        • Lifecycle status

          Discontinued / Obsolete by OEM
          Apter Power offers rare ABB MOD 300 hardware to maintain your legacy plant platforms.

        PM510V08 3BSE008373R1

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The ABB PM510V08 3BSE008373R1 is the definitive Central Processing Unit (CPU) module designed exclusively for the Advant Controller 410/450 (AC 410 / AC 450) systems within the Advant OCS architecture.
        In Stock
        Ships by Friday, October 30
        Fast Shipping Available
        Get a quick price for PM510V08 3BSE008373R1
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for PM510V08 3BSE008373R1

        • Manufacturer:
          ABB
        • Part Number:
          PM510V08 3BSE008373R1
        • Product Family:
          ABB Advant OCS and Advant-800xA
        • Product Type:
          Central Processing Unit Module
        • Stock:
          11
        • Operating Temperature:
          0 °C to +55 °C
        • Programming Language Support:
          AMPL (Advant Master Programming Language)
        • Hardware Revision:
          Version 08 (Enhanced Memory/Stability Profile)
        • Primary Communication Profile:
          MasterBus 300 (MB 300) / Dedicated Subrack Bus
        • Cooling Profile:
          Passive / Natural Convection
        • On-Board Memory Capacity:
          8 MByte (RAM)
        • Weight:
          0.76 kg
        • Estimated shipping dimensions:
          3x33.5x30cm
        • Tariff Code:
          8537101190
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Applications Monitoring & Control Safety & Compliance

        Features:

        • Authentic Advant Controller 450 Backplane Architecture
        • High-Capacity Executive NVRAM with Parity Protection
        • Deterministic Real-Time LED Diagnostic Vector & Watchdog Integration
        The ABB PM510V08 3BSE008373R1 is precision-engineered exclusively for dedicated processing slots within the AC 450 subrack. It guarantees absolute electronic and mechanical alignment with the native Advant Master backplane, utilizing high-integrity bus transceivers to prevent signal attenuation and impedance mismatches during high-density data transfers across the controller chassis.

        Equipped with hardened, industrial-grade non-volatile memory (NVRAM) and battery-backed RAM modules, the ABB PM510V08 3BSE008373R1 ensures that volatile runtime elements—including AMPL application databases, system configuration parameters, tuned PID constants, and real-time event logs—remain completely intact and corruption-free during abrupt station power disruptions or full subrack power cycling.

        The front faceplate of the ABB PM510V08 3BSE008373R1 integrates a discrete matrix of hardware-driven physical LEDs mapping precise Run, Fault, Redundancy, and Maintenance flags. Operating independently of the main software execution loop, these indicators interface directly with the module's internal hardware watchdog timer, enabling plant maintenance technicians to execute instantaneous, low-level hardware status evaluations and fault isolation without needing to establish a software interrogation link via an engineering workstation.

        The PM510V08 3BSE008373R1 ABB Advant Controller 450 (AC 450) Processor Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        ABB PM510V08 3BSE008373R1 Advant Controller 450 (AC 450) Processor Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        ABB PM510V08 3BSE008373R1 Advant Controller 450 (AC 450) Processor Module

        General

        • Manufacturer ABB
        • Model PM510V08 3BSE008373R1
        • Condition New Original ready stock
        • Product Family PM510V16 3BSE008358R1,PM511V08 3BSE011180R1,PM511V16 3BSE011181R1
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Large-Scale Boiler & Turbine Automation: Within power generation facilities, the ABB PM510V08 3BSE008373R1 is deployed within AC 450 controllers to manage coordinated boiler-turbine controls, master pressure regulations, and balance-of-plant automation.
        • Continuous Distillation & Refining Processes: In petrochemical environments, the module executes multi-variable loops within the Advant OCS network, providing the precision required to stabilize temperature and feed fractions in distillation columns.
        • Pulp Digester & Paper Machine Coordination: The ABB PM510V08 3BSE008373R1 processes massive I/O points simultaneously, coordinating wet-end logic and multi-sectional motor drive communication lines in high-speed paper manufacturing lines.
        • Metal Rolling Mill Sequencing: Highly utilized in heavy metallurgy, the module handles high-speed logic calculations and millisecond-level reaction times needed for automatic gauge control (AGC) in modern rolling mills.
        • Deterministic Multi-Tasking Schedule: The ABB PM510V08 3BSE008373R1 segments control applications into prioritized cyclical tasks, ensuring safety-critical interlocks override background telemetry processing instantly.
        • Advanced S100/S800 I/O Management: Operating as the host processor, the ABB PM510V08 3BSE008373R1 scans distributed I/O racks, converting field electrical values into logical variables inside the AMPL execution table.
        • Redundant Processor Synchronization: In dual-processor configurations, the ABB PM510V08 3BSE008373R1 continuously mirrors its memory registers to the standby unit via the backplane, ensuring bumpless transfer if a failover triggers.
        • System Event Logging (Time-Stamping): The internal system clock of the ABB PM510V08 3BSE008373R1 logs alarms and system events with millisecond precision, enabling definitive sequence-of-events (SOE) tracking.
        • Industrial Electromagnetic Immunity: Enclosed in a custom-engineered Faraday shield, the ABB PM510V08 3BSE008373R1 is immune to electrostatic discharge (ESD) and high-frequency noise spikes prevalent in industrial motor control centers.
        • CE Compliance Directive Alignment: The module fulfills all structural mandates outlined by European CE low-voltage and electromagnetic compatibility directives for industrial control equipment.
        • Fail-Safe Output Interlocking: Upon discovering critical internal logic corrupted or a CPU trap failure, the ABB PM510V08 3BSE008373R1 immediately de-energizes its watchdog contact, instructing downstream I/O to assume predefined safe states.
        • Environmental Material Standard Verification: Constructed with heavy-duty, long-lifecycle substrates, the physical module design minimizes thermal degradation and satisfies baseline global compliance for industrial electronics waste.
        Description
        The ABB PM510V08 3BSE008373R1 functions as the primary execution engine inside Advant Controller 450 subracks. Unlike generic cross-platform components, this module is specifically hardwired to interface with the AC 450 backplane, providing full-scale execution of AMPL (Advant Master Programming Language) control programs and managing integrated S100, S600, or distributed S800 I/O clusters.

