1756-L72S

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-L72S is a 4 MB/2 MB GuardLogix 5570 controller that requires a matched 1756-L7SP safety partner.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1756-L72S
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-L72S

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-L72S
  • Product Family:
    ControlLogix
  • Product Type:
    Logix 5572S Automation Controller 4M/2M
  • Stock:
    1
  • Standard/safety memory:
    4 MB / 2 MB
  • Local programming:
    1 USB
  • Storage:
    SD
  • Energy storage:
    1756-ESMCAP
  • Power dissipation:
    2.5 W
  • Listed firmware:
    GuardLogix 5570 v38.011
  • Controller family:
    GuardLogix 5570 Safety Controller
  • Standard memory:
    4 MB
  • Safety memory:
    2 MB
  • Nonvolatile memory:
    1784-SD1 1 GB or 1784-SD2 2 GB Secure Digital card
  • Operating temperature:
    0 to +60 °C
  • Storage temperature:
    -40 to +85 °C
  • Weight:
    0.25 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals 4M/2M Identity Controller Service Safety Verification Application
  • 4 MB user memory and 2 MB safety memory for larger GuardLogix 5570 projects
  • Requires a 1756-L7SP immediately to the right with matching major and minor firmware
  • Uses SD nonvolatile storage and the installed 1756-ESMCAP energy-storage module

1756-L72S is the 4 MB/2 MB GuardLogix 5570 controller for safety applications requiring more memory than the 1756-L71S.

The primary controller and 1756-L7SP form one safety pair; partner position and exact firmware alignment are essential.

Before substitution, verify both memory allocations, the validated safety signature, SD image, safety I/O and energy-storage-module status.

Availability, condition, price, and shipping time for 1756-L72S are confirmed during quotation.

Allen-Bradley 1756-L72S GuardLogix 5570 Controller Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm both standard and safety project memory requirements
  • Do not substitute a 2M/1M controller from family similarity alone
  • Review the approved safety application after any memory-class change
  • Use the USB Type B service port for temporary programming and maintenance access
  • Verify the installed 1784-SD1 image before any load-on-power-up or restoration operation
  • Inspect the 1756-ESMCAP status and observe the documented shutdown procedure
  • Use a 1756-L7SP immediately to the right of 1756-L72S
  • Match the major and minor firmware revisions of both safety-pair modules
  • Repeat the required safety validation after controller or safety-project changes
  • GuardLogix applications requiring 4 MB standard memory and 2 MB safety memory
  • SIL 3 and Performance Level e machine-safety systems using a matched 1756-L7SP
  • Distributed CIP Safety architectures using supported ControlLogix communication modules
Description
1756-L72S is a GuardLogix 5570 safety controller with 4 MB user memory and 2 MB safety memory.

It operates with a 1756-L7SP safety partner installed immediately to the right; both modules must use matching major and minor firmware revisions.

The controller uses SD nonvolatile storage and a 1756-ESMCAP energy-storage module. Preserve the safety signature and validation record during replacement.
Revisions

Revision Part #

Also known as

1756-L72S Ser B
1756-L72S/B, Series B, Rev B
Alternative Names
1756-L72S 1756 L72S 1756L72S Allen-Bradley 1756-L72S Rockwell Automation 1756-L72S Logix 5572S 1756-L72S
Technical notes
1756-L72S provides 4 MB user memory and 2 MB safety memory and requires a 1756-L7SP immediately to its right; match both firmware revisions and preserve the safety signature, SD image and ESM status.
