Features:
- Dual-Channel Binary and Analog Control for Industrial Automation Applications
- Combines 4 Digital Inputs, 1 Digital Output, 2 Analog Inputs and 1 Analog Output Per Channel
- Operates in Conjunction with the Procontrol P14 System and Process Operator Station (POS30)
The GJR2396200R1210 83SR51F-E operates as the Control Module in a Procontrol P14 system, providing reliable binary and analog control for various industrial actuators. It continuously processes input signals from digital and analog sensors and generates precise control outputs to regulate system operation. Seamless integration is standard with the GJR2396200R1210 83SR51F-E, however using an optional Redundant Configuration will allow seamless switchover to a backup module in the event of a primary control failure. The GJR2396200R1210 83SR51F-E has made improvements in several areas over previous control module designs in addition to incorporating universal voltage capability within the Procontrol P14 rack.
The GJR2396200R1210 83SR51F-E provides essential control functions common to the entire system, and is a critical component of the control path, directly affecting the proper, normal operation of the overall automation system. One or two GJR2396200R1210 83SR51F-E control modules are required per rack depending on the desired redundancy level. The GJR2396200R1210 83SR51F-E occupies a single slot in the rack and can be plugged into any station of the PROCONTROL bus system.
For Dual Redundant Control applications, the Procontrol P14 System requires a second GJR2396200R1210 83SR51F-E control module installed in the redundant slot. In addition to standard single module operation, the redundant configuration also performs automatic switchover. The Procontrol P14 dual control configuration executes failover using the internal circuitry specified in the module options. Using this method, the redundant control system continually monitors the health of both modules. If the system detects that the primary control module is no longer providing stable output (outside configured voltage/tolerance levels), it will automatically transfer the load to the secondary module and place an event in the System Event List.
The GJR2396200R1210 83SR51F-E ABB Control Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB GJR2396200R1210 83SR51F-E Control Module Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB GJR2396200R1210 83SR51F-E Control Module Specs
General
- Manufacturer ABB
- Model GJR2396200R1210 83SR51F-E
- Condition New Original ready stock
- Product Family 83SR04G-E, 83SR51F-E,83SR51E-E
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- The official module envelope is 198 mm deep, 261 mm high and 20 mm wide for cabinet-fit verification.
- Confirm the installed connector assignment and exact nameplate extension before exchanging the control card.
- Preserve the validated P14 application and channel mapping before disturbing the rack or field conductors.
- Mixed feedback and command signals can be handled for closed-loop actuator positioning functions.
- Binary status paths and continuous process signals are combined for coordinated control sequences.
- The two-channel arrangement supports paired control duties without adding a separate signal-conversion card.
- The complete module provides twelve input channels and two output channels across its dual-channel architecture.
- AX and DX channel types identify the analog and binary signal resources documented by ABB.
- A 0.55 kg net weight and narrow 20 mm width support dense Procontrol P14 cabinet layouts.
