when installed near variable frequency drives, contactors, and other common sources of industrial electromagnetic interference.
  • DIN Rail Mounting:The snap-on fastening mechanism of the Woodward 5460-667 allows secure installation on standard 35mm DIN rails, the universal mounting system found in virtually all industrial control panels worldwide.
  • Ventilation Requirements:The compact housing of the Woodward 5460-667 is designed for natural convection cooling, requiring only standard clearance around the unit rather than forced air or special cooling arrangements.
  • High Efficiency Design:The Woodward 5460-667 converts input power to regulated 125V DC output with minimal energy loss, reducing heat generation inside control cabinets and lowering operational costs compared to less efficient power conversion methods.
  • Low Residual Ripple:Clean DC output with low residual ripple from the Woodward 5460-667 ensures sensitive electronic controls receive power free from unwanted AC components that could cause measurement errors or control instability.
  • Wide Input Tolerance:With ±15% tolerance on both three-phase and single-phase inputs, the Woodward 5460-667 maintains full rated output even when site power fluctuates due to load changes or utility variations, providing consistent performance without nuisance shutdowns.
  • Surge Protection:Compliance with EN 6100-4-5 means the Woodward 5460-667 withstands voltage surges and transients common in industrial power systems, protecting downstream control equipment from damage during switching events or lightning strikes.
Description
The Woodward 5460-667 DC/DC power supply module represents Woodward's commitment to robust industrial power solutions. Designed to accept either three-phase 530V AC or single-phase 230V AC input with ±15% tolerance, this module delivers a regulated 125V DC output essential for critical control systems. Its wide input voltage range makes it adaptable to various industrial power infrastructures commonly found in power generation and marine applications.

Safety and electromagnetic compatibility are cornerstones of the Woodward 5460-667 design. The unit complies with VDE 0805 and EN 60950 safety standards, ensuring operator protection and system reliability. It features comprehensive electromagnetic interference suppression meeting EN 55011 Class B requirements, while its immunity to electrical disturbances complies with EN 50082-2. These certifications make the Woodward 5460-667 suitable for installation in electrically noisy industrial environments where other power supplies might fail.

The Woodward 5460-667 is built for practical field application. Its compact housing measures allowing easy DIN rail mounting in space-constrained control cabinets. The module incorporates both screw-type and plug-in connectors for flexible wiring options, while LED status indicators provide at-a-glance operational confirmation. Short-circuit and no-load protection features safeguard both the power supply and connected equipment from common fault conditions.
Alternative Names
5460667 546O-667 5417-028 5417-175 5417-040 5437-672 5437-843 5466-353
Technical notes
The Woodward 5460-667 requires professional installation by qualified technicians familiar with high-voltage DC power systems; regular inspection of its LED status indicators is recommended as part of preventive maintenance schedules, and optimal performance is achieved when the unit is mounted on a standard DIN rail with adequate ventilation clearance.
