The ABB SAFT167APC SAFT-167-APC is a APC Power Connection II board engineered for heritage ABB Stromberg drive and industrial inverter systems, delivering optimized gate control power distribution and absolute signal integrity.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for SAFT167APC SAFT-167-APC
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SAFT167APC SAFT-167-APC

  • Manufacturer:
    ABB
  • Part Number:
    SAFT167APC SAFT-167-APC
  • Product Family:
    ABB Drives
  • Product Type:
    Power Connection Board
  • Stock:
    1
  • Primary Function:
    Gate Drive Power Supply Distribution & Signal Coupling
  • Rated Bus Input Voltage:
    24 VDC
  • Board Material:
    High-Tg Flame Retardant FR4 with Anti-Corrosive Coating
  • Mounting Architecture:
    Direct Chassis-Rack Multi-pin Slot / Standoff Integrated
  • Cooling Requirements:
    Forced Air (Integrated within the main Drive Enclosure air stream)
  • Dielectric Strength:
    ≥ 2.5 kV AC
  • Operating Temperature:
    -10°C to +60°C (with standard power derating above 40°C)
  • Storage Temperature:
    -40°C to +85°C
  • Relative Humidity:
    5% to 95%, non-condensing
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    7.6x15.2x2.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Features:

  • Proprietary POW.CONN.II High-Density Power Routing
  • Robust Electromagnetic Compatibility (EMC) Shielding Layer
  • Plug-and-Play Footprint for Fast Mean-Time-To-Repair (MTTR)
The ABB SAFT167APC SAFT-167-APC employs advanced Power Connection II proprietary layout metrics that dramatically lower parasitic inductance across control rails, guaranteeing uniform gate-firing voltages to multi-phase phase modules.

Built with a specialized ground-plane configuration, the ABB SAFT167APC SAFT-167-APC effectively shields vulnerable logic control circuitry from the severe electromagnetic interference (EMI) typical of heavy-duty industrial megawatt-class inverters.

Featuring strict physical dimensions and high-retention slot pins, the ABB SAFT167APC SAFT-167-APC slides directly into existing chassis slots, cutting troubleshooting time down to minutes and preventing wiring errors under pressure.

The SAFT167APC SAFT-167-APC ABB APC Power Connection Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SAFT167APC SAFT-167-APC APC Power Connection Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB SAFT167APC SAFT-167-APC APC Power Connection Board

General

  • Manufacturer ABB
  • Model SAFT167APC SAFT-167-APC
  • Condition New Original ready stock
  • Product Family SAFT185TBC SAFT 185 TBC 58119687,SAFT132CBS SAFT 132 CBS 57411619,SAFT121PAC SAFT 121 PAC
