        • Lifecycle status

          Active / Available from OEM
          Apter Power supports quotations, ABB records, R4 cabinet checks, and protection review.

        ACS510-01-060A-4

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB ACS510-01-060A-4 is a 30 kW, 60 A, 380-480 V IP21 ACS510 wall-mounted drive in frame R4.
        In Stock
        Ships by Friday, October 30
        Fast Shipping Available
        Get a quick price for ACS510-01-060A-4
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for ACS510-01-060A-4

        • Manufacturer:
          ABB
        • Part Number:
          ACS510-01-060A-4
        • Product Family:
          ABB Drives
        • Product Type:
          ACS510 General Purpose Wall-Mounted Drive
        • Stock:
          1
        • ABB Product ID:
          3ABD00015752-D
        • Input Voltage:
          380 ... 480 V AC
        • Input Frequency:
          47.5 ... 63 Hz
        • Number of Phases:
          3-phase
        • Normal Output Current:
          60 A
        • Normal Output Power:
          30 kW
        • Apparent Power Output:
          42 kV·A
        • Frame Size:
          R4
        • Degree of Protection:
          IP21
        • Enclosure Type:
          NEMA Type 1
        • Mounting:
          Wall-mounted
        • Efficiency Level:
          IE2
        • Standby Loss:
          17 W
        • Temperature Rating:
          40 °C
        • Built-in Communication:
          Modbus
        • Weight:
          22.5 kg
        • Estimated shipping dimensions:
          25.7 x 72.3 x 30.6 cm
        • Tariff Code:
          85044099
        • Country of origin:
          China
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications R4 Cabinet Protection Network Control

        Features:

        • 30 kW normal-use rating with 60 A output
        • R4 IP21 wall-mounted mechanical format
        • Documented 280 m³/h cooling-air demand
        ACS510-01-060A-4 is the 60 A R4 configuration for 30 kW applications.

        The larger power stage can coordinate process speed and status with plant control systems, but requires deliberate electrical, thermal, mechanical, and communication integration.

        Engineering release should follow a feeder and cable study, R4 mounting and cooling review, motor and stopping calculations, signal and Modbus ownership, safe commissioning, and maintainable access planning.

        Availability is subject to Apter Power's current inventory and sourcing confirmation.
        ABB ACS510-01-060A-4 ACS510 General Purpose Wall-Mounted Drive Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        ABB ACS510-01-060A-4 ACS510 General Purpose Wall-Mounted Drive Specs

        General

        • ManufacturerABB
        • ModelACS510-01-060A-4
        • ConditionNew Original ready stock
        • Product FamilyABB ACS510 Drives
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Mechanical and cooling layout

        • Mounting: Confirm wall or panel support, fasteners, orientation, and access route.
        • Airflow: Provide the documented cooling volume without hot-air recirculation.
        • Cable space: Reserve bend radius, support, terminal, and cover-removal clearances.
        • Service: Keep fans, panel, power terminals, and communication hardware reachable.

        30 kW electrical coordination

        • Fault current: Use the site study when selecting the isolation and protective devices.
        • Fuse basis: Coordinate the published IEC value with conductor and local-code limits.
        • Motor cable: Review length, voltage drop, shielding, insulation, and output switching.
        • PE system: Verify protective-earth conductors, bonding, and shield terminations.

        Modbus command boundaries

        • Master design: Document the controller, polling, addresses, serial settings, and termination.
        • Authority: Define how network, terminals, and panel control transfer safely.
        • Timeout: Specify stop, alarm, or fallback behavior for communication loss.
        • Evidence: Retain mapping, accepted tests, firmware, and parameter backup.
        Description
        ACS510-01-060A-4 introduces the R4 ACS510 mechanical group with a 30 kW normal-use rating and 60 A output for 380-480 V motor systems.

        ACS510-01-060A-4 integrates variable-speed motor control, plant signals, relay feedback, local setup, and Modbus communication for larger pump, fan, conveyor, and process-support duties.

        ACS510-01-060A-4 must be treated as an R4 cabinet project with planned protection and isolation, large-conductor terminations, heat removal, mounting and service access, motor and braking duty, control hierarchy, fault recovery, and witnessed commissioning.
        Alternative Names
        ACS510 01 060A 4 ACS51001060A4 3ABD00015752-D ABB ACS510-01-060A-4 ABB 3ABD00015752-D ACS510 30 kW drive 60 A R4 wall-mounted drive ABB general purpose drive 30 kW
        Technical notes
        ACS510-01-060A-4 uses frame R4 and dissipates 907 W with a documented 280 m³/h cooling-air requirement. Before panel release, verify the 60 A motor duty, 63 A IEC fuse basis, isolation and cable study, R4 mounting and service clearances, airflow without recirculation, external braking arrangement, Modbus authority, and controlled loaded-test plan.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Which mechanical checks are specific to ACS510-01-060A-4 frame R4?
        Confirm support and mounting, access route, cable-entry and bend space, terminal and fan service, door interference, and an airflow path for the documented 280 m³/h requirement. The 60 A R4 installation should not inherit an R3 layout without a new mechanical and cooling review.
        How should the 63 A protection basis be coordinated for ACS510-01-060A-4?
        ACS510-01-060A-4 combines a 60 A output rating with an official 63 A IEC fuse basis. Use site fault current, isolation equipment, conductor thermal and short-circuit limits, installation method, voltage drop, PE design, and discrimination to complete the R4 feeder study.
        Why can the ACS510-01-060A-4 enclosure overheat after filters are installed?
        ACS510-01-060A-4 dissipates 907 W and requires 280 m³/h cooling airflow. Check filter pressure drop and contamination, fan direction and performance, recirculation, inlet and outlet area, ambient temperature, neighboring heat sources, and derating so the filter does not remove the required thermal margin.
        Can ACS510-01-060A-4 control a high-inertia 30 kW fan?
        Evaluate motor current against 60 A, the fan curve, inertia, acceleration and deceleration, current limits, minimum speed, resonant zones, coast or external-braking strategy, R4 cooling, and process risk. The 30 kW nameplate alone does not establish suitable starting or stopping duty.
        What should be captured after repeated Modbus timeouts on ACS510-01-060A-4?
        For ACS510-01-060A-4, preserve event timing, command source, 60 A load condition, and configured timeout response before inspecting topology, shielding, grounding, termination, baud and parity, duplicate addresses, master polling, electrical noise, and controller load. This links network faults to the actual operating state.
        Which quotation records distinguish ACS510-01-060A-4?
        Include ACS510-01-060A-4, Product ID 3ABD00015752-D, the 30 kW and 60 A duty, 63 A fuse basis, 907 W losses, R4 cabinet plan, motor and cable data, braking and network scope, quantity, destination, inspection, and delivery requirements.
