ABB 1MRK000508-BDR06 is an RL110 binary input module providing sixteen 110–125 V DC input channels for compatible protection and control equipment.
In Stock
Ships by Sunday, October 18
Fast Shipping Available
Get a quick price for 1MRK000508-BDR06
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1MRK000508-BDR06

  • Manufacturer:
    ABB
  • Part Number:
    1MRK000508-BDR06
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    16-Channel 110–125 V DC Binary Input Module
  • Stock:
    1
  • Module Designation:
    BIM
  • Input Type:
    Binary DC inputs
  • Input Channels:
    16
  • Input Voltage Class:
    110–125 V DC
  • Input Current Version:
    50 mA
  • Variant Code:
    RL110
  • Signal Function:
    Field binary-status acquisition
  • Dimensions:
    23.3 × 17 × 1.5 cm
  • Weight:
    0.41 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Identity Check Wiring Review Commissioning Application
  • Provides sixteen binary input paths for protection and control indications
  • Uses the RL110 110–125 V DC field-input class
  • Transfers field contact states to the compatible host IED

1MRK000508-BDR06 is the BD R06 build of an ABB binary input module used in compatible protection and control assemblies.

Its role is to acquire sixteen station-DC field indications so the host equipment can use those states in protection, interlocking, alarm, and supervision logic.

Correct selection depends on the complete article, RL110 voltage/current variant, module position, connector arrangement, and the approved host-equipment bill of material.

Availability, condition, price, and shipping time for 1MRK000508-BDR06 are confirmed during quotation.

ABB 1MRK000508-BDR06 Binary Input Module Manuals, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Read the complete base article and R06 suffix from the installed module label
  • Confirm the RL110 voltage/current class in the approved host documentation
  • Compare connector keying and slot allocation before removing the original module
  • Trace each station-DC indication to its documented binary-input terminal
  • Verify polarity, source contact, common return, and isolation practice before energizing
  • Retain the terminal schedule so channel identities can be tested after replacement
  • Restore the approved input mapping in the protection and control project
  • Prove every indication from field contact to host IED status display
  • Record any inverted, delayed, or missing indication before returning the bay to service
  • Substation breaker and disconnector position acquisition
  • Protection-trip, alarm, and interlock contact monitoring
  • Station-DC binary status collection in compatible ABB protection IEDs
Description
1MRK000508-BDR06 is an ABB RL110 binary input module for compatible protection and control equipment.

Its sixteen input circuits receive 110–125 V DC field indications and transfer binary status information to the host IED.

Before replacement, compare the complete BD R06 identifier, input-voltage class, input-current version, connector arrangement, module position, and host-equipment ordering documentation.
Alternative Names
1MRK000508-BDR06 1MRK000508-BD R06 1MRK000508 BD R06 ABB 1MRK000508-BDR06 ABB 1MRK000508-BD R06 ABB BIM 1MRK000508-BDR06
Technical notes
1MRK000508-BDR06 requires matching the BD R06 identity, RL110 input class, connector, slot, field wiring, and host IED documentation; a voltage or revision mismatch can invalidate replacement compatibility.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why must the complete ABB 1MRK000508-BDR06 identifier be checked before ordering?
The BD base article and R06 revision identify a specific module build. Match the complete label, host IED documentation, voltage class, and connector arrangement rather than selecting by appearance.
Can ABB 1MRK000508-BDR06 replace an older 1MRK000508-BB module automatically?
ABB identifies BD as a later replacement path for the older BB article, but the host relay, input-current version, connector, firmware documentation, and engineering approval still require confirmation.
What should be compared with the installed unit before fitting ABB 1MRK000508-BDR06?
Compare the full article and revision, RL110 marking, 110–125 V DC input supply, module slot, connector keying, terminal wiring, and host-equipment bill of material.
How should an inactive channel on ABB 1MRK000508-BDR06 be investigated?
Check field voltage at the correct terminal, polarity, wiring continuity, source contact, connector seating, module diagnostics, and the corresponding binary-input mapping before replacing hardware.
Does ABB 1MRK000508-BDR06 accept any station DC voltage?
No. The documented RL110 variant is tied to the 110–125 V DC input class; a different station voltage requires the matching ABB input-module variant.
What records should be retained when replacing ABB 1MRK000508-BDR06?
Retain the original module label, slot position, terminal schedule, input mapping, protection project, alarm list, and test results so each field indication can be verified after replacement.
What is the main selection risk for ABB 1MRK000508-BDR06?
The principal risk is ordering the correct base family with the wrong voltage/current or revision variant, which may fit mechanically but not match the approved relay configuration.
