PM860AK01 3BSE066495R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB PM860AK01 3BSE066495R1 is a single-controller AC 800M processor unit kit built around the PM860A CPU.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PM860AK01 3BSE066495R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PM860AK01 3BSE066495R1

  • Manufacturer:
    ABB
  • Part Number:
    PM860AK01 3BSE066495R1
  • Product Family:
    ABB Advant AC800M
  • Product Type:
    Processor Unit
  • Stock:
    1
  • Package Configuration:
    Single-controller K01 kit
  • Controller Version:
    PM860A
  • Redundancy:
    No
  • High Integrity:
    No
  • Clock Frequency:
    48 MHz
  • Performance:
    0.23 ms per 1000 Boolean operations
  • Memory:
    16 MB
  • Application RAM:
    10.346 MB
  • Flash Storage:
    Yes
  • Processor:
    MPC860
  • Power Supply:
    24 V DC (19.2-30 V DC)
  • Current Consumption:
    180 mA typical; 300 mA maximum
  • Typical Power Dissipation:
    4.32 W
  • Ethernet Channels:
    2
  • Serial Channels:
    2 RS-232C
  • CEX-Bus Capacity:
    12 communication modules
  • Minimum Application Cycle:
    1 ms
  • Operating Temperature:
    0 to +55 C
  • Storage Temperature:
    -40 to +70 C
  • Relative Humidity:
    5-95%, non-condensing
  • Protection Rating:
    IP20
  • Weight:
    1.1 kg
  • Estimated shipping dimensions:
    11.9 x 18.6 x 13.5 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Load Review Interface Review Recovery Plan

Features:

  • PM860A processing: The processor executes the documented controller workload at 48 MHz.
  • Application storage: Flash memory supports stored application and data.
  • Communication base: Two Ethernet and two serial channels are built into the controller baseplate.
PM860AK01 is the single-controller PM860A configuration for an AC 800M project whose measured load and resource plan fit the documented controller limits.
Its integrated network and serial ports support controller communication and engineering access, while CEX-Bus modules extend the approved interface architecture.
Before a replacement outage, preserve the running project, firmware, Control Network configuration, serial assignments, communication-module tree, and field I/O records.
The PM860AK01 3BSE066495R1 ABB may be available from Apter Power subject to exact-article, condition and sourcing confirmation.

ABB PM860AK01 3BSE066495R1 Processor Unit Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

ABB PM860AK01 3BSE066495R1 Processor Unit Specs

General

  • ManufacturerABB
  • ModelPM860AK01 3BSE066495R1
  • ConditionNew and factory sealed
  • Product FamilyAC 800M Controllers

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

PM860A project checks

  • Application RAM: Compare the compiled project with the verified available memory.
  • Task execution: Review controller load and the shortest configured cycle.
  • Communication traffic: Include Control Network and CEX-Bus processing demand.
  • Operating margin: Confirm adequate capacity after all planned changes.

Built-in port preparation

  • CN1 and CN2: Record both Ethernet connections and node settings.
  • COM3: Preserve RS-232C modem-control assignments where used.
  • COM4: Confirm the isolated configuration-tool connection.
  • CEX-Bus: Match module order, termination, and power demand.

Controlled controller replacement

  • Verified backup: Use a tested application and configuration backup.
  • Firmware match: Confirm the approved controller firmware before download.
  • Power sequence: Follow site isolation and controlled start-up procedures.
  • Acceptance test: Validate controller load, networks, serial paths, I/O, and alarms.
Description

The ABB PM860AK01 3BSE066495R1 is a single-controller AC 800M processor unit kit built around the PM860A CPU.

Official ABB documentation for PM860AK01 3BSE066495R1 states: ABB documents 48 MHz processing, 16 MB memory, 10.346 MB application RAM, flash storage, two Ethernet ports, and two serial ports.

Before ordering PM860AK01 3BSE066495R1, confirm compiled application demand, controller firmware, network and serial assignments, CEX-Bus modules, base hardware, and full article identity.

Alternative Names
PM860AK01 3BSE066495R1 ABB PM860AK01 3BSE066495R1 PM860AK01 3BSE066495R1 PM860AK-01 3BSE066495R1 PM860AK01 3BSE 066495 R1 PM860AK013BSE066495R1 ABB AC 800M PM860AK01 PM860AK01 Processor Unit
Technical notes
PM860AK01 3BSE066495R1 must be matched by controller version and package configuration, not processor specifications alone. Confirm compiled application demand, controller firmware, network and serial assignments, CEX-Bus modules, base hardware, and full article identity.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should engineers size an application for ABB PM860AK01?
Use the compiled project, task execution data, communication load, CEX modules, I/O scan demand, and approved growth plan—not memory alone.
Can ABB PM860AK01 be installed as a redundant controller?
ABB identifies this K01 configuration as non-redundant. Select a separately documented redundant controller package when the architecture requires one.
What should be backed up before replacing ABB PM860AK01?
Retain the application, hardware tree, firmware, node settings, serial parameters, alarm configuration, controller diagnostics, and commissioning records.
What wiring checks apply to ABB PM860AK01?
Verify 24 V DC polarity and range, supply-status inputs, Ethernet and serial connectors, CEX termination, grounding, shielding, and cabinet routing.
Why might ABB PM860AK01 lose communication after restoration?
Compare node identity, IP configuration, Control Network topology, port assignments, firmware, CEX modules, and the restored hardware definition.
How should ABB PM860AK01 be validated after start-up?
Check task execution, controller load, both Ethernet paths, serial communication, module diagnostics, I/O updates, alarms, and operator functions.
What should a buyer include with an ABB PM860AK01 RFQ?
Provide the processor and base nameplates, software release, connected interfaces, quantity, condition, destination, and requested delivery date.
