ABB XO08R1 1SBP260101R1001 is an AC31 binary extension used to add eight relay output channels to compatible control hardware.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for XO08R1 1SBP260101R1001
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for XO08R1 1SBP260101R1001

  • Manufacturer:
    ABB
  • Part Number:
    XO08R1 1SBP260101R1001
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    8-Relay Binary Output Extension Module
  • Stock:
    1
  • Output Type:
    Relay binary outputs
  • Output Channels:
    8
  • Contact Rating:
    250 V AC, 2 A
  • Dimensions:
    6.5 × 9.3 × 8.45 cm
  • Module Power Supply:
    5 V DC supplied by the connected basic unit or extensible remote unit
  • Output Isolation Test Voltage:
    1500 V RMS for 1 minute
  • Output Groups:
    2 groups, arranged as 4 + 4 outputs
  • Total Output Capacity:
    8 × 2 A
  • Minimum Load:
    10 mA at 12 V DC
  • Breaking Capacity at 120 V AC:
    2 A
  • Breaking Capacity at 250 V AC:
    2 A; 1.5 A under UL rating
  • Resistive-Load Switching Rate:
    Less than 1 Hz
  • Inductive-Load Switching Rate:
    Less than 0.2 Hz
  • Lamp-Load Switching Rate:
    Less than 0.2 Hz
  • Mechanical/Electrical Endurance for AC-1 Loads:
    1,000,000 switching cycles
  • Endurance for AC-15 Loads:
    100,000 switching cycles
  • Maximum Unshielded Cable Length:
    150 m
  • Maximum Shielded Cable Length:
    500 m
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Diagnostics Integration Connection Application
  • Eight relay output channels
  • 250 V AC and 2 A ABB contact rating
  • AC31 extension reference 1SBP260101R1001

XO08R1 1SBP260101R1001 is an ABB binary output extension designed for compatible AC31 control hardware.

It adds eight relay-operated binary outputs and is identified in ABB's AC31 reference table by commercial reference 1SBP260101R1001.

Before installation or replacement, verify the host unit, extension interface, common grouping, connector wiring, load characteristics, and available mounting space.

Availability, condition, price, and shipping time for XO08R1 1SBP260101R1001 are confirmed during quotation.

ABB XO08R1 1SBP260101R1001 8-Relay Binary Output Extension Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Front panel provides status visualization for the relay output channels
  • AC31 diagnostics identify XO08R1 with unit type code 016
  • Diagnostic records identify the extension address and affected channel number
  • Designed as an AC31 binary extension
  • Used with compatible central or extensible remote units
  • Documented in an ICMK-CS31 replacement arrangement
  • Powered with 5 V by the connected AC31 basic unit or remote unit
  • Connected to the basic unit or remote unit through the cable on the left side of the extension
  • Relay output common terminals C are electrically independent
  • XO08R1 1SBP260101R1001 provides eight relay outputs for expanding compatible AC31 Series 40 and Series 50 basic units.
  • The module provides relay output expansion for centrally extensible AC31 remote units and is powered by the connected basic unit or remote unit.
  • ABB documents the module with ICMK-CS31 as a replacement configuration for ICSO 08 R1 installations requiring two independent output commons.
Description
XO08R1 1SBP260101R1001 is an ABB binary output extension for compatible AC31 control hardware.

The module provides eight relay output channels rated by ABB at 250 V AC and 2 A, with commercial reference 1SBP260101R1001.

Before installation or replacement, confirm the AC31 host, extension interface, two-common wiring arrangement where applicable, connector assignment, and actual load requirements.
Alternative Names
XO08R1 1SBP260101R1001 ABB XO08R1 1SBP260101R1001 XO08R1 XO 08 R1 ABB XO08R1 ABB XO 08 R1 1SBP260101R1001 ABB 1SBP260101R1001
Technical notes
ABB XO08R1 1SBP260101R1001 provides eight 250 V AC, 2 A relay outputs for compatible AC31 extension positions. For ICSO 08 R1 replacement, verify the ICMK-CS31 arrangement and two independent commons.
