ABB 3BHE026284R0105 UAD215-A105, type UA D215 A105, is a 30 V, 1000 V converter signal interface board for UNL14300 power converters in UNITROL 6000 excitation systems.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 3BHE026284R0105 UAD215-A105
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3BHE026284R0105 UAD215-A105

  • Manufacturer:
    ABB
  • Part Number:
    3BHE026284R0105 UAD215-A105
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Converter Signal Interface Board
  • Stock:
    1
  • Functional abbreviation:
    CSI
  • Function:
    Converter Signal Interface
  • Documented voltage designation:
    30 V, 1000 V
  • Documented converter:
    UNL14300
  • System role:
    Internal converter interface board
  • A104 distinction:
    3BHE026284R0104, UA D215 A104, 30 V, 500 V
  • A106 distinction:
    3BHE026284R0106, UA D215 A106, 30 V, 1500 V
  • Adapter plate reference:
    3BHE051993R0001, separate UA D215-to-UA D209 adapter plate
  • Board type:
    UA D215 A105
  • Function:
    CSI Converter Signal Interface
  • Voltage designation:
    30 V, 1000 V
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Variant Matching System Integration Replacement Checks Application
  • Match the complete 3BHE026284R0105 UAD215-A105 identity, including ABB identification number 3BHE026284R0105 and official type UA D215 A105
  • Use this 30 V, 1000 V CSI only with the documented UNL14300 converter arrangement
  • Keep UA D215 A104, UA D215 A106 and the separate UA D215-to-UA D209 adapter plate distinct during replacement planning

3BHE026284R0105 UAD215-A105 is an ABB UNITROL 6000 converter signal interface board, officially styled UA D215 A105.

ABB identifies this exact A105 variant as the 30 V, 1000 V CSI for the UNL14300 power converter. It is an internal excitation-system interface board, not a complete controller or standalone power converter.

Before replacement, confirm the complete board marking, UNL14300 system configuration, connector and harness arrangement, required adapter hardware and approved maintenance procedure.

Availability, condition, price, and shipping time for 3BHE026284R0105 UAD215-A105 are confirmed during quotation.
