3BHE043576R0011 UNITROL 1005-0011 ECO

/ 4.9
1001 reviews | Need a Specific Revision?
ABB 3BHE043576R0011 UNITROL 1005-0011 ECO is a compact automatic voltage regulator with 5 A continuous and 10 A ceiling excitation current.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 3BHE043576R0011 UNITROL 1005-0011 ECO
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3BHE043576R0011 UNITROL 1005-0011 ECO

  • Manufacturer:
    ABB
  • Part Number:
    3BHE043576R0011 UNITROL 1005-0011 ECO
  • Product Family:
    ABB UNITROL
  • Product Type:
    Automatic Voltage Regulator
  • Stock:
    1
  • Official configuration:
    UNITROL 1005-0011 ECO
  • Continuous excitation current:
    5 A
  • Ceiling excitation current:
    10 A at 70 °C ambient
  • Digital inputs:
    8
  • Digital outputs:
    4
  • Analog outputs:
    2
  • Communication interfaces:
    USB and Ethernet
  • Protection class:
    IP20
  • Local HMI:
    Not included
  • Separate auxiliary-power terminals:
    Not included
  • Weight:
    1.32 kg
  • Estimated shipping dimensions:
    23x16x7cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Excitation Capacity ECO Configuration I/O and Access Product Applications

Features:

  • Excitation control: regulates generator voltage through a compact UNITROL 1005 platform.
  • ECO configuration clarity: preserves the -0011 boundary and its hardware omissions.
  • Commissioning discipline: links wiring, settings, and protection checks before automatic release.
This regulator is appropriate when the installed excitation design calls for the UNITROL 1005 ECO configuration and its documented current capability.

The purchasing decision must distinguish -0011 ECO from -0012 LIGHT because configuration-level differences are part of the ordered product identity.

A safe replacement records the existing excitation and generator settings, restores wiring and communication interfaces, then completes controlled regulation and protection tests.

Apter Power supports exact-configuration quotation and application review for ABB 3BHE043576R0011 UNITROL 1005-0011 ECO.
3BHE043576R0011 UNITROL 1005-0011 ECO Automatic Voltage Regulator Manuals,Datasheets,Links Important Notice: No qualified exact-model English PDF is attached. Use the complete product model in every document request.
  • Continuous current: 5 A excitation output.
  • Ceiling current: 10 A at 70 °C ambient.
  • Regulator role: automatic generator voltage regulation.
  • Application check: reconcile generator and exciter requirements before use.
  • Exact suffix: -0011 identifies the ECO configuration.
  • No local HMI: plan operation and service interfaces accordingly.
  • No separate auxiliary terminals: follow the documented ECO wiring boundary.
  • Variant separation: do not substitute -0012 LIGHT by name similarity.
  • Digital inputs: eight available channels.
  • Digital outputs: four available channels.
  • Analog outputs: two available channels.
  • Interfaces: USB and Ethernet support configuration and communication tasks.
  • Generator excitation: automatic voltage regulation within the documented current range.
  • Excitation retrofit: exact ECO configuration selection after engineering review.
  • Regulator replacement: restoration of approved wiring, settings, and protection.
  • Commissioning support: controlled voltage-regulation and protection validation.
Description
3BHE043576R0011 UNITROL 1005-0011 ECO is an ABB UNITROL 1005 automatic voltage regulator. ABB identifies the -0011 configuration as ECO and rates the unit for 5 A continuous excitation current with a 10 A ceiling at 70 °C ambient.

The ECO configuration of 3BHE043576R0011 UNITROL 1005-0011 ECO has no separate auxiliary-power terminals and no local HMI. Selection should preserve the exact -0011 suffix instead of substituting the separately ordered -0012 LIGHT configuration.

For installation or replacement, verify generator and excitation data, wiring, I/O allocation, communication requirements, protection settings, and the approved commissioning plan. Voltage regulation and protection checks must be completed before the excitation system is returned to automatic operation.
Alternative Names
3BHE043576R0011 UNITROL 1005-0011 UNITROL1005-0011 UNITROL 1005 ECO
Technical notes
3BHE043576R0011 UNITROL 1005-0011 ECO is the ECO configuration with no separate auxiliary-power terminals and no local HMI; do not confuse it with UNITROL 1005-0012 LIGHT. Match excitation ratings, wiring, I/O, communications, and settings carefully, and stop commissioning if generator data or protection limits are unresolved.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should a buyer distinguish 3BHE043576R0011 UNITROL 1005-0011 ECO from -0012 LIGHT?
Use the full ABB order number and -0011 ECO suffix; the ECO configuration has no local HMI and no separate auxiliary-power terminals.
What excitation capability is documented for 3BHE043576R0011 UNITROL 1005-0011 ECO?
ABB rates it for 5 A continuous excitation current and 10 A ceiling current at 70 °C ambient.
What should engineers verify before applying 3BHE043576R0011 UNITROL 1005-0011 ECO?
Verify generator and exciter data, required current, wiring, I/O allocation, communication, protection settings, and the commissioning procedure.
Can 3BHE043576R0011 UNITROL 1005-0011 ECO be released after power-up alone?
No. The team should complete wiring checks, configuration review, controlled voltage-regulation testing, protection validation, and approved handover.
Which interfaces are available on 3BHE043576R0011 UNITROL 1005-0011 ECO?
The official brochure lists USB and Ethernet interfaces; their use still depends on the approved project and service configuration.
What should receiving inspect on 3BHE043576R0011 UNITROL 1005-0011 ECO?
Inspect the complete order number, ECO suffix, enclosure and terminals, supplied accessories, physical condition, and documented configuration scope.
