        • Lifecycle

          Superseded
          Superseded in December 1998
          Original successor: C350
          Current replacement product: ControlMaster CM30

        C300/0010/STD

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB C300/0010/STD is a COMMANDER 300 universal process controller used for multi-input control, alarms and programmable ramp/soak processes.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for C300/0010/STD
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for C300/0010/STD

        • Manufacturer:
          ABB
        • Part Number:
          C300/0010/STD
        • Product Family:
          ABB Commander
        • Product Type:
          COMMANDER 300 Universal Process Controller
        • Stock:
          1
        • Analog Inputs:
          Three universal inputs
        • Input Types:
          Thermocouple, RTD, mV, current, DC voltage or resistance
        • Input Sampling Time:
          160 ms per channel
        • Input Impedance:
          mV: >10 MΩ; voltage: >500 kΩ; current: 10 Ω
        • Common-Mode Rejection:
          >140 dB
        • Series-Mode Rejection:
          >60 dB
        • Transmitter Power Supply:
          24 V DC at 30 mA
        • Isolated Current Output:
          0–20 or 4–20 mA; maximum load 750 Ω
        • Logic Output:
          12 V; minimum load 400 Ω
        • Relay Outputs:
          Two SPST relays
        • Ramp/Soak Capacity:
          30 segments across 9 programs
        • Power Supply:
          115 V AC ±15%, 50/60 Hz
        • Power Consumption:
          Less than 10 VA
        • Power Interruption Immunity:
          Less than 60 ms
        • Operating Temperature:
          0 to +55 °C
        • Operating Humidity:
          0 to 95% RH, non-condensing
        • Front Protection:
          IP66/NEMA 4X
        • Dimensions:
          9.6 × 9.6 × 24.0 cm
        • Self-Tuning:
          User-activated start-up or at-setpoint self-tuning with failure and caution diagnostics
        • Tariff Code:
          9032899099
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Input Assignment Program Control Output Integration Application
        • Three universal analog inputs for process and auxiliary signals
        • Configurable process control with isolated current, logic and relay outputs
        • Thirty ramp/soak segments distributed across nine stored programs

        C300/0010/STD is an ABB COMMANDER 300 controller configured for 115 V AC operation without an option board.

        Its multi-input architecture, control algorithms, alarm functions and stored programs support more complex single-loop process duties than a basic indicator-controller.

        Before installation or replacement, verify every input assignment, control algorithm, output scale, relay function, terminal connection, security setting and stored program.

        Availability, condition, price, and shipping time for C300/0010/STD are confirmed during quotation.

        ABB C300/0010/STD COMMANDER 300 Controller Manuals, Product Family, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • Configure each universal input for its thermocouple, RTD, analog or resistance signal
        • Assign the process variable, remote setpoint and auxiliary functions before loop tuning
        • Match engineering ranges, linearization and transmitter power to the connected devices
        • Arrange up to thirty ramp and soak segments across nine stored programs
        • Check segment targets, durations, linking and end actions before starting a sequence
        • Verify the program position and output state after any supply interruption
        • Scale the isolated current output for the selected control or retransmission function
        • Assign logic and relay outputs to the required control, alarm or valve duties
        • Do not configure communications or additional I/O that require an absent option board
        • Single-loop temperature, pressure, flow or level control in industrial processes
        • Heat/cool or motorized-valve control requiring several analog input assignments
        • Batch processes using multi-program ramp/soak profiles
        Description
        C300/0010/STD is an ABB COMMANDER 300 universal process controller with three analog inputs, standard /00 hardware and a 115 V AC power supply.

        The controller supports sensor and analog-process inputs, isolated current control, logic and relay outputs, alarms and up to thirty ramp/soak segments across nine programs.

        Before installation or replacement, confirm the complete C300/0010/STD order code, all input assignments, supply voltage, control algorithm, output scaling, alarms, terminal wiring, security settings and stored programs.
        Alternative Names
        C300/0010/STD C300 / 00 1 0 / STD ABB C300/0010/STD ABB Commander C300/0010/STD COMMANDER 300 C300/0010/STD
        Technical notes
        C300/0010/STD is the 115 V AC configuration without an option board. Verify input assignments, output scaling, alarm logic, terminal wiring and stored programs before replacement.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How can ABB C300/0010/STD use its three analog inputs in one control loop?
        ABB C300/0010/STD can assign its universal inputs to the process variable, remote setpoint or auxiliary functions supported by the selected control strategy. Confirm each input type, range and terminal connection before enabling the loop.
        Does ABB C300/0010/STD include an optional communications board?
        No. The /00 hardware identified in ABB C300/0010/STD specifies no option board, so optional communications or additional I/O must not be assumed.
        Which control strategies can ABB C300/0010/STD support?
        ABB C300/0010/STD supports configurable single-loop process control, including standard PID, heat/cool and motorized-valve arrangements when the required outputs and wiring are assigned correctly.
        How are ramp/soak programs organized in ABB C300/0010/STD?
        ABB C300/0010/STD supports up to thirty ramp/soak segments arranged across nine programs. Confirm segment targets, durations, linking and end actions before starting a production sequence.
        What must be checked before replacing ABB C300/0010/STD?
        Record all input types and ranges, the 115 V AC supply, control algorithm, output scaling, relay and alarm assignments, security settings, terminal wiring and stored programs before removing ABB C300/0010/STD.
        How should ABB C300/0010/STD be handled after a brief power interruption?
        After supply recovery, verify the process value, setpoint, program position and output state before returning ABB C300/0010/STD to automatic control, especially when the interruption approached the documented immunity period.
        Why can ABB C300/0010/STD display an unstable process value?
        Check the selected input type and linearization, sensor wiring, shielding, grounding, transmitter supply, engineering range and nearby electrical noise before replacing ABB C300/0010/STD.
