BINT-12C

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB BINT-12C is a highly isolated, multi-functional analog signal MC interface board with strong environmental adaptability and seamless integration with ABB systems.
Get a quick price for BINT-12C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for BINT-12C

  • Manufacturer:
    ABB
  • Part Number:
    BINT-12C
  • Product Family:
    ABB Drives
  • Analog signals:
    0-10V/4-20mA
  • Isolation Voltage:
    2500V AC
  • Control Voltage:
    24V DC ±10%
  • Operating Temperature:
    -25°C to +70°C
  • Storage Temperature:
    -40°C to +85°C
  • Relative Humidity:
    5% to 95% non-condensing
  • Weight:
    0.12 kg
  • Estimated shipping dimensions:
    15x10.5x3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The ABB BINT-12C MC interface board is a critical signal conversion and transmission hub in industrial automation systems, specifically designed to process analog signals from ABB drives and control units. It is compatible with 0-10V voltage signals and 4-20mA current signals, allowing for flexible connection of various field sensors (such as pressure sensors, temperature transmitters, and flow meters) to the main control system. This broad signal support eliminates the need for additional signal converters, simplifying system architecture and reducing deployment costs.

A key feature of the BINT-12C is its 2500V AC isolation voltage, effectively preventing electromagnetic interference (EMI) and voltage surges common in industrial environments. This isolation ensures accurate and distortion-free transmission of analog signals, avoiding control errors that could lead to equipment failure or production interruptions. The board requires 24V DC ±10% for control voltage and is optimized for standard industrial power supplies, ensuring stable operation even with slight fluctuations in factory grid voltage.

The BINT-12C is designed with environmental adaptability in mind, operating from -25°C to +70°C, covering extreme cold and high temperature industrial environments, suitable for everything from cold storage facilities to high-temperature manufacturing workshops. Its storage temperature range of -40°C to +85°C ensures component integrity during long-distance transport or long-term storage. Furthermore, the board can withstand non-condensing relative humidity from 5% to 95%, making it suitable for humid environments such as chemical plants and coastal factories when properly ventilated. As an original ABB component, it integrates seamlessly with ABB drive systems, ensuring reliable communication and simplifying maintenance.
Alternative Names
B1NT-12C 8INT-12C BINT-I2C BINT12C B1NT12C 8INT12C BINTI2C
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the operating temperature range of the ABB BINT-12C?
It can operate reliably in a temperature range of -25°C to +70°C, suitable for harsh industrial environments.
What control voltage does the ABB BINT-12C MC interface board require?
It uses a 24V DC control voltage with a tolerance of ±10%, accommodating slight power supply fluctuations.
Is the ABB BINT-12C MC interface board a brand new original product?
Of course, all our products are 100% brand new and original.
What is the isolation voltage of the ABB BINT-12C interface board?
It has a high isolation voltage of 2500V AC, ensuring safe signal transmission in industrial environments.
How long does it take to receive my ABB BINT-12C order?
This interface board is in stock. We will arrange shipment within 2-3 business days after order confirmation.
What analog signals does the ABB BINT-12C MC interface board support?
It is compatible with 0-10V voltage signals and 4-20mA current signals, suitable for industrial control.
Does the ABB BINT-12C come with a warranty?
Yes, brand new ABB BINT-12C MC interface boards come with a one-year standard warranty covering manufacturing defects.
