1336F-BRF75-AE-DE

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1336F-BRF75-AE-DE is a 380–480 V 1336 PLUS II drive with German designation, AE conformity enclosure, and dual-duty ratings.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1336F-BRF75-AE-DE
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1336F-BRF75-AE-DE

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1336F-BRF75-AE-DE
  • Product Family:
    1336 Drives
  • Product Type:
    1336 PLUS II Adjustable Frequency AC Drive
  • Stock:
    1
  • Input Class:
    380–480 V AC or 513–620 V DC
  • Constant-Torque Rating:
    13.3 A, 7.5 HP / 5.5 kW
  • Variable-Torque Rating:
    15.4 A, 10 HP / 7.5 kW
  • Enclosure:
    AE — IP20 II (NEMA Type 1), CE/C-Tick Conformity
  • Output Frequency:
    0–400 Hz
  • Typical Efficiency:
    97.5%
  • Dimensions:
    26.0 × 35.0 × 21.2 cm
  • Frame Reference:
    A4
  • Input Phase:
    Three-phase for full-rated operation
  • Input Frequency:
    48–62 Hz
  • Output Voltage Range:
    0 to rated voltage
  • PWM Carrier Frequency:
    2–10 kHz; ratings based on 4 kHz
  • Tariff Code:
    8504409999
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Ratings Compliance Options Application
  • 380–480 V 1336 PLUS II adjustable-frequency drive
  • 7.5 HP constant-torque and 10 HP variable-torque ratings
  • AE NEMA Type 1 / IP20 conformity enclosure with German-language designation

1336F-BRF75-AE-DE is a German-designation 1336 PLUS II adjustable-frequency drive for compatible three-phase induction motors.

Its BRF75 code has distinct constant-torque and variable-torque ratings, while AE identifies the NEMA Type 1 / IP20 conformity enclosure.

Final selection must confirm actual motor current and duty, installation compliance, ventilation, braking equipment, options, command architecture, and the saved parameter set.

Availability, condition, price, and shipping time for 1336F-BRF75-AE-DE are confirmed during quotation.

Allen-Bradley 1336F-BRF75-AE-DE Adjustable Frequency AC Drive Manuals, Product Series, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Use 7.5 HP / 13.3 A for constant-torque duty
  • Use 10 HP / 15.4 A only for qualifying variable-torque duty
  • Confirm motor current and acceleration or deceleration demands
  • Treat AE as NEMA Type 1 / IP20 with conformity provisions
  • Follow the complete installation and EMC requirements
  • Do not treat AE as a washdown or outdoor enclosure
  • Confirm German-language documentation and operator-interface needs
  • Record SCANport devices, option boards, and firmware
  • Verify brake hardware, resistor duty, and parameter backup
  • Constant-torque induction-motor control up to the documented 7.5 HP rating
  • Variable-torque induction-motor control up to the documented 10 HP rating
  • Adjustable-frequency control of 380–480 V three-phase motors in an IP20 NEMA 1 EMC installation
Description
1336F-BRF75-AE-DE is a 380–480 V Allen-Bradley 1336 PLUS II adjustable-frequency drive with German-language designation.

The BRF75 rating provides 13.3 A, 7.5 HP / 5.5 kW for constant-torque duty and 15.4 A, 10 HP / 7.5 kW for variable-torque duty.

Its AE enclosure is NEMA Type 1 / IP20 with conformity provisions; duty, motor current, cooling, EMC installation, options, braking hardware, and parameters require verification.
Alternative Names
1336F-BRF75-AE-DE 1336F BRF75 AE DE 1336FBRF75AEDE Allen-Bradley 1336F-BRF75-AE-DE Allen Bradley 1336F-BRF75-AE-DE AB 1336F-BRF75-AE-DE Rockwell Automation 1336F-BRF75-AE-DE
Technical notes
Allen-Bradley 1336F-BRF75-AE-DE requires duty-specific sizing; verify German interface needs, AE installation compliance, airflow, motor current, braking hardware, and saved parameters.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What should be backed up before replacing Allen-Bradley 1336F-BRF75-AE-DE?
Record the complete parameter set, firmware information, motor nameplate data, acceleration and deceleration settings, I/O assignments, fault history, option boards, communication settings, and machine acceptance values.
Will the existing HIM and SCANport equipment work with Allen-Bradley 1336F-BRF75-AE-DE?
Compatibility must be verified rather than assumed. Record each HIM, adapter, communication module, cable, port assignment, and firmware level, then compare them with the applicable 1336 PLUS II documentation.
Can Allen-Bradley 1336F-BRF75-AE-DE be commissioned without the original parameter backup?
It can be configured manually, but commissioning becomes more difficult and risky. Reconstruct settings from drawings, motor data, PLC logic, option hardware, process requirements, and documented machine tests.
Can Allen-Bradley 1336F-BRF75-AE-DE replace an AA-EN drive directly?
Do not assume it can. Confirm enclosure and conformity requirements, language needs, power code, firmware, option boards, motor data, I/O, SCANport equipment, and installation approvals.
Why might Allen-Bradley 1336F-BRF75-AE-DE trip immediately after installation?
Possible causes include incorrect motor parameters, missing interlocks, incompatible option settings, wiring errors, unstable input power, output contactor operation, grounding problems, or an unresolved motor or load fault.
What cooling checks matter for Allen-Bradley 1336F-BRF75-AE-DE?
Verify vertical clearances, ambient temperature, altitude, cabinet heat removal, fan condition, unobstructed airflow, and neighboring heat sources against the official installation requirements.
What should be checked before reconnecting braking hardware to Allen-Bradley 1336F-BRF75-AE-DE?
Identify the brake option, resistor resistance and wattage, duty cycle, wiring, insulation, and existing fault history. Confirm compatibility with the drive and application deceleration energy.
