Allen-Bradley 1785-BCM/C is a Series C PLC-5 backup communication module for an installed primary and secondary controller arrangement.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1785-BCM/C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1785-BCM/C

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1785-BCM/C
  • Product Family:
    PLC-5
  • Product Type:
    PLC-5 Backup Communication Module
  • Stock:
    1
  • Module series:
    C
  • System family:
    PLC-5 backup
  • Module role:
    Backup communication
  • Installed arrangement:
    Primary and secondary controller pair
  • Order identity:
    1785-BCM/C
  • Pairing review:
    Compare installed rack records
  • Separate accessory:
    1785-BEM backup expansion
  • Revision evidence:
    Use the removed-module label
  • Weight:
    0.56 kg
  • Estimated shipping dimensions:
    3.2x14.6x26cm
  • Tariff Code:
    8517795000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Selection Installation Service Checks Applications

Features:

  • PLC-5 backup module: intended for controller redundancy arrangements.
  • Series C identity: the /C suffix identifies the replacement revision.
  • Installed-system fit: review the primary and secondary chassis records together.
1785-BCM/C is used in a PLC-5 backup arrangement where the existing controller pair and communication layout determine the spare-part requirement.

The Series C suffix matters: a similarly named 1785-BCM/A or 1785-BEM is not automatically an interchangeable replacement.

Before sourcing 1785-BCM/C, record the removed module label, rack position, companion controller, and installed firmware and wiring documentation.

Apter Power supports document review and exact-revision sourcing for the Allen-Bradley 1785-BCM/C PLC-5 backup module.
Allen-Bradley 1785-BCM/C PLC-5 Backup Communication Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Confirm the full 1785-BCM/C label, including the Series C suffix.
  • Identify the existing primary and secondary PLC-5 chassis before selecting a spare.
  • Compare the removed board revision and companion controller records; a family match alone does not establish interchangeability.
  • Capture the installed 1785-BCM/C slot, cable paths, and module markings before removal.
  • Use the site-approved PLC-5 backup procedure and the documentation for the installed revision.
  • Keep a rollback record for the original module and its settings during service.
  • If backup communication is unavailable, first compare the 1785-BCM/C status indicators with the site fault log.
  • Check whether the issue follows one module, one chassis, or a changed communication path.
  • Escalate ambiguous revision or pair behavior to a qualified PLC-5 service specialist before substituting hardware.
  • Spare-part support for an installed PLC-5 primary and secondary controller pair.
  • Maintenance of a legacy backup system where the Series C module identity is documented.
  • Revision-specific replacement planning during a PLC-5 lifecycle or migration project.
Description
1785-BCM/C is an Allen-Bradley PLC-5 backup communication module identified by its Series C suffix. It belongs to a legacy controller-redundancy arrangement, so the installed pair and its system documentation matter more than a family-level part match.

For a 1785-BCM/C replacement, record the original module marking, rack position, companion controller, cable connections, and revision information before comparing stock. The related 1785-BEM expansion module and other BCM series are separate identities and should not be treated as automatic substitutes.

Because 1785-BCM/C is discontinued, plan availability and any migration in the context of the complete PLC-5 backup system. A qualified controls specialist should validate the approved configuration and site procedure before returning the installation to service.
Alternative Names
1785 BCM/C 1785-BCM-C 1785BCMC
Technical notes
1785-BCM/C is identified by its /C suffix. The linked three-page document is a Series C reference excerpt from Rockwell's 1785-BCM family manual; the source pages use "1785-BCM Series C", not the full slash-suffix catalog string. Match the installed label, paired-controller records and site-approved configuration before applying switch or compatibility guidance. Series B settings are not evidence for Series C.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is the /C suffix important when replacing 1785-BCM/C?
It identifies Series C. Match the removed label and the installed primary/secondary rack documentation; a 1785-BCM/A, 1785-BCM/B or 1785-BEM listing is not proof of interchangeability.
Is 1785-BEM another name for 1785-BCM/C?
No. 1785-BEM is a separate backup expansion module. Check the required rack position and the original part label before ordering either item.
What should be recorded before removing a 1785-BCM/C?
Photograph the complete label, status indicators, rack slot and cable terminations, then save the associated primary/secondary controller records under the site change procedure.
Our 1785-BCM/C backup pair no longer communicates. What should I compare first?
Compare each module indication with the site fault log and check whether a recent cable, rack or configuration change preceded the issue. Escalate the findings to a qualified PLC-5 specialist; a spare module alone may not resolve a system-level fault.
Does a Series B manual establish Series C switch settings for 1785-BCM/C?
No. A family manual focused on Series B is background reference only. Obtain documentation for the installed Series C revision before applying any switch or compatibility instructions.
How should 1785-BCM/C be scoped for a modernization project?
Inventory both controllers, backup modules, communication paths and application records. Assess the complete redundancy function with the migration engineer rather than replacing only the 1785-BCM/C by part number.
