        DAI05 0336025MR

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB DAI05 0336025MR is a 16-channel 4–20 mA analog input module that powers two-wire transmitters, supervises line breaks and isolates two eight-channel groups in Freelance rack systems.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for DAI05 0336025MR
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for DAI05 0336025MR

        • Manufacturer:
          ABB
        • Part Number:
          DAI05 0336025MR
        • Product Family:
          ABB H&B Freelance 2000
        • Product Type:
          16-Channel 4–20 mA Two-Wire Transmitter Input Module
        • Stock:
          1
        • Input Channels:
          16
        • Input Range:
          4–20 mA
        • Standard Input Impedance:
          250 Ω
        • Transmitter Type:
          Two-wire
        • Transmitter Supply:
          14–24 V DC
        • Transmitter Current Limit:
          40 mA
        • External Supply:
          24 V DC nominal, 18–32.5 V DC operating range
        • Channel Grouping:
          Two groups of eight
        • Self-Scan Cycle:
          10 ms or slower
        • Resolution:
          12 bit
        • Least Significant Bit:
          5 µA
        • Maximum Cable Length:
          1,000 m
        • Hot Insertion:
          Unrestricted
        • Rack Power Consumption:
          2.4 W
        • Maximum External Power:
          24 W
        • Dimensions:
          4 × 18.5 × 31 cm
        • Weight:
          1.8 kg
        • Tariff Code:
          8538900000
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Loop Supply Acquisition Fault Handling Application
        • Sixteen 4–20 mA inputs for two-wire transmitters
        • Integrated 14–24 V DC transmitter supply with 40 mA limiting
        • Two isolated channel groups with line-break supervision

        DAI05 0336025MR is an ABB analog input module designed to acquire and power sixteen two-wire 4–20 mA transmitters in Freelance racks.

        It combines loop supply, 250-ohm inputs, 12-bit conversion and channel fault indication while separating the inputs into two optocoupler-isolated groups.

        Before installation or replacement, verify external supply voltage, loop polarity, transmitter burden, group commons, cable voltage drop, scaling and process interlocks.

        Availability, condition, price, and shipping time for DAI05 0336025MR are confirmed during quotation.

        ABB DAI05 0336025MR 16-Channel 4–20 mA Two-Wire Transmitter Input Module Manuals and Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • Each two-wire transmitter receives a 14–24 V DC loop supply
        • The transmitter supply is current-limited to 40 mA
        • The external source must remain within 18–32.5 V DC
        • Each 4–20 mA input uses a standard 250-ohm impedance
        • 12-bit conversion provides a 5-microampere least significant bit
        • The self-scan cycle is 10 milliseconds or slower
        • Line-break monitoring supervises each transmitter loop
        • Sixteen red indicators identify channel threshold or fault conditions
        • Current limiting separates abnormal loop demand from normal 4–20 mA operation
        • Powered acquisition of sixteen two-wire 4–20 mA field transmitters
        • Supervised process-current loops requiring individual fault indication
        • Grouped analog acquisition in ABB Freelance rack systems
        Description
        DAI05 0336025MR is an ABB 16-channel 4–20 mA analog input module for powered two-wire transmitters in Freelance rack systems.

        The module provides 14–24 V DC transmitter supply with 40 mA current limiting, groups the inputs into two isolated sets of eight, and uses 12-bit conversion with line-break supervision.

        Before installation or replacement, confirm the external supply, loop polarity, transmitter load, group commons, 4–20 mA scaling, cable shield and rack power budget.
        Alternative Names
        DAI05 DAI 05 ABB DAI05 ABB DAI 05 0336025MR DAI05 0336025MR ABB DAI05 0336025MR
        Technical notes
        DAI05 0336025MR requires confirmation of the 18–32.5 V external supply, loop polarity, two-wire transmitter burden, grouped commons and 4–20 mA scaling; wiring errors can current-limit multiple field loops.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Can DAI05 0336025MR directly replace a passive current-input module?
        Not without checking the loop design. DAI05 0336025MR supplies two-wire transmitters, so confirm whether the existing loop expects module-provided power, the polarity and the transmitter burden before transferring wiring.
        Why can all DAI05 0336025MR transmitter loops remain dead after an otherwise correct module replacement?
        DAI05 0336025MR depends on an external DC source for transmitter power. Check the external supply at the module under load, its polarity, protection and common connections before blaming the field transmitters.
        How does DAI05 0336025MR protect a transmitter loop from excessive current?
        The transmitter supply is current-limited to 40 mA. If a loop reaches the limit, inspect wiring, polarity and the field transmitter instead of treating it as a normal process signal.
        Why might eight DAI05 0336025MR channels fail together while the other eight continue operating?
        The sixteen channels are arranged as two isolated groups of eight. Inspect the failed group's supply and common wiring before replacing the module or disturbing transmitters in the healthy group.
        How can a technician distinguish a broken DAI05 0336025MR loop from a genuine low process value?
        Use the individual channel indication together with a loop-current measurement and transmitter-power check. DAI05 0336025MR provides line-break supervision, so an open or unpowered loop should not be treated as normal process minimum.
        Why can a correctly wired DAI05 0336025MR transmitter under-range on a long cable run?
        Cable voltage drop can reduce the transmitter's available supply margin even within the documented distance limit. Check loaded loop voltage, transmitter burden, cable resistance and shield routing at the actual installation.
        Can DAI05 0336025MR be replaced with the rack energized?
        ABB marks hot insertion as unrestricted, but the external transmitter supply and live process loops remain present. Apply site safety procedures and control the process effect before removal.
