    Apter Power offers legacy ABB field controller electronics to sustain system network uptime seamlessly.

SA801F 3BDH000011R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB SA801F 3BDH000011R1 is a power supply module that provides 115/230 VAC power for the FieldController and must be installed in slot P, the first slot on the left side of the basic unit.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for SA801F 3BDH000011R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SA801F 3BDH000011R1

  • Manufacturer:
    ABB
  • Part Number:
    SA801F 3BDH000011R1
  • Product Family:
    ABB H&B Freelance 2000
  • Product Type:
    Power Supply Module
  • Stock:
    3
  • Voltage:
    115-230 VAC
  • Frequenz:
    60-50 Hz
  • Leistung / power:
    max. 48 VA
  • Class of equipment:
    II
  • Weight:
    0.39 kg
  • Estimated shipping dimensions:
    12.5x8.2x3.6cm
  • Tariff Code:
    2942000000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Efficiency Standards Application Scenarios

Features:

  • Provides the required operating power for FieldController basic units using standard 115/230 VAC supplies.
  • Supports both 50 Hz and 60 Hz power networks, enabling flexible deployment across different industrial installations.
  • Incorporates Class II equipment design for dependable operation within industrial automation environments.
ABB SA801F 3BDH000011R1 serves as a fundamental component within the FieldController architecture, supplying the electrical power necessary for controller operation. Reliable power delivery is critical for maintaining stable automation processes, and the module fulfills this requirement through direct connection to standard AC power systems. The compact design allows seamless integration into the controller base unit.

In automation facilities, ABB SA801F 3BDH000011R1 helps establish a dependable foundation for process control functions. By supporting both 115 VAC and 230 VAC input voltages, the module can accommodate a variety of plant power infrastructures. Compatibility with 50 Hz and 60 Hz networks further increases installation flexibility across global industrial applications.

ABB SA801F 3BDH000011R1 is particularly suitable for process industries, manufacturing facilities, and distributed control environments that utilize FieldController technology. Placement in the dedicated slot P position ensures correct system configuration and efficient power distribution. Combined with its maximum 48 VA power rating and Class II construction, the module provides a practical and reliable power solution for everyday control system operation.

The SA801F 3BDH000011R1 ABB Power Supply Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SA801F 3BDH000011R1 Power Supply Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB SA801F 3BDH000011R1 Power Supply Module Specs

General

  • Manufacturer ABB
  • Model SA801F 3BDH000011R1
  • Condition New Original ready stock
  • Product Family SA811F,SA801FR,SA811FR
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • High-frequency switching technology achieves a full-load overall conversion efficiency of over 90%.
  • Optimized heat loss of internal components under no-load standby conditions.
  • Ultra-low heat generation significantly extends the lifespan of other components in the cabinet.
  • Built-in active power factor correction circuit maximizes energy utilization efficiency.
  • Fully compliant with IEC 61131-2 standards for control power supplies.
  • Meets stringent EN 61000-6-4 industrial-grade electromagnetic radiation and immunity requirements.
  • ATEX Area 2 certified for safe deployment in potentially explosive gas environments.
  • Overall manufacturing process and internal components strictly adhere to EU RoHS environmental standards.
  • Deployed as the main power supply for AC 800F controller racks in medium-sized DCS systems.
  • Distributed power supply panels suitable for onshore oilfields and long-distance monitoring stations along oil pipelines.
  • Deployed in high-precision aseptic batching control systems that meet GMP cleanliness requirements.
  • Widely used inside the core control cabinets of clinker sintering kilns in dusty and high-vibration environments.
Description
ABB SA801F 3BDH000011R1 is a dedicated power supply module used within the FieldController system. The module delivers the required operating power from a 115/230 VAC supply and forms an essential part of the controller infrastructure. Installation of the module is mandatory in every basic unit, where it is mounted in slot P, located on the far left side of the base unit.

Designed to operate with input voltages of 115 to 230 VAC and frequencies of 50 to 60 Hz, ABB SA801F 3BDH000011R1 provides a stable power source for FieldController applications. With a maximum power consumption of 48 VA and equipment Class II construction, the module supports reliable operation while meeting the electrical requirements of the control platform. Its purpose is to ensure continuous power delivery to the controller environment and connected automation functions.

ABB SA801F 3BDH000011R1 belongs to a family of FieldController power supply modules that also includes the SD 802F version for 24 VDC and redundant power supply applications. While SD 802F is intended for installations requiring enhanced power availability, ABB SA801F 3BDH000011R1 serves as the standard AC-powered solution for systems operating from common industrial mains supplies. The module is widely used in process automation and control installations where dependable controller power is required for daily operation.
Alternative Names
SA8O1F 3BDHOOOO11R1 SA80IF 3BDH0000IIRI SA 801F 3BDH000011R1 SA811F SA801FR SA811FR SD802F
Technical notes
The ABB SA801F (3BDH000011R1) is a high-efficiency power supply module designed for Freelance AC 800F systems, delivering stable 24V DC output with over 90% energy conversion efficiency. It effectively minimizes thermal load within dense control enclosures to prolong component lifespan.
