YPQ111A 61161007

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB YPQ111A 61161007 is a field expansion board providing reliable I/O control with watchdog and timeout functions for system stability.
Get a quick price for YPQ111A 61161007
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for YPQ111A 61161007

  • Manufacturer:
    ABB
  • Part Number:
    YPQ111A 61161007
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    61161007
  • Product Numbers:
    YPQ111A 61161007
  • Product Type:
    Extended I/O Board
  • Operating Voltage:
    24V DC (±15%)
  • Power Consumption:
    5W (typical)
  • Isolation:
    500V AC (field to logic)
  • Input Impedance:
    10kΩ (digital), 100kΩ (analog)
  • Operating Temperature:
    -25°C to +55°C
  • Storage Temperature:
    -40°C to +85°C
  • Humidity:
    5-95% RH (non-condensing)
  • Weight:
    0.32 kg
  • Estimated shipping dimensions:
    28x20.1x3.1cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The ABB YPQ111A 61161007 Expansion I/O Board is a highly reliable field expansion module that can be used with the YPP110A application controller or other I/O boards. For local I/O, the YPQ111A connects to the I/O bus via a 64-pin flat cable X1 interface and is powered by the I/O bus. It is compatible with the same APC applications used by the YPQ110A board, enabling flexible expansion.

The board features a software-configurable timeout function; if the I/O board does not update new data within the timeout period, the output will be reset. While this function is not implemented in the local I/O function elements, it can be used in remote I/O applications to enhance system security.

The YPQ111A is equipped with an onboard watchdog function. The microcontroller refreshes the watchdog every 100 milliseconds, and the watchdog timeout after reset is 1.6 seconds. If the watchdog signal disappears, all binary and analog outputs will fail, a red LED will illuminate, and the microcontroller will automatically reset, ensuring system stability. This module always requires a YPT111A connector board for connection to field instruments.
Alternative Names
YPQ111A 61161OO7 YPQIIIA 6II6I007 YPQIIIA 6II6IOO7 YPQ111A YPQIIIA 61161OO7 6II6I007 6II6IOO7 61161007
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does the YPQ111A 61161007 come with a warranty?
Yes, the YPQ111A 61161007 includes a free 1-year Apter Power warranty.
What is the supply voltage of the ABB YPQ111A 61161007?
24V DC (±15%).
What are the typical power consumption and isolation voltage of the module?
Typical power consumption is approximately 5W, providing 500V AC isolation protection.
Which I/O connection methods does the module support?
Connects to the I/O bus via a 64-pin flat cable X1 interface, requiring a YPT111A connector board for interfacing with field instruments.
