    Minimize operational downtime for your ABB equipment by utilizing this verified spare part, provided by Apter Power to ensure continued reliability for your facility's core electronics.

HEIA303892R1 ED1251A

/ 4.9
1001 reviews | Need a Specific Revision?
ABB HEIA303892R1 ED1251A PC board serves as the embedded controller of the ABB Procontic industrial automation control system, executing logic control, communication coordination, timing, counting, and arithmetic operations.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for HEIA303892R1 ED1251A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for HEIA303892R1 ED1251A

  • Manufacturer:
    ABB
  • Part Number:
    HEIA303892R1 ED1251A
  • Product Family:
    ABB Procontic
  • Product Type:
    PC Board
  • Stock:
    1
  • Power Supply Voltage:
    5V DC
  • Operating Current:
    Less than 1.5 A
  • Electrical Isolation:
    500V AC
  • Operating Temperature:
    0 °C to +55 °C
  • Storage Temperature:
    -25 °C to +70 °C
  • Relative Humidity:
    5% to 95% (non-condensing)
  • Protection Rating:
    IP00 (must be installed in a control cabinet)
  • Baseboard Material:
    FR-4 flame-retardant fiberglass PCB
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    1.5x20x30.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Logic Control Application Scenarios System Configuration

Features:

  • Performs logic control, timing, counting, arithmetic processing, and I/O communication coordination within ABB Procontic systems.
  • Designed for industrial reliability with 500 V AC electrical isolation and enhanced resistance to electromagnetic interference.
  • FR-4 flame-retardant PCB construction supports stable operation from 0 °C to +55 °C and installation inside industrial control cabinets.
ABB HEIA303892R1 ED1251A is an embedded control PC board developed for the ABB Procontic industrial automation control system. As the central processing unit of the control platform, it manages essential automation tasks while coordinating communication among distributed I/O modules. This capability enables reliable control of industrial production processes requiring continuous operation.

Powered by 5 V DC with an operating current below 1.5 A, ABB HEIA303892R1 ED1251A combines efficient electrical performance with dependable operation. Electrical isolation of 500 V AC enhances system safety, while the operating and storage temperature ranges support installation in demanding industrial environments. The board also accommodates relative humidity from 5% to 95% without condensation.

Manufactured using an FR-4 flame-retardant fiberglass PCB, ABB HEIA303892R1 ED1251A offers the durability expected in industrial automation equipment. The hardware is intended for installation inside a control cabinet because of its IP00 protection rating. Typical applications include early-generation factory automation, power industry control systems, and process control installations using the ABB Procontic platform.

The HEIA303892R1 ED1251A ABB PC Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB HEIA303892R1 ED1251A PC Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB HEIA303892R1 ED1251A PC Board Specs

General

  • Manufacturer ABB
  • Model HEIA303892R1 ED1251A
  • Condition New Original ready stock
  • Product Family HEDT300254R1 ED1790,HEDT300272R1 ED1782,HEDT300813R1 ED1633
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Scanning Mechanism: Employs a classic cyclic scan working mode; the control cycle depends on the logical complexity of the user program block.
  • Instruction Processing: The hardware integrates a high-efficiency microcontroller core, specifically designed to accelerate bit, byte, and word-level industrial Boolean logic instructions.
  • Interrupt Trigger: Equipped with a high-priority hardware interrupt input interface, it can latch sudden emergency signals and immediately jump to the interrupt control program.
  • Clock Synchronization: The module integrates a hardware real-time clock (RTC) generator, providing a high-precision time stamp for the event sequence recording of the entire PLC system.
  • Power Automation: Widely used in the excitation control systems of generator sets in early small and medium-sized substations and hydropower stations, as well as in the logic protection of high-voltage switchgear.
  • Metallurgical Blast Furnaces: Deployed in the automated sequential control logic of material conveyor belts and blast furnace batching systems in steel plants and non-ferrous metal smelters.
  • Water Treatment Plants: Commonly used in the automated control of urban sewage treatment and large industrial water pumping stations, realizing the interlocking start/stop and flow regulation of multiple pump sets.
  • Papermaking Machinery: Suitable for tension control and multi-stage speed coordination control of transmission systems in papermaking production lines, ensuring smooth operation of the continuous winding process.
  • Address Allocation: Hardware addressing is performed via onboard micro-DIP switches, allowing manual configuration of the unique slot number within the Procontic rack.
  • Storage Image: An EPROM chip with a specific version of the bootloader is embedded, supporting dynamic loading of runtime configurations into the RAM area via the bus.
  • Topology: The underlying hardware adopts a master-slave architecture, allowing configuration into a multi-processor collaborative working mode within a single rack.
  • Communication Mapping: Supports direct mapping of physical I/O channel register addresses to the processor core memory area, simplifying the hardware and software coupling configuration of variables.
Description
ABB HEIA303892R1 ED1251A is a PC board developed for the ABB Procontic industrial automation control system. Acting as the core controller of the system, it performs logic control, timing, counting, and arithmetic operations required for reliable industrial process automation. The board also coordinates communication between multiple I/O modules, ensuring efficient data exchange throughout the control system.

Operating from a 5 V DC power supply with an operating current of less than 1.5 A, ABB HEIA303892R1 ED1251A is engineered for dependable industrial performance. The board provides 500 V AC electrical isolation to improve system protection and operates within a temperature range of 0 °C to +55 °C. Storage temperatures from -25 °C to +70 °C and a relative humidity range of 5% to 95% (non-condensing) support long-term reliability under demanding environmental conditions.

Built on an FR-4 flame-retardant fiberglass PCB, ABB HEIA303892R1 ED1251A offers the durability required for industrial control applications. The hardware is designed to withstand electromagnetic interference while maintaining stable operation in harsh industrial environments. With an IP00 protection rating, the board is intended for installation inside a control cabinet and is widely applied in early large-scale factories, power generation facilities, and process industries where the ABB Procontic automation platform is deployed.
Alternative Names
HEIA303892RI EDI25IA HEIA3O3892R1 ED1251A HEIA303892R1 ED1251A HEDT300813R1 ED1633 HESG330061R1 ED1411C HEDT300272R1 ED1782 HEDT300340R1 ED1780A
Technical notes
The ABB HEIA303892R1 ED1251A is a dedicated Procontic processor board utilizing a 5V DC backplane bus for seamless rack integration. This embedded controller features manual hardware addressing via on-board DIP switches, ensuring fast configuration and dependable byte-level logic execution on web-based plant networks.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does ABB HEIA303892R1 ED1251A support industrial automation?
The board coordinates data communication across multiple I/O modules while processing control logic, allowing automation equipment to operate efficiently and reliably.
Does ABB HEIA303892R1 ED1251A require cabinet installation?
Yes. With an IP00 protection rating, ABB HEIA303892R1 ED1251A must be installed inside a suitable industrial control cabinet.
What hardware construction does ABB HEIA303892R1 ED1251A use?
ABB HEIA303892R1 ED1251A is manufactured with an FR-4 flame-retardant fiberglass PCB, operates from a 5 V DC power supply, and requires less than 1.5 A operating current.