        Engineered for high-end process applications, the ABB PM510V08 3BSE008373R1 handles dense mathematical operations, complex regulatory control, and high-speed binary interlocking. Its dedicated processor architecture guarantees rigid scan-time intervals, eliminating jitters in high-priority PID loops and safety-critical sequences.

        Network integrity is a core capability of the ABB PM510V08 3BSE008373R1, which natively drives peer-to-peer communications over the MasterBus 300 (MB 300) network. This allows the host AC 450 controller to seamlessly sync databases, display process variables on Advant Station HMIs, and maintain structured interconnectivity across the plant-wide control topology.

        System resilience is reinforced via the internal self-diagnostics running continuously within the ABB PM510V08 3BSE008373R1. It monitors memory parity, system clock alignment, and subrack power rails; upon detecting an unrecoverable hardware fault, it executes an orderly switchover to a redundant processor configuration or initiates a safe-state shutdown.
        Alternative Names
        PM510V08 3BSE008373R1 PM51OVO8 3BSEOO8373R1 PM5I0V08 3BSE008373RI PM510V16 3BSE008358R1 PM511V08 3BSE011180R1 PM511V16 3BSE011181R1
        Technical notes
        The ABB PM510V08 3BSE008373R1 processor module must be loaded with system software compatible with your specific AC 450 controller firmware revision (e.g., QC01 or QC07) to avoid system initialization blocks. Prior to physical module extraction, verify that the controller's backup battery unit is fully functional to prevent volatile RAM application logic erasure.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Can the ABB PM510V08 3BSE008373R1 be dropped directly into an older MOD 300 SC controller subrack?
        No. The ABB PM510V08 3BSE008373R1 is a native processor module designed strictly for Advant Controller 410/450 racks within the Advant OCS ecosystem. While it communicates with MOD 300 nodes over a shared MasterBus 300 network, it is physically and architecturally incompatible with MOD 300 backplanes.
        How do you resolve firmware mismatch codes when initializing a replacement ABB PM510V08 3BSE008373R1 module in an existing AC 450 rack?
        The ABB PM510V08 3BSE008373R1 requires the correct system executive software to be loaded matching your node configuration. If a mismatch alarm occurs, you must clear the module's RAM, connect via the engineering tool (Advant Station 100 Series or Engineering Workplace), and reload the exact AMPL executive files corresponding to your running system version.
        Does the ABB PM510V08 3BSE008373R1 processor module support direct Ethernet-based TCP/IP communication from its onboard ports?
        No, the ABB PM510V08 3BSE008373R1 relies on proprietary backplane connections to handle specialized communication modules. For standard TCP/IP or Ethernet communication, the ABB PM510V08 3BSE008373R1 must interface with dedicated communication boards like the CS513 or CI543 within the AC 450 subrack.
        Does the ABB PM510V08 3BSE008373R1 carry direct ATEX ratings for deployment into explosive environments?
        No, the ABB PM510V08 3BSE008373R1 does not possess intrinsic safety certifications for direct exposure to hazardous areas. It must always be installed in a safe area enclosure (Class 1 Division 2 or unclassified zones), utilizing galvanic isolators or barriers for any wiring running into hazardous field environments.
