1785-ME32

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1785-ME32 is a 32K-word nonvolatile EEPROM memory module for compatible enhanced and Ethernet PLC-5 processors, with jumper-selectable write protection.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1785-ME32
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1785-ME32

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1785-ME32
  • Product Family:
    PLC-5
  • Product Type:
    32K EEPROM Memory Module
  • Stock:
    1
  • Memory Technology:
    EEPROM
  • Memory Capacity:
    32K words
  • Memory Type:
    Nonvolatile
  • Write Protection:
    Enabled by removing the jumper
  • Compatible Platform:
    Supported Enhanced PLC-5 processors
  • Operating Temperature:
    0 to 60°C
  • Storage Temperature:
    -40 to 85°C
  • Relative Humidity:
    5% to 95%, non-condensing
  • Operating Shock:
    15 g peak acceleration for 11 ms
  • Non-operating Shock:
    3 g peak acceleration for 11 ms
  • Vibration:
    2 g peak acceleration at 10 to 500 Hz
  • Dimensions:
    13.5 × 7.1 × 1 cm
  • Weight:
    0.070875 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Capacity Check Handling Image Control Application
  • Keeps an approved PLC-5 application available for controlled processor recovery
  • Moves stored program memory between compatible enhanced PLC-5 processors during planned maintenance
  • Locks the saved image against unintended changes when the write-protect jumper is selected

1785-ME32 is a removable application carrier that allows a supported PLC-5 processor image to be retained independently of chassis power.

Its 32K-word capacity is useful only when both the controller catalog and saved program are compatible with that module size.

Maintenance control should cover safe power removal, image verification, jumper state, physical labeling, and a tested restore procedure.

Availability, condition, price, and shipping time for 1785-ME32 are confirmed during quotation.

Allen-Bradley 1785-ME32 32K EEPROM Memory Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The official specification identifies 32K words of EEPROM capacity.
  • The target Enhanced PLC-5 processor must support the selected module.
  • Project size and processor limit must both be reviewed.
  • Remove processor and I/O-chassis power before installation or removal.
  • Use the processor card guides and locking bar to seat the module.
  • Inspect the connector area before returning the controller to service.
  • Verify the machine and project identity before writing the EEPROM.
  • Set the jumper for the required protected or writable state.
  • Label and validate the stored image before relying on it as a backup.
  • Nonvolatile storage for supported PLC-5 projects that require up to 32K words.
  • Program recovery procedures using a labeled and verified EEPROM image.
  • Enhanced PLC-5 maintenance where processor compatibility and safe power-down are confirmed.
Description
Allen-Bradley 1785-ME32 is the 32K-word member of the removable PLC-5 EEPROM family and is intended for verified applications that exceed the smaller ME16 capacity.

Program-image control is central to its use: the stored machine revision should be identified, tested, labeled, and then protected with the documented jumper so another controller is not loaded accidentally.

Physical exchange is performed only after processor and chassis power are removed, followed by inspection of the contacts, alignment in the card guides, engagement of the locking bar, and a controlled restore test.
Alternative Names
1785-ME32 Allen-Bradley 1785-ME32 Allen Bradley 1785-ME32 PLC-5 1785-ME32 Bulletin 1785-ME32
Technical notes
1785-ME32 program transfer requires a compatible Enhanced PLC-5 processor, verified 32K application image, de-energized chassis, correct seating, and controlled write-protection jumper; an unlabeled module risks restoring the wrong machine project.
