  • Lifecycle status

    Active / Available from OEM
    Apter Power supports NPCI03 quotations, documentation review and cabinet-matching guidance.

NPCI03

/ 4.9
1001 reviews | Need a Specific Revision?
ABB Bailey NPCI03 is a Network 90 24 VDC I/O power supply with 120/240 VAC, 50/60 Hz, 530 VA input marking.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for NPCI03
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for NPCI03

  • Manufacturer:
    ABB
  • Part Number:
    NPCI03
  • Product Family:
    ABB Bailey
  • Product Type:
    Bailey Network 90 24 VDC I/O Power Supply
  • Stock:
    1
  • System family:
    Bailey Network 90
  • Product role:
    24 VDC I/O Power Supply
  • Input voltage:
    120/240 VAC
  • Input frequency:
    50/60 Hz
  • Input rating:
    530 VA
  • Referenced instruction:
    E93-909-5
  • Weight:
    11.08 kg
  • Estimated shipping dimensions:
    30 x 9.7 x 21.7 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Switzerland
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cabinet Integration AC Input Assembly Boundary Product Applications

Features:

  • Network 90 supply: Enclosure label identifies NPCI03 as a 24 VDC I/O power supply.
  • Dual-voltage input: Nameplate specifies 120/240 VAC at 50/60 Hz.
  • Declared load: Input apparent-power rating is 530 VA.
NPCI03 is a complete power-supply assembly for an installed Bailey Network 90 cabinet, not merely the rectifier mounted inside it.

The model label establishes the AC input options and product role while referring installation details to instruction E93-909-5.

Replacement work should match the full enclosure, input selection and cabinet wiring instead of sourcing by an internal component number.

Apter Power supports the ABB NPCI03 Bailey Network 90 24 VDC I/O Power Supply through quotations, label review and cabinet matching.
ABB NPCI03 Bailey Network 90 24 VDC I/O Power Supply Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Feed selection: Confirm the installed cabinet supply against the 120/240 VAC, 50/60 Hz nameplate options.
  • Assembly boundary: NPCI03 is the complete 24 VDC I/O power supply; the internal rectifier is only one component.
  • Connection check: Match the enclosure connectors and cabinet wiring using instruction reference E93-909-5 and the site drawings.
  • Voltage selections: Nameplate input is 120 or 240 VAC.
  • Frequency: Both 50 Hz and 60 Hz supplies are listed.
  • Apparent power: Input rating is 530 VA.
  • Commissioning limit: Verify the actual input selection and cabinet wiring before energization.
  • Complete item: NPCI03 refers to the enclosed Network 90 power-supply assembly.
  • Internal component: The photographed Acme rectifier is one internal device, not the public product model.
  • Output details: Do not transfer an internal component rating to the complete assembly without the circuit documentation.
  • Replacement scope: Match enclosure, connectors and cabinet wiring as a complete unit.
  • Network 90 I/O power: Maintains the 24 VDC I/O supply function in a confirmed NPCI03 cabinet position.
  • Legacy-system spare: Exact-model replacement for installed Bailey assemblies carrying the NPCI03 label.
  • Cabinet maintenance: Supports planned exchange where AC feed, connectors and mechanical fit have been checked.
  • Engineering limit: New installations require the complete instruction and site power-distribution design.
Description
In Bailey Network 90 cabinets, NPCI03 is the complete 24 VDC I/O power-supply assembly. Its function is stated directly on the enclosure, helping maintenance teams separate it from the internal rectifier and other cabinet power components.

The NPCI03 nameplate accepts 120 or 240 VAC at 50/60 Hz and lists 530 VA. Those input choices affect the cabinet feed and commissioning setup; the internal rectifier label does not replace the complete power-supply rating.

For a replacement NPCI03, match the enclosure, AC input selection, connectors and cabinet wiring to the removed unit. Treat the internal rectifier number as a component reference only, not an alternative model or a direct substitute for the Network 90 supply.
Alternative Names
NPCI-03 ABB NPCI03 Bailey NPCI03
Technical notes
Evidence is limited to the NPCI03 equipment nameplate and internal rectifier label. The enclosure label references product instruction E93-909-5; do not infer terminal assignments, output current or interchangeability without that instruction and the site drawings.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
A technician is preparing to reconnect NPCI03; which AC input options are shown on the enclosure?
The enclosure lists 120 or 240 VAC, 50/60 Hz and 530 VA input. Use instruction E93-909-5 and the site drawings to identify the actual tap and terminal arrangement before connection.
Does Acme PS-633534 identify the complete NPCI03 assembly?
PS-633534 identifies an internal Acme custom rectifier, not the complete Bailey enclosure. Keep NPCI03 as the product identity for quotation, receiving and system matching.
Can the internal rectifier’s 24 VDC, 10.9 A marking be used as the published NPCI03 output rating?
Treat 24 VDC at 10.9 A as an internal component marking only. It does not establish the complete assembly’s terminal rating without the Bailey instruction and circuit documentation.
Which installation document should control terminal work on NPCI03?
The enclosure names Bailey instruction E93-909-5. Use that instruction together with the site cabinet drawings; the visible labels alone do not define terminal assignments.
Does the 530 VA marking on NPCI03 define the complete Network 90 cabinet load?
The 530 VA figure belongs to this power-supply assembly, not the whole cabinet. Build the cabinet load calculation from every installed supply and module branch.
Can a purchasing team treat any 24 VDC supply as a direct replacement for NPCI03?
No. NPCI03 is a Network 90 I/O power-supply assembly with its own 120/240 VAC input, enclosure and cabinet interfaces. Match the exact model and installation documentation.
