        • Lifecycle status

          Discontinued / Obsolete by OEM
          Apter Power helps source this discontinued ABB module and supports documentation review before an installed-system replacement.

        GJR2390200R1010 83SR04A-E

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        ABB GJR2390200R1010 83SR04A-E is a PROCONTROL P binary and analog control module for drive, group and unit control tasks.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for GJR2390200R1010 83SR04A-E
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for GJR2390200R1010 83SR04A-E

        • Manufacturer:
          ABB
        • Part Number:
          GJR2390200R1010 83SR04A-E
        • Product Family:
          ABB Procontrol
        • Product Type:
          Binary and Analog Control Module
        • Stock:
          1
        • Control modes:
          Binary control; analog control; signal conditioning
        • Program storage:
          Nonvolatile EEPROM
        • Process interfaces:
          4 hardware interfaces
        • Binary function groups:
          Up to 4 per module, subject to cycle time
        • Front indications:
          ST disturbance; SG module disturbance
        • Tariff Code:
          Please confirm the destination before shipping
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Control Program Station Interface Diagnostics Applications

        Features:

        • Programmable control: Binary and analog functions support drive, group and unit tasks in PROCONTROL P stations.
        • Stored application: User logic resides in nonvolatile EEPROM and is managed through the station bus.
        • Front diagnostics: ST and SG indicators distinguish communication-inclusive disturbances from module faults.
        ABB lists GJR2390200R1010 as the complete-module order number; retain it instead of relying on the 83SR04 family alone.

        The first TXT1 function block selects the operating mode, making the installed user list part of every replacement review.

        ST and SG cover different diagnostic scopes, so their combination directs maintenance toward module or communication checks.

        Apter Power supports the ABB GJR2390200R1010 83SR04A-E PROCONTROL P Binary and Analog Control Module through quotations, documentation review and replacement planning.
        ABB GJR2390200R1010 83SR04A-E Binary and Analog Control Module Manuals,Datasheets,Link
        Important Notice: Use the complete ABB order number and installed control documentation when selecting a service spare.
        • The first TXT1 function block selects the operating mode; program changes must preserve the intended control structure.
        • Binary mode has a variable cycle time, making the installed function-group schedule part of the service review.
        • Analog mode uses a fixed, selectable cycle time; the selected value belongs to the installed control application.
        • The user program resides in nonvolatile EEPROM and can be loaded or changed through PDDS on the station bus.
        • ABB places this module in a multi-purpose processing station, where it communicates with plant control through the station bus.
        • The station sets the module address automatically on insertion, so the host position governs the address used in service.
        • Four hardware interfaces connect the module to switchgear or process signals, supporting its configured control tasks.
        • Separate contact-supply branches are described as short-circuit-proof and interaction-preventing; the installed interface arrangement still governs field connections.
        • The ST lamp covers disturbances inside the module and in its data communication, widening the first diagnostic search.
        • The SG lamp identifies module disturbances only; compare both indications before treating a station fault as a board fault.
        • Incoming station-bus telegrams are checked with parity bits, providing an error-checking path for received data.
        • A valid user list is required for readiness; a powered spare without that list is not an operational replacement.
        • Unidirectional drive control uses the stored program to coordinate commands at an installed drive-control level.
        • Actuator and solenoid-valve control are documented applications when the configured plant interface matches the job.
        • Sequential and logic function-group control supports ordered actions across a drive, group or unit task.
        • Three-step control and signal conditioning provide other documented roles when the proper operating mode is selected.
        Description
        GJR2390200R1010 83SR04A-E is an ABB PROCONTROL P module for stored-program binary and analog control at drive, group and unit levels. Its R1010 ordering number identifies this product separately from other 83SR04 variants.

        GJR2390200R1010 83SR04A-E supports binary function-group control, three-step control and signal conditioning in the modes documented by ABB. The selected operating mode is established by the first TXT1 function block in the installed control structure.

        GJR2390200R1010 83SR04A-E stores its user program in nonvolatile EEPROM and exchanges data through the station bus. A valid user list is required before operation; service work therefore depends on the installed program and station configuration, not the hardware label alone.
        Alternative Names
        GJR2390200R1010 83SR04A-E GJR2390200 R1010
        Technical notes
        GJR2390200R1010 83SR04A-E stores its user program in nonvolatile EEPROM and becomes operational only after a valid user list is loaded. ABB documents the operating mode as selected by the initial TXT1 function block. For a service replacement, compare the installed user list and selected mode with the plant control documentation before returning the station to operation.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        A supplier quotes only 83SR04A-E; what should a buyer require before ordering GJR2390200R1010 83SR04A-E?
        Require the complete GJR2390200R1010 order number on the quotation and installed label. ABB lists R1010 as a complete-module order number, while the short type alone does not establish the same ordered variant.
        After fitting GJR2390200R1010 83SR04A-E, why can a station remain unready even though the module is powered?
        The module requires a valid user list before it becomes ready. Confirm that the intended program has been loaded through the documented station-bus/PDDS process before treating the hardware as faulty.
        If ST is lit while SG stays off on GJR2390200R1010 83SR04A-E, which fault area should maintenance investigate first?
        This lamp pattern points first toward the communication path because ST includes module and data-communication disturbances, while SG covers module disturbances only. Review station-bus diagnostics before condemning the board.
        When changing GJR2390200R1010 83SR04A-E from binary group control to analog three-step control, what selects the operating mode?
        The first TXT1 function block selects the operating mode. Update and validate the complete user list for the intended control structure rather than treating the change as a hardware switch setting.
        Can one GJR2390200R1010 83SR04A-E be assigned five binary function groups in a control design?
        ABB limits an R1010 module to four binary function groups, subject to cycle time. Divide the fifth group across the control design and review the resulting timing before release.
        After moving GJR2390200R1010 83SR04A-E to another processing station, should the old module address be copied?
        The multi-purpose processing station sets the module address automatically when the board is inserted. Use the target station records and diagnostics to validate the new position instead of copying the former address.
