CI851K01 3BSE018101R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB CI851K01 3BSE018101R1 is a PROFIBUS DP-V0 master interface kit for AC 800M CEX-Bus systems, supplied with TP851.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CI851K01 3BSE018101R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI851K01 3BSE018101R1

  • Manufacturer:
    ABB
  • Part Number:
    CI851K01 3BSE018101R1
  • Product Family:
    ABB Advant AC800M
  • Product Type:
    PROFIBUS DP Communication Interface Kit
  • Stock:
    1
  • ABB Article Number:
    3BSE018101R1
  • Package Contents:
    CI851 interface and TP851 baseplate
  • Protocol:
    PROFIBUS DP-V0
  • Operating Role:
    DP Master Class I
  • Communication Speed:
    9.6 to 12000 kbit/s
  • Hot Swap:
    Not supported
  • Protection Rating:
    IP20
  • Weight:
    0.7 kg
  • Estimated shipping dimensions:
    5.9 x 18.5 x 12.75 cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications PROFIBUS Topology CEX-Bus Limits Legacy Migration

Product overview

  • Interface role: PROFIBUS DP-V0 Master Class I for AC 800M controllers
  • Kit scope: CI851 communication interface with TP851 baseplate
  • Legacy status: ABB identifies CI854 as the replacement for CI851

CI851K01 3BSE018101R1 connects a PROFIBUS DP segment to the AC 800M CEX-Bus. It supports 9.6 to 12000 kbit/s and uses a female DB9 connector on TP851.

Verify the installed controller, PROFIBUS topology, project version, and replacement plan before ordering this legacy kit.

ABB CI851K01 3BSE018101R1 PROFIBUS DP Interface Kit Specifications

General

  • ManufacturerABB
  • ModelCI851K01 3BSE018101R1
  • ConditionNew and factory sealed
  • Product FamilyAC 800M Communication Interfaces

PROFIBUS DP segment planning

  • Master class: DP Master Class I
  • Nodes: Up to 32 nodes on one segment
  • Connector: Female DB9 on TP851
  • Speed range: 9.6 to 12000 kbit/s

Controller-side checks

  • Mounting: CI851 uses the TP851 baseplate on the AC 800M CEX-Bus
  • Hot swap: Not supported
  • Protection: IP20
  • High Integrity: CI851 is not supported in a High Integrity controller

CI851 replacement review

  • OEM direction: ABB identifies CI854 as the replacement for CI851
  • Project check: Confirm controller software and PROFIBUS configuration before migration
  • Hardware check: Compare the baseplate, connector, cable, and segment layout
  • Commissioning: Validate node addresses, baud rate, and diagnostics after replacement
Description
The CI851K01 3BSE018101R1 kit combines the CI851 PROFIBUS DP-V0 master interface with the TP851 baseplate for connection to the AC 800M CEX-Bus.

It supports DP Master Class I operation, 9.6 to 12000 kbit/s, and up to 32 nodes per segment. ABB specifies a female DB9 connector and no hot-swap support.

ABB identifies CI851 as a legacy interface replaced by CI854. Confirm the installed controller, PROFIBUS segment, project version, and replacement plan before ordering.
Alternative Names
CI851K01 3BSE018101R1 ABB CI851K01 3BSE018101R1 CI851K01 3BSE018101R1 CI851K01-3BSE018101R1 CI851 3BSE018101R1 ABB AC 800M CI851K01 CI851 PROFIBUS DP Interface Kit
Technical notes
CI851K01 is a PROFIBUS DP-V0 Master Class I interface kit with TP851. Verify the legacy replacement path and project compatibility.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is included in ABB CI851K01 3BSE018101R1?
ABB lists the CI851 interface and TP851 baseplate in the K01 package.
Which fieldbus protocol does CI851K01 support?
CI851 operates as a PROFIBUS DP-V0 Master Class I interface.
What PROFIBUS speed range does CI851 support?
ABB specifies 9.6 to 12000 kbit/s.
How many nodes can CI851 handle per segment?
ABB specifies up to 32 nodes on one PROFIBUS segment.
Does CI851 support hot replacement?
No. ABB documentation states that CI851 does not support hot swap.
Which connector is used for the CI851 PROFIBUS port?
The TP851 baseplate provides a female DB9 PROFIBUS connector.
Can CI851K01 be replaced by CI854 without engineering checks?
ABB identifies CI854 as the replacement; verify hardware, software, and project compatibility before migration.
