1336-PB-SP5A

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1336-PB-SP5A is a 460 V common-bus precharge PCB listed for 1336STEF X40–X60 HP drives. It is a drive spare board, not a complete precharge assembly or complete drive.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1336-PB-SP5A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1336-PB-SP5A

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1336-PB-SP5A
  • Product Family:
    1336 Drives
  • Product Type:
    460 V common-bus precharge printed circuit board for 1336STEF X40–X60 HP drives
  • Stock:
    1
  • Spare-part function:
    Precharge PCB
  • Drive family:
    1336STEF
  • Input class:
    460 V
  • Configuration:
    Common bus (CB)
  • Documented power-code range:
    X40–X60 HP
  • Part scope:
    Printed circuit board only; not a complete drive or precharge assembly
  • Tariff Code:
    8504909090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compatibility Precharge Circuit Service Checks Application
  • Officially listed precharge PCB for the 1336STEF drive family
  • Matched to 460 V common-bus X40–X60 HP configurations
  • Board-level spare requiring complete drive and circuit verification

The Allen-Bradley 1336-PB-SP5A is a precharge control PCB for specified 1336STEF common-bus drives.

It is documented for the 460 V X40–X60 HP range and controls part of the DC-bus charging sequence.

Confirm the full drive nameplate, common-bus architecture, existing board label, and related precharge hardware before installation.

Availability, condition, price, and shipping time for Allen-Bradley 1336-PB-SP5A precharge PCB are confirmed during quotation.

Allen-Bradley 1336-PB-SP5A 1336STEF Precharge PCB Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use only after matching the complete 1336STEF drive catalog number
  • Confirm the 460 V rating and X40–X60 HP power-code range
  • Do not substitute a stand-alone precharge board for a common-bus board
  • Inspect charging resistors, contactor, fuses, and DC-bus components
  • Verify connector condition and control signals before energizing
  • Resolve the original precharge fault before replacing the PCB
  • Record the installed board label and drive fault history
  • Inspect for heat damage, contamination, corrosion, and prior repair
  • Follow qualified high-voltage lockout and discharge procedures
  • Common-bus conveyor drive sections using documented 1336STEF units
  • Coordinated process lines with shared DC-bus regeneration
  • Legacy 1336 drive systems requiring board-level precharge repair
Description
The Allen-Bradley 1336-PB-SP5A is identified in the official 1336 spare-parts list as a 460 V precharge printed circuit board for common-bus 1336STEF drives in the X40–X60 HP range.

The common-bus designation is important: this board is selected for a shared-DC-bus drive configuration and should not be assumed interchangeable with a stand-alone precharge board. The complete drive catalog number, voltage, power code, frame, and bus arrangement must be checked before purchase.

Replacement work should also inspect the contactor, charging resistors, fuses, DC-bus components, connectors, and fault history. The board alone will not correct an unresolved power-circuit or precharge-sequence problem.
Alternative Names
Allen-Bradley 1336-PB-SP5A AB 1336-PB-SP5A Rockwell Automation 1336-PB-SP5A 1336 PB SP5A 1336-PB-SP5A Precharge PCB
Technical notes
Allen-Bradley 1336-PB-SP5A is a 460 V common-bus precharge PCB for documented 1336STEF X40–X60 HP drives; confirm the complete drive nameplate and precharge circuit before installation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Allen-Bradley 1336-PB-SP5A be installed in a stand-alone 1336 drive?
Not by assumption. The official list identifies Allen-Bradley 1336-PB-SP5A for a common-bus configuration. A stand-alone drive uses a different precharge arrangement, so the complete drive catalog number and bus design must be verified.
What does the X40–X60 HP range mean when ordering Allen-Bradley 1336-PB-SP5A?
It is the documented 1336STEF power-code range for this board. Match the exact code on the drive nameplate; do not select the board from motor horsepower alone.
Does Allen-Bradley 1336-PB-SP5A include the precharge contactor and resistors?
No complete assembly should be assumed. The official description is a precharge PCB. Contactors, resistors, fuses, busbars, wiring, and mounting hardware must be identified and quoted separately when required.
Why can a drive still fail precharge after Allen-Bradley 1336-PB-SP5A is replaced?
The root cause may remain in the contactor coil or contacts, charging resistors, DC-bus capacitors, fuses, supply, connectors, feedback path, or control sequence. Test the whole precharge circuit before condemning another board.
Is Allen-Bradley 1336-PB-SP5A interchangeable with a similarly rated stand-alone precharge board?
No interchangeability should be inferred from voltage or horsepower. Common-bus and stand-alone boards serve different power architectures and must be matched by the official drive and spare-part references.
Does Allen-Bradley 1336-PB-SP5A require programming after installation?
No separate user programming is documented for the precharge PCB itself. However, technicians must verify connector placement, precharge timing, DC-bus charging, contactor operation, fault clearance, and safe startup before returning the drive to service.
What information is needed for a reliable Allen-Bradley 1336-PB-SP5A quotation?
Provide the full drive catalog number, input voltage, power code, frame, common-bus configuration, board-label photos, installed board number, fault history, and whether related precharge components are also required.
