RMIO-02C

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB RMIO-02C is a high-precision motor control & I/O board for ACS800 drives, integrating robust isolation, versatile signal handling, and reliable communication.
Get a quick price for RMIO-02C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for RMIO-02C

  • Manufacturer:
    ABB
  • Part Number:
    RMIO-02C
  • Product Family:
    ABB Drives
  • Isolation test voltage:
    500VAC, 1 min
  • Max. common mode voltage between the channels:
    ±15 VDC
  • Common mode rejection ratio:
    > 60 dB at 50 Hz
  • Resolution:
    0.025% (12-bit) for the -10 V ... +10 V input. 0.5% (11-bit) for the 0 ... +10 V and 0 ... 20 mA inputs.
  • Inaccuracy:
    ±0.5% (Full Scale Range) at 25 °C (77 °F).
  • Temperature coefficient:
    ± 100ppm/°C (±56ppm/°F), max.
  • Maximum load:
    10 mA
  • Applicable potentiometer:
    1 kohm to 10 kohm
  • Input current:
    DI1 to DI 5: 10 mA, DI6: 5 mA
  • Logical thresholds:
    < 8 V DC “0”, > 12 V DC “1”
  • Filtering time constant:
    1 ms
  • Switching capacity:
    8 A at 24 V DC or 250 V AC, 0.4 A at 120 V DC
  • Minimum continuous current:
    5 mArms at 24 VDC
  • Maximum continuous current:
    2Arms
  • Isolation test voltage:
    4kVAC, 1 minute
  • Voltage:
    24 VDC ± 10%
  • Typical current consumption (without optional modules):
    250 mA
  • Maximum current consumption (with optional modules inserted):
    1200 mA
  • Weight:
    0.18 kg
  • Estimated shipping dimensions:
    24.2x10x1.7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The ABB RMIO-02C Motor Control & I/O Board is a core component engineered for ABB ACS800 series AC drives (Frame S2-S6), serving as the central hub for motor control logic, I/O signal processing, and system communication.   It combines precise signal measurement with robust electrical protection, featuring an isolation test voltage of 4kVAC (1 minute) between power and control circuits, and 500VAC (1 minute) for signal isolation, ensuring safety in industrial environments.

Equipped with 8 digital inputs (DI1-DI5: 10mA; DI6: 5mA) and 4 digital outputs (8A at 24VDC/250VAC), the board supports flexible I/O integration with logical thresholds of <8VDC ("0") and >12VDC ("1") and a 1ms filtering time constant.   Analog inputs offer tailored resolution: 0.025% (12-bit) for -10V~+10V, and 0.5% (11-bit) for 0~10V/0~20mA, with ±0.5% FSR inaccuracy at 25°C and a maximum temperature coefficient of ±100ppm/°C.   It operates on 24VDC ±10% power, with a typical current consumption of 250mA (without optional modules) and 1200mA max (with modules), plus compatibility with 1kΩ~10kΩ potentiometers and a 10mA maximum input load
Alternative Names
RMI0-02C RMIO-O2C RM1O-02C RMIO02C RMI002C RMIOO2C RM1O02C
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the maximum common mode voltage?
The maximum common mode voltage between channels is ±15 V DC.
What is the common mode rejection ratio (CMRR)?
CMRR is greater than 60 dB at 50 Hz.
What is the resolution of the analog inputs?
Resolution is 12-bit (0.025%) for –10 V…+10 V inputs, and 11-bit (0.5%) for 0…10 V and 0/4–20 mA inputs.
What is the accuracy of the board?
Inaccuracy is ±0.5% of full scale at 25 °C, with a temperature coefficient of ±100 ppm/°C.
What are the digital input characteristics?
DI1–DI5: 10 mA; DI6: 5 mA. Logical thresholds: <8 V DC = “0”, >12 V DC = “1”. Filtering time constant is 1 ms.
What is the switching capacity of relay outputs?
Relay outputs can switch 8 A at 24 V DC or 250 V AC, 0.4 A at 120 V DC. Minimum continuous current is 5 mA, maximum 2 A.
