        TU835V1 3BSE013236R1

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB TU835V1 3BSE013236R1 is an extended 50 V S800 I/O module termination unit with eight channels, fused transducer-power terminals, ModuleBus continuity, and DIN-rail mounting.
        In Stock
        Ships by Friday, October 30
        Fast Shipping Available
        Get a quick price for TU835V1 3BSE013236R1
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for TU835V1 3BSE013236R1

        • Manufacturer:
          ABB
        • Part Number:
          TU835V1 3BSE013236R1
        • Product Family:
          ABB Advant OCS and Advant-800xA
        • Product Type:
          8-Channel 50 V Extended Module Termination Unit
        • Stock:
          1
        • Channels:
          Up to 8 I/O channels
        • Rated Voltage:
          50 V
        • Maximum Current per I/O Channel:
          2 A
        • Maximum Process-Connection Current:
          8 A
        • Process Connections:
          16 signal/channel terminals, 4 process power, 4 process power 0 V
        • Compatible I/O:
          AI810, AI815, AI845
        • I/O Architecture:
          Single
        • Process-Voltage Groups:
          2 individually isolated groups
        • Solid Wire Size:
          0.2–4 mm²
        • Stranded Wire Size:
          0.2–2.5 mm²; 24–12 AWG
        • Recommended Torque:
          0.5–0.6 N·m
        • Strip Length:
          7 mm
        • Dielectric Test Voltage:
          500 V AC
        • Mounting:
          Standard DIN rail, both directions
        • Protection Class:
          IP20
        • Operating Temperature:
          0 to +55 °C
        • Storage Temperature:
          -40 to +70 °C
        • Relative Humidity:
          5–95%, non-condensing
        • Dimensions:
          12.6 × 11.0 × 6.4 cm
        • Weight:
          0.26 kg
        • Tariff Code:
          8538900000
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Module Match Field Wiring Installation Application
        • Terminates up to eight field channels for selected S800 analog input modules
        • Distributes fused transducer power and two isolated process-voltage groups
        • Extends ModuleBus while providing mechanical module keying and DIN-rail grounding

        TU835V1 3BSE013236R1 is an ABB extended module termination unit for AI810, AI815, and AI845 installations.

        It combines field terminals, fused transducer-power outlets, process-power distribution, ModuleBus continuation, mechanical keying, and the physical seat for one I/O module.

        Successful replacement depends on the complete article, supported I/O type, key positions, terminal schedule, power grouping, grounding, and single-I/O system design.

        Availability, condition, price, and shipping time for TU835V1 3BSE013236R1 are confirmed during quotation.

        ABB TU835V1 3BSE013236R1 Module Termination Unit Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • Confirm the installed I/O is AI810, AI815, or AI845
        • Restore both mechanical keys to the approved positions
        • Use the complete TU835V1 and 3BSE013236R1 identity during selection
        • Map each signal, fused transducer supply, process power, and 0 V conductor
        • Keep the two process-voltage groups separated as shown in the official drawing
        • Apply the documented strip length, conductor size, and terminal torque
        • Lock the MTU to a grounded standard DIN rail
        • Check ModuleBus continuation and position signaling to the next MTU
        • Seat the keyed I/O module only after wiring and power-group verification
        • Field termination and transducer-power distribution for ABB AI810
        • Eight-channel field connection for ABB AI815 installations
        • Single-I/O termination for ABB AI845 where TU835V1 is specified
        Description
        TU835V1 3BSE013236R1 is an ABB extended module termination unit for selected S800 I/O analog input modules.

        It provides eight signal channels, fused transducer-power connections, process-power distribution, mechanical keying, and ModuleBus continuation to the next termination unit.

        Before installation, confirm AI810, AI815, or AI845 compatibility, mechanical-key positions, process-voltage grouping, conductor preparation, DIN-rail grounding, and the single-I/O architecture.
        Alternative Names
        TU835V1 3BSE013236R1 TU835V1 3BSE013236R1 ABB TU835V1 ABB 3BSE013236R1 ABB TU835V1 3BSE013236R1
        Technical notes
        TU835V1 3BSE013236R1 requires AI810, AI815, or AI845 compatibility, correct mechanical keys, process-power grouping, DIN-rail grounding, conductor torque, and single-I/O architecture; incorrect MTU selection prevents proper module insertion.
