FS300R12OE4/BGAD-22C

/ 4.9
1001 reviews | Need a Specific Revision?
This kit combines the FS300R12OE4 1200V/300A IGBT module with ABB's BGAD-22C gate driver, providing a highly reliable power core for the ACS880-104 drive.
Get a quick price for FS300R12OE4/BGAD-22C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FS300R12OE4/BGAD-22C

  • Manufacturer:
    ABB
  • Part Number:
    FS300R12OE4/BGAD-22C
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Voltage class:
    1200V
  • Current rating:
    300A
  • Total power dissipation:
    1650W
  • Storage temperature:
    -40 °C ... 125 °C
  • Operating Frequency:
    Up to 12 kHz
  • Compatible Drive Family:
    ACS880-104
  • Weight:
    0.24 kg
  • Estimated shipping dimensions:
    2.1x30.3x12.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The FS300R12OE4/BGAD-22C IGBT module kit is specifically designed for the ABB ACS880-104 drive system. It combines the FS300R12OE4 IGBT (1200V voltage rating, 300A rated current) with the dedicated BGAD-22C gate driver module. This IGBT supports operating frequencies up to 12 kHz, providing precise power conversion for industrial motor drives and energy systems, and its 1650W total power dissipation rating ensures stable operation even under sustained heavy loads. Its storage temperature range of -40°C to 125°C enables it to withstand extreme environmental conditions, from cold industrial areas to high-temperature production lines.

The BGAD-22C gate driver is pre-calibrated to the electrical parameters of the FS300R12OE4, providing precise gate control to optimize switching efficiency and reduce energy loss—crucial for improving the overall efficiency of the ACS880-104 driver. This pre-matched integration eliminates compatibility risks between different components, simplifying installation and maintenance in industrial environments. The kit's robust design meets ABB's stringent quality standards, striking a balance between high power density (1200V/300A) and long-term durability to minimize downtime in critical production processes.

As the core power component of the ACS880-104 driver, the kit handles dynamic load adjustments through the stable current output of the IGBT, while the BGAD-22C adds real-time protection (overvoltage/overcurrent) to prevent transient failures. Whether applied in manufacturing, logistics, or process automation, it provides stable, high-performance power conversion for heavy industrial equipment.
Alternative Names
FS3OOR12OE4/BGAD-22C FS300RI2OE4/BGAD-22C FS300R1ZOE4/BGAD-ZZC FS300R12OE4/8GAD-22C FS300R12OE4/BGAD22C FS300R12OE4 BGAD-22C BGAD22C
